4022 593 50571 Service Manual
06.01 AX - series A8-35
A8. Spares, tools and materials
A. SYSTEM
11-01
11-02
11-03
11-04
11-05
A8. Spares, tools and materials
Service Manual 4022 593 50571
A8-36 AX - series 06.01
A. SYSTEM
A8.3.15 Placement controller
Item No.
Part of Item No.
Ordering Code
Description
Qty/ Mod
Priority indicator
Repair options
Replacement Instruction
Remarks
14-01 9498-396-00129 AX placement controller - Y - • Equals PA 1800/00
14-02 9498-397-00129 AX placement controller
Rep.
- Y RO • Same as 14-01, but
repaired
14-03 9498-396-00712 Flightcase AX placement
controller
- - - - For 14-01 and 14-02
14-04 9498-396-00081 Motion controller 1 Y - •
14-05 9498-396-00082 Motion amplifier 1 Y - •
14-06 9498-396-00083 EPC 1 - - • For placement controller
4022-591-05504 and older
14-07 9498-397-00083 EPC rep 1 Y RO • For placement controller
4022-591-05504 and older
14-08 9498-396-00087 Fan 1 Y - •
14-09 9498-396-00267 EPC 1 - - • For placement controller
4022-591-05505 and up
14-10 9498-397-00267 EPC rep 1 Y RO • For placement controller
4022-591-05505 and up
14-11 9498-396-00268 EPC adaptation kit 1 - - - See SI-A-series-016
4022 593 50571 Service Manual
06.01 AX - series A8-37
A8. Spares, tools and materials
A. SYSTEM
14-08
14-01
14-04
14-06
14-07
14-05
14-11
14-09
14-10
14-03
14-02
