KGR_YG88_PL - 第11页
2 4 Y -axis Moving-axis KGR-090604 4 5 42 56 44 40 70 70 3 5 56 43 29 2 31 60 3 59 36 56 61 1 19 49 57 14 12 13 1 1 14 15 15 9 8 45 66 58 25 26 67 35 56 65 68 25 41 30 68 55 32 21 18 16 24 55 34 21 16 18 24 33 68 65 56 4…
1
4
X-axis
Moving-axis
KGR-090604
67
49
32
61
50
31
59
58
40
32
61
31
49
59
30
51
57
47
76
57
55
53
71
72
72
74
20
20
20
20
74
20
20
36
74
73
66
66
78
37
6
62
62
20
44
45
68
68
21
29
21
22
26
4
16
15
5
24
75
77
7
12
14
13
28
25
46
35
69
42
43
41
76
63
55
38
19
1
20
65
53
56
56
33
54
39
25
3
27
54
54
33
56
78
56
60
34
52
52
23
18
22
11
10
11
9
64
8
2
52
43
65
65
20
20
67
30
70
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KGS-M2211-01X FRAME X AXIS 1
2 KM0-M2220-00X COUPLING, X-AXIS 1
3 KGS-M2241-00X HOLDER, MOTOR X 1
4 KGS-M2242-00X HOLDER, BRG X 1
5 KGS-M2645-00X BRG.,ANGULAR 1
5-1 90990-26J008 BEARING 1 (2007/12/6) MDX0068 OK
6 KGR-M2261-00X HOLDER, HEAD 1
7 KGS-M2271-01X SCREW BALL X AXIS 1
7-1 KHW-M2271-00X SCREW BALL, X AXIS 1 (2007/7/19) MD70085 OK
8 90K63-511403 AC SERVO MOTOR 1
9 KGS-M2276-S0X X-AXIS GUIDE SET 1
10 KGA-M2651-41X DAMPER 24 ASSY. 1
11 KGA-M2649-00X NYLOCK BOLT 2 M2.6X10
11-1 90990-01J023 BOLT,HEX.SOCKET HEAD 2 (2007/10/29) MD00030 OK
12 KGS-M2248-00X DAMPER 1
13 KGS-M2240-00X SLEEVE, BRG. 1
14 KGS-M2244-00X COVER, BRG. 1
15 KV7-M2648-00X SPACER 3
15-1 90990-41J100 COLLAR 3 (2008/4/11) ME30019 OK
16 KG2-M9173-00X LOCK NUT 1
17
18 KV7-M2604-00X SUPPORT UNIT 1
19 KGS-M220A-30X TAPE X-AXIS 1
20 91317-04008 BOLT HEX. SOCKET HEAD 13
21 91317-04010 BOLT HEX. SOCKET HEAD 20
22 91317-04014 BOLT HEX. SOCKET HEAD 8
23 91317-04016 BOLT HEX. SOCKET HEAD 34
24 91317-05018 BOLT HEX. SOCKET HEAD 4
25 91317-06018 BOLT HEX. SOCKET HEAD 8
26 91317-06020 BOLT HEX. SOCKET HEAD 4
27 91317-06025 BOLT HEX. SOCKET HEAD 4
28 92903-06100 WASHER SPRING 4
29 99480-06012 PIN, PARALLEL 2
30 KGS-M220A-00X TAPE ,X DUCT 1
30-1 KGS-M220A-01X TAPE ,X DUCT 1 (2007/6/5) MD60003 OK
31 KGS-M220B-00X TAPE 2, X DUCT 1
32 KGS-M220C-00X TAPE 3, X DUCT 1
33 KGS-M2213-S1X PLATE A, X AXIS SET 1
34 KGS-M2236-00X PLATE A 1
34-1 KGR-M2236-00X PLATE A 1 (2005/12/2) MBY0002 OK
34-2 KGR-M2236-01X PLATE A 1 (2007/1/22) MD10016 OK
35 KGS-M2237-00X PLATE B 1
36 KGS-M2238-00X PLATE C 1
36-1 KGS-M2238-01X PLATE C 1 (2006/6/21) MC60055 OK
37 KGR-M2239-00X BRACKET 1 2
38 KGS-M2252-00X STOPPER 1
39 KGS-M2256-00X GRIP 1
40 KGS-M2267-A0X CABLE, DUCT 1
41 KGS-M226A-00X COVER CABLE 1
42 KGS-M2282-00X DOG, ORG 1
43 KGS-M2283-00X DOG, 2ND LIMIT 2
44 KGS-M2291-00X BRACKET, SENSOR 1
