RV-2-3DHL PRODUCT SPECIFICATIONS
3
2. Basic Specification
Item Specification
Model name RV-2-3DHL
External dimensions
940-mm (W) × 1,800-mm (D) × 1,530-mm (H)
(including a 2,006-mm (H) signal tower)
Weight 1,250 kg
Electric power
3-phase AC200 to 230 V 50/60 Hz 2.0 kVA or less
* Connection specification
Power supply cable: 2.0 mm
2
x 4-core cable, less than 3 m
Terminal block size: Terminal screw(M4), compatible power cable
AWG10-14 (2-5.5sq)
Terminal shape: Round terminal with insulation Terminal size 5.5 mm,
compatible screw diameter 4 mm
Air supply pressure
0.49 Mpa Air consumption: 10 L / min
* Connection specification
Hose connection shape: Hi Cupla 20PM (Nitto Kohki)
Reference international standards for machine safety
Machinery Directive: EN ISO 12100:2010, EN 60204-1:2006+A1:2009, 2006/42/EC ANNEX I
RV-2-3DHL PRODUCT SPECIFICATIONS
4
3. Environment Condition
Transportation and storage conditions
Item Environment condition
Transportation and
storage temperature
+10～+60 °C
Transportation and
storage humidity
30% to 80% (with no condensation)
Operating environment condition
Item Environment condition
Ambient temperature +15～+30 °C
Ambient humidity 30% to 65% (with no condensation)
Altitude 1000 m or less from the sea level
Degree of pollution
2 (IEC60664-1 compliant, corresponding to general electronic circuit board
assembly lines)
Overvoltage category III (IEC60664-1 compliant)
RV-2-3DHL PRODUCT SPECIFICATIONS
5
4. Applicable Boards
Applicable board specification
Item Specification
External board dimensions
■ Standard head
L 50 mm × W 50 mm to L 410 mm × W 590 mm
■ Longer-sized Specifications
L 50 mm × W 50 mm to L 650 mm × W 590 mm
■ Marking specification
L 50 mm × W 50 mm to L 330 mm × W 590 mm
Board thickness 0.3 to 8.0 mm
Maximum board height Standard Top side: 40 mm Bottom side: 70 mm
Payload
7.0 kg or less (The transfer speed is changed variably according to the
payload.)
* Please consult us if the weight exceeds the limit.
∗ The maximum board dimensions need to be changed according to the board weight and shape.
Loading a board having a part whose height exceeds 40 mm on the top side or 70 mm on the bottom side
may damage the board or cause the device to malfunction. The above dimensions provide clearances
from the shafts and lights when boards are transferred and inspected.
If a part or solder is installed/applied within 3 mm of either end of the board in the transfer direction, the
board cannot be transferred or positioned.
The maximum payload of the board is 7 kg. When you convey a board of weight more than 1 kg, you lower
the conveyance speed, and please use it. Let me carry in a board after cooling off enough so that board
surface temperature is as follows 60 °C Celsius after reflowing it. It causes belt damage, the loser when it
cannot cool off enough. (exchange indication 0.5 years)
Marking can not be used with inspection data with Longer-sized selection enabled for Longer-sized and
marking unit combination equipment. Marking can be used only in normal board mode.
Board W
Board L
Transfer rail part
