A8. Spares, tools and materials
Service Manual 4022 593 50571
A8-44 AX - series 06.01
A. SYSTEM
A8.3.19 Trolley
Trolleys exist in two different technical versions:
• A8.3.19.1 A-Series feeder trolley (PA 2632/05)
• A8.3.19.2 FCM trolley for AX (PA 2631/10) / Upgraded FCM-II feeder trolley
(PA 2631/00)
A8.3.19.1 A-Series feeder trolley (PA 2632/05)
Item No.
Part of Item No.
Ordering Code
Description
Qty/ Mod
Priority indicator
Repair options
Replacement Instruction
Remarks
19-01 9498-396-00440 Swivelling wheel 2 Y - •
19-02 9498-396-00441 Wheel 2 Y - •
19-03 9498-396-00442 Footswitch 2 Y - •
19-04 9498-396-00443 Trolley power supply board 1 Y - •
19-05 9498-396-00444 Trolley controller board 1 Y - •
19-06 9498-396-00445 Feeder interface electrical board 1 Y - •
19-07 9498-396-00446 Trolley interface electrical board 1 Y - •
19-08 9498-396-00125 Contact pen 3 Y - •
19-09 9498-396-00560 Feeder interface front plate 1 Y - •
19-11 9498-396-00451 Upper feeder guide 1 Y - •
19-12 9498-396-00452 Handle 1 Y - •
19-14 9498-396-00458 Bottom feeder guide 1 Y - • Part of trolley
upgrade air
(PA 2532/10)
19-15 9498-396-00121 Air ram 1 Y - • Part of trolley
upgrade air
(PA 2532/10)
19-16 9498-396-00561 Component bin 1 Y - •
4022 593 50571 Service Manual
06.01 AX - series A8-45
A8. Spares, tools and materials
A. SYSTEM
19-01
19-02
19-03
19-04
19-05
19-06
19-07
19-08
19-09
19-11
19-13
19-10
19-12
19-14
19-15
19-16
A8. Spares, tools and materials
Service Manual 4022 593 50571
A8-46 AX - series 06.01
A. SYSTEM
A8.3.19.2 FCM trolley for AX (PA 2631/10) / Upgraded FCM-II feeder trolley (PA 2631/00)
Item No.
Part of Item No.
Ordering Code
Description
Qty/ Mod
Priority indicator
Repair options
Replacement Instruction
Remarks
13-01 9498-396-00117 Bumper strip 1 Y - -
13-02 9498-396-00120 Swivelling roller 2 Y - -
13-03 9498-396-00119 Wheel 2 Y - -
13-04 9498-396-00121 Air ram 1 Y - -
13-05 9498-396-00100 Trolley interface board 1 Y - -
13-06 9498-396-00124 O-ring 13.4x18x2.0 pvc 1 Y - -
13-07 9498-396-00099 Feeder interface board 4 Y - -
13-08 9498-396-00101 Assy power converter 1 Y - - Behind lid.
13-09 9498-396-00125 Contact pin 3 Y - -
13-10 9498-396-00106 Rocker switch aml24 2 Y - -
13-11 9498-396-00114 Rocker switch operator l 1 Y - -
13-12 9498-396-00115 Rocker switch operator r 1 Y - -
13-13 9498-396-00108 Air valve 8 Y - -
13-14 9498-397-00589 FCM trolley for AX
refurbished
1 - RO - Only for trolleys without
SVS-PRO
13-15 9498-398-00589 FCM trolley for AX
customized repair
1 - RC - For alle trolleys