45 KGR-M220A-00X SENSOR, ORG (L=300) 1
46 KGR-M220B-00X SENSOR, OT (L=300) 1
47 KGT-M221A-A0X COVER DUCT ASSY 1
47-1 KHY-M221A-A0X COVER DUCT ASSY 1 (2008/12/7) MEY0066 OK
48
49 KGT-M2266-10X PLATE, NUT 2
50 KGT-M2268-00X BRACKET 1, TAPE 1
50-1 KHY-M2268-00X BRACKET 1, TAPE 1 (2008/12/7) MEY0066 OK
51 KGT-M2269-00X BRACKET 2, TAPE 1
51-1 KHY-M2269-00X BRACKET 2, TAPE 1 (2008/12/7) MEY0066 OK
52 KM0-M2251-00X NYLOCK BOLT 16 M8X22L
52-1 90990-01J024 BOLT,HEX.SOCKET HEAD 16 (2007/10/29) MD00030 OK
52-2 90990-01J179 BOLT,HEX.SOCKET HEAD 16 (2020/1/24) MT10096 OK
53 KV7-M2231-00X SPACER R, NUT 4
54 KV7-M2253-00X WASHER,SPRING 16
54-1 90990-38J001 WASHER,SPRING 16 (2008/4/15) ME20075 OK
55 KV7-M226B-00X PLATE 2
56 KV7-M2663-00X NYLOCK BOLT 16 M5X16
56-1 90990-01J030 BOLT,HEX.SOCKET HEAD 16 (2007/10/29) MD00030 OK
57 $USD8-6 JOINT 2
58 $US8 JOINT 2
59 $2TE8-R URETHANE TUBE 6500 MM
59-1 $2UB08-2F-R URETHANE TUBE 6500 (2008/11/11) ME00131 OK
60 91317-05010 BOLT HEX. SOCKET HEAD 6
61 91317-06012 BOLT HEX. SOCKET HEAD 8
62 91317-06030 BOLT HEX. SOCKET HEAD 4
63 92907-04200 WASHER, PLAIN 4
64 92907-10200 WASHER, PLAIN 1
65 97604-04308 SCREW,PAN HEAD W/W 6
65-1 97602-04308 SCREW,PAN HEAD W/W 6 (2006/2/14) MBY0144 OK
65-2 90990-11J003 SCREW,PAN HEAD W/W 6 (2006/3/13) MC30052 OK
66 98707-04010 SCREW,FLAT HEAD (+) 8
67 98907-03005 SCREW BINDING HEAD 4
67-1 98902-03006 SCREW BINDING HEAD 4 (2007/7/9) MD60168 OK
68 98907-03010 SCREW BINDING HEAD 2
69 KGR-M223E-00X COVER,REAR 1
69-1 KGR-M223E-01X COVER,REAR 1 (2005/12/2) MBY0002 OK
70 KGR-M223F-00X STAY L, HARNESS 1
71 KGR-M223G-00X STAY R, HARNESS 1
72 KGR-M223H-00X STAY 1 2
73 $UY6 JOINT 2
74 91317-04006 BOLT HEX.SOCKET HEAD 2
74-1 91317-04006 BOLT HEX.SOCKET HEAD 4 (2005/12/2) MBY0002 OK
74-2 91317-04006 BOLT HEX.SOCKET HEAD 12 (2006/7/24) MC70066 OK
75 KGS-M2278-00X COVER UNDER, GUIDE 1
76 91317-04010 BOLT HEX. SOCKET HEAD 4
77 91317-05008 BOLT HEX. SOCKET HEAD 2
78 KGS-M2271-A0X X-AXIS B.S.SUB ASSY 1 (2009/4/23) MF40074
2
4
Y-axis
Moving-axis
KGR-090604
4
5
42
56
44
40
70
70
3
5
56
43
29
2
31
60
3
59
36
56
61
1
19
49
57
14
12
13
11
14
15
15
9
8
45
66
58
25
26
67
35
56
65
68
25
41
30
68
55
32
21
18
16
24
55
34
21
16
18
24
33
68
65
56
45
8
47
9
11
15
13
14
15
12
57
14
63
27
6
1
47
39
9
64
54
46
53
61
28
66
58
26
25
26
25
65
56
47
7
56
65
68
48
17
23
69
69
49
51
69
50
51
22
20
16
37
62
52
38
71
21
18
17
22
20
16
18
21
63
72
27
67
26
25
28
23
48
39
47
9
64
54
65
68
4
72
46
53
19
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KGS-M2604-00X SUPPORT UNIT 2
