4022 593 50571 Service Manual 06.01 AX - series A8-17 A8. Spares , tools and materials A. SYSTEM 05-01 05-03 05-02 18-01 18-02 18-03
A8. Spares, tools and materials
Service Manual 4022 593 50571
A8-16 AX - series 06.01
A. SYSTEM
A8.3.7 System controller
System controllers exist in two different technical versions.
A8.3.7.1 System controller, 4022-594-1238X
A8.3.7.2 System controller, 4022-594-1430X
Item No.
Part of Item No.
Ordering Code
Description
Qty/ Mod
Priority indicator
Repair options
Replacement Instruction
Remarks
18-01 9498-396-00375 System controller 1 - - • Not compatible with
application software 1.02
18-02 9498-397-00375 System controller rep 1 Y RO • Not compatible with
application software 1.02
Same as 18-01 but repaired
18-03 AX software release 1 - - • See current software release
introduction service
information
Item No.
Part of Item No.
Ordering Code
Description
Qty/ Mod
Priority indicator
Repair options
Replacement Instruction
Remarks
05-01 9498-396-00080 System controller 1 - - •
05-02 9498-397-00080 System controller rep 1 Y RO • Same as 05-01 but repaired
05-03 AX software release 1 - - • See current software
release introduction service
information
4022 593 50571 Service Manual
06.01 AX - series A8-17
A8. Spares, tools and materials
A. SYSTEM
05-01
05-03
05-02
18-01
18-02
18-03
A8. Spares, tools and materials
Service Manual 4022 593 50571
A8-18 AX - series 06.01
A. SYSTEM
A8.3.8 Base CAN module
Item No.
Part of Item No.
Ordering Code
Description
Qty/ Mod
Priority indicator
Repair options
Replacement Instruction
Remarks
08-01 9498-396-00009 Can Coupler 1 Y - • Also in transport CAN
module
08-02 9498-396-00011 Dig. Input mod 4x 4 Y - • Number on part: 403
08-03 9498-396-00010 Dig. Output mod 4x 1 Y - • Number on part: 504
08-04 9498-396-00013 Potential multiplier 1 Y - • Number on part: 614
08-05 9498-396-00012 End terminal 1 Y - • Number on part: 600,
Also in transport CAN
module
