Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE 354 0921B20A BOL T 4 10921001 10-054 355 221K1004 RING C 8 4 10921001 10-055 356 221AA007 ROHS_HEX-SCT 35 M3L10 10921001 10-056 357 221AA017 ROHS_HEX-SCT 14 M4L10 10921001…
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
Fig. N1-4
1104-002
Fig. N1
302 0921C701 BRACKET 1 1092100110-002
303 09212600 ASSY_FE1_SEN 1 1092100110-003
304 09212601 ASSY_FE2_SEN 1 1092100110-004
305 09211609 ASSY_JE7_SEN 1 1092100110-005
306 0921160A ASSY_JE8_SEN 1 1092100110-006
307 0921160B ASSY_JE9_SEN 1 1092100110-007
308 09212602 ASSY_FE3_SEN 1 1092100110-008
309 0921160J ASSY_JE16_SEN 1 1092100110-009
310 09211605 ASSY_JE3_SEN 1 1092100110-010
311 09211606 ASSY_JE4_SEN 1 1092100110-011
315 211DE615 PLATE 2 1092100110-015
316 211DE856 GUIDE 2 1092100110-016
317 211F9304 BRACKET 4 1092100110-017
318 0921B10B SHAFT 2 1092100110-018
319 0921B006 BRACKET 4 1092100110-019
320 212B2317 CHUTE 1 1092100110-020
321 212B2318 CHUTE 1 1092100110-021
322 0921C103 PLATE 1 1092100110-022
323 0921B10C PLATE 1 1092100110-023
325 211AE127 COVER 2 1092100110-025
326 0921B600 BRACKET 1 1092100110-026
327 0921B601 BRACKET 1 1092100110-027
330 0921B002 BRACKET 1 1092100110-030
331 0921B003 BRACKET 1 1092100110-031
332 211G6443 BLOCK 1 1092100110-032
333 211G6444 BLOCK 1 1092100110-033
334 216E1452 PIN_LOCATE 2 1092100110-034
335 23G00183 SENSOR PELEC 4 1092100110-035
336 0921B106 PULLY_TIMING 2 1092100110-036
337 222D0050 BEARING RADIAL 4 1092100110-037
338 0921C100 GUIDE_LINEAR 1 1092100110-038
339 223L0399 BELT_TIMING 1 1092100110-039
340 211G5359 BLOCK 2 1092100110-040
341 211DB811 PLATE 11 1092100110-041
343 0920E10S FEEDER_GUIDE_R 1 1092100110-043
344 0920E10R FEEDER_GUIDE_L 1 1092100110-044
345 0921B304 COVER 1 1092100110-045
346 0921B807 ROD 1 1092100110-046
347 0921B808 ROD 1 1092100110-047
348 0921B809 BRACKET 2 1092100110-048
349 0921E20E SENSOR_PELEC 1 1092100110-049
350 23G10029 SENSOR_PHOTO 1 1092100110-050
351 23G00157 SENSOR PELEC 2 1092100110-051
352 23G00207 SENSOR PELEC 2 1092100110-052
353 0921B300 SENSOR_PELEC 2 1092100110-053
SIGMA-G5SA
SIGMA-G5SB
SIGMA-G5SC
SIGMA-G5SD
UNIT-13
Fig. N1
TRAVERSE F
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
354 0921B20A BOLT 4 1092100110-054
355 221K1004 RING C 8 4 1092100110-055
356 221AA007 ROHS_HEX-SCT 35 M3L10 1092100110-056
357 221AA017 ROHS_HEX-SCT 14 M4L10 1092100110-057
358 221AA016 ROHS_HEX-SCT 24 M4L8 1092100110-058
359 221AA018 ROHS_HEX-SCT 10 M4L12 1092100110-059
360 221AA028 ROHS_HEX-SCT 16 M5L8 1092100110-060
361 221AA031 ROHS_HEX-SCT 42 M5L16 1092100110-061
362 221AA032 ROHS_HEX-SCT 10 M5L20 1092100110-062
363 221AA034 ROHS_HEX-SCT 4 M5L30 1092100110-063
364 221FA001 NUT_HEX 2 M2 1092100110-064
365 221DA102 MACHINE_SCREW 8 FLT M2L6 1092100110-065
366 221DA114 MACHINE_SCREW 8 FLT M4L8 1092100110-066
367 221AA002 MACHINE_SCREW 2 PAN M2L6 1092100110-067
368 221DA090 ROHS_HEX-SCT 4 M3L6 SW+FWS 1092100110-068
369 221AA011 MACHINE_SCREW 4 PAN M3L8 1092100110-069
370 221DB003 MACHINE_SCREW 16 1092100110-070
371 221DA002 MACHINE_SCREW 2 PAN M2L6 1092100110-071
372 221DA207 MACHINE_SCREW 1 TRS M4L6 1092100110-072
373 221CA026 SET_SCREW 4 SET M3L3 1092100110-073
374 221HA101 WASHER 4 FW2 1092100110-074
375 221HA103 WASHER 14 FW3 1092100110-075
376 221HA104 WASHER 14 FW4 1092100110-076
377 221HA105 WASHER 68 FW5 1092100110-077
378 221HA001 WASHER 4 SW2 1092100110-078
379 221HA003 WASHER 18 SW3 1092100110-079
380 221HA004 WASHER 14 SW4 1092100110-080
381 221HA005 WASHER 68 SW5 1092100110-081
382 221AA006 WASHER 4 M3L8 1092100110-082
383 221HA203 WASHER 4 FWS3 1092100110-083
384 0921B005 COVER 2 1092100110-084
391 0921160N ASSY_SENSOR 1 1092100110-091
392 0921B007 BRACKET 4 1092100110-092
393 0921B008 BRACKET 2 1092100110-093
394 0921B009 BRACKET 2 1092100110-094
395 221AA005 ROHS_HEX-SCT 8 M3L6 1092100110-095
Fig. N1
1104-002
Fig. N1-4
SIGMA-G5SA
SIGMA-G5SB
SIGMA-G5SC
SIGMA-G5SD
UNIT-13
Fig. N1
TRAVERSE F
Fig. N1-5
パレットチャック
Pallet Chuck
1104-002
419
419
405
420
423
415
422
423
417
422
423
417
406
404
409
451
455
452
455
453
441
445
442
445
443
454
444
410
411
411
401
410
401
414
414
422
422
425
425
412
412
403
407
402
431
432
413
415
415
419
420
415
420
415
See Fig. N1-4
Key No.338
See Fig. N1-4
Key No.339
See Fig. N1-3
Key No.208
421
424
418
484
484
486
483
488
483
487
410
462
461
461
463
463
408
416
0921000R
0921000S
0921004R
0921000T
UNIT-13
Fig. N1
TRAVERSE F
Fig. N1
トラバースカート部
(FULL)
TRAVERSE CART SECTION(FULL)