2 KGS-M260A-00X TAPE, Y AXIS 1
3 KGS-M260B-00X TAPE, Y DUCT 1
4 KGS-M260C-00X TAPE 2, Y DUCT 1
5 KGS-M260D-00X TAPE 3, Y DUCT 1
6 KGS-M2611-00X FRAME R, Y AXIS 1
6-1 KGS-M2611-01X FRAME R,Y AXIS 1 (2007/6/25) MD40108 OK
7 KGS-M2612-00X FRAME L, Y AXIS 1
7-1 KGS-M2612-01X FRAME L,Y AXIS 1 (2007/6/25) MD40108 OK
8 KGS-M2628-00X LOCK NUT 2
9 KGS-M264A-00X HOLDER SET,Y AXIS 2
10
11 KGS-M2643-00X HOUSING, BRG. Y 2
12 KGS-M2644-00X COVER, BRG. HOUSING 2
13 KGS-M2645-00X BRG.,ANGULAR 2
13-1 KGS-M2645-01X BRG.,ANGULAR 2 (2006/8/31) MC80062 OK
13-2 90990-26J011 BEARING 2 (2007/12/6) MDX0068 OK
14 KGS-M2647-00X OIL SEAL 4
15 KGS-M2648-00X SPACER 6
15-1 90990-41J079 COLLAR 6 (2008/4/11) ME30019 OK
16 KV7-M2651-00X DAMPER, STOPPER 4
17 KV7-M2653-00X PIN,PARALLEL 1
17-1 90990-18J012 PIN,PARALLEL 1 (2007/11/30) MD00140 OK
18 KGS-M2654-00X PLATE, DAMPER 4
19 KGS-M2655-00X BLOCK 1, STOPPER 2
20 KGS-M2656-00X BLOCK 2, STOPPER 2
21 91317-04008 BOLT HEX. SOCKET HEAD 8
22 91317-06025 BOLT HEX. SOCKET HEAD 8
23 91317-08020 BOLT HEX. SOCKET HEAD 4
24 KGS-M2652-10X BRACKET, STOPPER 1 2
25 91314-04008 BOLT HEX.SOCKET HEAD 2
25-1 91312-04008 BOLT HEX.SOCKET HEAD 2 (2006/1/16) MBY0158 OK
26 92903-04200 WASHER PLAIN 9
27 KGS-M2666-00X HOLDER, NUT Y AXIS 2
28 KGS-M2671-00X SCREW BALL Y AXIS 2
28-1 KGS-M2671-01X SCREW BALL Y AXIS 2 (2005/5/12) MB50032 OK
29 KGS-M2678-A0X GUIDE, CABLE Y 1
30 KGS-M2694-00X BRACKET A, GUIDE 1
31 KGS-M2695-01X BRACKET B, GUIDE 1
32 KGS-M26F1-00X FRAME 1 1
33 KGS-M26F2-00X FRAME 2 1
34 KGS-M26F3-00X FRAME 3 1
35 KGS-M26F4-00X DUCT, HARNESS 1
36 KGS-M26F5-00X BRACKET, HARNESS 1
37 KGR-M260A-00X SENSOR, ORG (L=1000) 1
38 KGR-M260B-00X SENSOR, OT (L=1000) 1
39 KGR-M2611-00X COUPLING, Y-AXIS 2
40 KGT-M2667-00X PLATE 1
41 KGT-M2698-00X PLATE 1, CLAMP 1
42 KV7-M2266-00X PLATE, NUT 1
43 KV7-M2268-00X BRACKET 1, TAPE 1
44 KV7-M2269-00X BRACKET 2, TAPE 1
45 KV7-M2646-00X COIL SPRING 12
46 KV7-M2661-00X NYLOCK BOLT 20 M12X50
46-1 90990-01J028 BOLT,HEX.SOCKET HEAD 20 (2007/10/29) MD00030 OK
47 KV7-M2662-01X NYLOCK BOLT 16 M6X30
47-1 90990-01J029 BOLT,HEX.SOCKET HEAD 16 (2007/10/29) MD00030 OK
48 KV7-M2663-00X NYLOCK BOLT 40 M5X16
48-1 90990-01J030 BOLT,HEX.SOCKET HEAD 40 (2007/10/29) MD00030 OK
49 KV7-M2676-S2X Y-AXIS GUIDE SET 2
50 KV7-M2682-01X DOG, ORG. 1
51 KV7-M2683-01X DOG, 2ND LIMIT 2
52 KV7-M2691-02X BRACKET, SENSOR 1
53 90201-124G9 WASHER, PLAIN 20
54 90K63-611404 AC SERVO MOTOR 2
55 91314-05010 BOLT HEX. SOCKET HEAD 4
55-1 91312-05010 BOLT HEX.SOCKET HEAD 4 (2006/1/26) MBY0159 OK
