RV-2- 3D HL PRODUCT SPECIFICA T IONS 7 6. Hardware Sp ecifica tion Item Specificat ion Image proc essin g sys tem Color image proc essing - 1200 - mi llion - pixel CMO S color c amer a, - H igh - br ightnes s white LEDs …
RV-2-3DHL PRODUCT SPECIFICATIONS
6
5. Inspection Function Specification
Item Specification
Types of boards that can be
inspected
After solder printing, before reflow, after reflow
Parts that can be inspected
Square chips of 0402 or more, cylindrical chips, tantalum capacitors,
aluminum chip capacitors, transistors, SOP/QFPs (0.3 mm or greater
pitch), connectors, leads of discrete parts
* If resolution 5.0 μm / pixel, Square chip 0201 or more, SOP / QFP (0.2
mm or more pitches)
Inspection item
Lack of parts, offset, polarity, front-side back, no solder, bridge, solder
amount, disconnected insertion part, etc
RV-2-3DHL PRODUCT SPECIFICATIONS
7
6. Hardware Specification
Item Specification
Image processing system
Color image processing
- 1200-million-pixel CMOS color camera,
- High-brightness white LEDs, coaxial illumination
Resolution Standard: 12.0 μm/pixel, Optional: 5.0 μm/pixel
Image range Standard: 48.0 x 36.0 mm, Optional: 20.0 x 15.0 mm
Transfer conveyor type Single track
Transfer conveyor width
adjustment
Automatic adjustment
Height of transfer conveyor 900 mm -20 mm to +70 mm Adjustable using the adjuster feet
Processing time 0.20 second/1 screen
Positioning Reference on end face of board
Electric power
3-phase 200 to 230 V ±10%, 2.0 kVA or less (effectively 0.8 kVA)
(Power supply cable: 2.0 mm2 x 4-core cable, less than 3 m)
Air supply pressure 0.49 MPa
Control computer OS Windows 7, 64-bit
Optional Marking unit (Air type)
RV-2-3DHL PRODUCT SPECIFICATIONS
8
7. Option
7-1. Optional Software
Item Specification
Main system
• Character-recognition (OCR/OCV)
• Code reader (1D, 2D)
• Communication license
* Required when connecting to a data server
Peripherals
* It is your responsibility to
prepare a PC.
• Remote judgment (CCC mode)
• Remote judgment (OLR mode)
• Repair station
• SPC
• Offline editor
• Quality Traceability
Server system
* It is your responsibility to
prepare a PC.
• Data server
* Required when connecting an optional peripheral software.
• Data share
7-1-1. Optional Main System Software
Character-recognition (OCR/OCV)
This OCR (Optical Character Recognition) is a support tool that recognizes an alphanumeric character
string written on the board or part and converts it into the character data that can be handled on the
computer so as to make the judgment.
Resistance constants, IC characters, etc., can be recognized.
This OCV (Optical Character Verification) is a support tool that recognizes characters using the pattern
matching.
Code reader (1D, 2D)
The cameras on the inspection machine can recognize 1D (barcodes) and 2D (2D codes).
◆ Recognizable size
• 1D (barcode) : Maximum 50 mm
• 2D (2-dimensional code) : Maximum 25 mm x 25 mm * Minimum cell size: 0.1 mm square
◆ Recognizable code list
• 1D (barcode)
2/5 Industrial, 2/5 Interleaved, Codabar (NW-7), Code 128, Code 39, Code 93,
EAN-13 (JAN-13), EAN-8 (JAN-8), MSI, Pharma Code, GS1 Databar (RSS), UPC-A, UPC-E
• 2D (2-dimensional code)
Data Matrix ECC 200, QR Code, Micro QR Code, PDF417, Aztec