56 91314-06010 BOLT HEX. SOCKET HEAD 28
56-1 91312-06010 BOLT HEX.SOCKET HEAD 28 (2006/1/26) MBY0159 OK
57 91317-04010 BOLT HEX. SOCKET HEAD 12
58 91317-04030 BOLT HEX. SOCKET HEAD 12
59 91317-05008 BOLT HEX. SOCKET HEAD 2
60 91317-05010 BOLT HEX. SOCKET HEAD 4
61 91317-05018 BOLT HEX. SOCKET HEAD 8
62 91317-06008 BOLT HEX. SOCKET HEAD 2
63 91317-06016 BOLT HEX. SOCKET HEAD 8
64 91317-06018 BOLT HEX. SOCKET HEAD 8
65 92903-06200 WASHER PLAIN 20
66 92907-04200 WASHER PLAIN 12
67 92990-04400 WASHER EXTL.TOOTHED 5
67-1 90172-00J040 WASHER,EXTL.TOOTHED 5 (2008/4/15) ME40115 OK
68 92990-06400 WASHER EXTL.TOOTHED 20
68-1 90172-00J060 WASHER,EXTL.TOOTHED 20 (2008/4/15) ME40115 OK
69 97604-04308 SCREW,PAN HEAD W/W 6
69-1 97602-04308 SCREW,PAN HEAD W/W 6 (2006/2/14) MBY0144 OK
69-2 90990-11J003 SCREW,PAN HEAD W/W 6 (2006/3/13) MC30052 OK
70 98903-03004 SCREW BINDING HEAD 4
70-1 98502-03004 SCREW PAN HEAD 4 (2006/2/17) MBY0200 OK
71 98903-03008 SCREW BINDING HEAD 2
71-1 98904-03008 SCREW BINDING HEAD 2 (2005/11/8) MBX0013 OK
71-2 98902-03008 SCREW BINDING HEAD 2 (2006/1/9) MBY0166 OK
72 KGS-M2671-A0X Y-AXIS B.S.SUB ASSY 2 (2009/4/23) MF40074
1
5
Head 1st Axis
Head
KGR-081113
2
11
4
32
34
13
15
14
17
18
12
48
61
10
1
37
5
41
19
3
42
43
20
33
36
38
60
44
73
41
27
26
30
39
24
7
9
49
61
55
64
47
72
51
65
55
59
56
55
55
58
57
66
61
50
54
71
59
53
68
70
70
60
57
62
62
59
52
21
28
29
46
59
63
60
60
53
52
53
52
69
66
23
25
16
8
6
45
67
35
22
31
40
1st Axis
74
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KGR-M7101-00X HOUSING, HEAD 1
1-1 KGR-M7101-01X HOUSING, HEAD 1 Casting Type (2006/3/27) MC30143 NG
2 KGR-M7102-00X HOLDER 1, MOTOR Z 1
3 KGR-M7105-00X BRACKET 1, Z AXIS 1
4 KGR-M7108-00X GUIDE, Z AXIS 1
5 KGR-M7109-00X HOLDER, BRG. Z 1
6 KGR-M710A-00X PLATE 1, BRG. 1
7 KGR-M710B-00X PLATE 2, BRG. 1
8 KGR-M710D-00X PLATE 4, BRG. 2
9 KGR-M710E-00X PLATE 5, BRG. 1
10 KGR-M710G-00X PLATE, GUIDE Z 1
11 KGR-M7115-00X BLOCK 1, Z AXIS 1
12 KGR-M7116-00X BLOCK 2, Z AXIS 1
13 KGR-M711A-00X GUIDE 1, SPRING 1
14 KGR-M711B-00X GUIDE 2, SPRING 1
15 KGR-M7120-00X SPRING, RETURN 1
16 KV7-M7121-01X GEAR, HEAD R 3
17 KV7-M7122-01X GEAR, MOTOR R 1
18 KV7-M7123-00X HOLDER, MOTOR R 1
19 KV7-M7124-00X NUT, LOCK 1
20 KV7-M7127-00X SET PIECE, LOCK 1
21 KGR-M7128-00X GUIDE, HOLDER 1
22 KGR-M7170-A0X N SHAFT 1 ASSY. 1
23 KGR-M7176-00X BELT, N AXIS 1
24 KGR-M7177-00X PULLEY, MOTOR N 1
25 KGR-M7178-00X PULLEY, SHAFT N 1
26 KGR-M7179-00X COLLAR, DOG 1 1
27 KGR-M7180-00X COLLAR, DOG 2 1
28 KGR-M7181-00X BRACKET, HOLDER 1
29
KGA-M7187-00X SHIM,GUIDE 1 t=0.01
KGA-M7187-10X SHIM,GUIDE 1 t=0.03
KGA-M7187-20X SHIM,GUIDE 1 t=0.05
30 KGR-M7188-00X BRACKET 1, MOTOR N 1
31 KGR-M7191-00X COLLAR 2,SHAFT 3
31-1 90990-41J023 COLLAR 3 (2008/4/15) ME20075 OK
32 KGA-M7193-01X PINION, Z AXIS 1
33 KGR-M7194-00X PLATE, BRG. 1
34 KGR-M7195-00X RACK, Z AXIS 1
35 KGR-M7196-00X WASHER 3,BRG. 3
35-1 90990-28J041 WASHER,PLAIN 3 (2007/12/20) MDX0104 OK
36 KGR-M7197-00X WASHER 4,BRG. 3
36-1 90990-28J042 WASHER,PLAIN 3 (2007/12/20) MDX0104 OK
37 KGR-M7198-00X PLATE, SENSOR 2
38 KGR-M7199-00X JOINT 3
38-1 90990-42J018 JOINT 3 (2008/6/17) ME30112 OK
39 KH5-M7118-00X PIN 2 TENTION 1
40 KV7-M71S6-00X WASHER,SEAL 3
40-1 90990-36J003 WASHER,SEAL 3 (2008/4/15) ME20075 OK
41 $TSH4-M5 JOINT 2
42 KV7-M71T1-00X BEARING 3 79M8ADF
42-1 90990-26J001 BEARING 3 (2007/12/6) MDX0068 OK
43 KV7-M71T3-00X BEARING 3 WBC7-13ZZA
43-1 90990-25J012 BEARING 3 (2007/12/4) MDX0031 OK
44 90440-01J060 CIRCLIP 1
45 99009-11800 CIRCLIP 1
46 99480-04008 PIN, PARALLEL 2
47 99480-04010 PIN PARALLEL: 4X10 2
48 KGR-M4880-00X AC SERVO MOTOR Z1 1
48-1 90K6D-02EE03 AC SERVO MOTOR Z1 1 (2006/10/24) MC90069 OK
49 KGR-M4882-00X AC SERVO MOTOR R1 1
49-1 90K6D-02FF11 AC SERVO MOTOR R1 1 (2006/10/24) MC90069 OK
50 KGR-M4884-00X AC SERVO MOTOR N1 1
50-1 90K6B-02GG14 AC SERVO MOTOR N1 1 (2006/10/24) MC90069 OK
51 KGR-M653G-00X HNS, SENSOR ASSY 1
52 $NK-4N NYLON CLIP 9
52-1 $NK-3N NYLON CLIP 6 (2007/1/22) MD10015 OK
53 97604-04308 SCREW,PAN HEAD W/W 9
53-1 97602-04308 SCREW,PAN HEAD W/W 9 (2006/2/14) MBY0144 OK
53-2 90990-11J003 SCREW,PAN HEAD W/W 9 (2006/3/13) MC30052 OK
53-4 90990-11J003 SCREW,PAN HEAD W/W 11 (2007/1/22) MD10015 OK
54 92907-05600 WASHER PLAIN 2
55 92A08-03303 SET SCREW M3X3 6
56 92A08-03305 SCREW, SET 1
57 92A08-04303 SET SCREW M4X3 4
58 92A08-04305 SET SCREW M4X5 2
59 91317-03006 BOLT HEX. SOCKET HEAD 10
60 91317-03008 BOLT HEX. SOCKET HEAD 11
61 91317-03010 BOLT HEX. SOCKET HEAD 16
62 91317-03014 BOLT HEX. SOCKET HEAD 4
63 91317-03016 BOLT HEX. SOCKET HEAD 2
64 91317-03022 BOLT HEX. SOCKET HEAD 4
65 91317-03025 BOLT HEX. SOCKET HEAD 4
66 91317-03035 BOLT HEX. SOCKET HEAD 14
67 91317-04006 BOLT HEX. SOCKET HEAD 1
68 91317-04010 BOLT HEX. SOCKET HEAD 2
69 91317-04016 BOLT HEX. SOCKET HEAD 2
70 91317-05015 BOLT HEX.SOCKET HEAD 7
70-1 91317-05014 BOLT HEX.SOCKET HEAD 7 (2007/1/22) MD10015 OK
71 91317-05020 BOLT HEX. SOCKET HEAD 2
72 91317-06020 BOLT HEX. SOCKET HEAD 4
73 KGR-M71C8-00X BRACKET, JOINT 1
74 90990-22J021 PACKING 2
