A8. Spares , tools and materials Service Manual 4022 593 50571 A8-50 AX - series 06.01 A. SYSTEM 6. Cylindrical screw M4x8 zinc coated (50x). Robot. 7. Cylindrical screw M3x6 zinc coated (50x). Robot. 8. Cylindrical scre…
4022 593 50571 Service Manual
06.01 AX - series A8-49
A8. Spares, tools and materials
A. SYSTEM
A8.4.3 First level spare parts kit (PA 2876/15)
Description Ordering code Application
Picture /
Spare part reference
AX 1st level spares kit
(PA 2876/15)
9498-396-00154
Front board clamp 9498-396-00032 10-01
Guide strip of rear
board clamp
9498-396-00042 09-06
Spring steel strip of rear
board clamp
9498-396-00038 09-07
Protection strip (4x) 9498-396-00153 09-05
Silencer 9498-396-00065 Part for air controller on robot 15-15
Valve (Picosol valve 2/2
NC)
9498-396-00066 Part for air controller on robot 15-16
Filter element 0.3 9498-396-00062 Part of air supply unit 03-01
Filter element 0.01 9498-396-00063 Part of air supply unit 03-03
Grease gun 9498-396-00394 To apply grease
Lubrication kit,
containing:
9498-396-00039 Lubrication (sufficient to lubricate the machine with maximum
configuration for 2 years, AX-5, 20 compact placement robots)
1. Grease nozzle and shaft Lubricating Z-spindles of transport lift
(The hexagon nozzle fits on
spindles)
2. Multemp SRL (3 x 80 gram)
Small brush included
• Linear guide and spindle of
Y-direction of robot.
•Linear guide and spindle of
X-direction of transport
•Spindles of Z-direction.
3. THK Grease type AFE (1 x 70
gram) Small brush included.
Linear guides, X-direction of robot.
4. 4 Brushes Applying lubrication
Assortment kit
containing:
9498-396-00045 Various repairs
1. Temperature sensor Y-
movement (5x).
Sensor on placement robot.
2. O-ring 1,8 x 0,7 (20x). Air controller and placement head.
3. Placement head, release bolt
(6x).
Interface placement head.
4. Air nipple (5x). Interface placement head.
5. Retain ring ∅ 4 (5x). Interface placement head.
A8. Spares, tools and materials
Service Manual 4022 593 50571
A8-50 AX - series 06.01
A. SYSTEM
6. Cylindrical screw M4x8 zinc
coated (50x).
Robot.
7. Cylindrical screw M3x6 zinc
coated (50x).
Robot.
8. Cylindrical screw M4x8 stainless
steel (10x)
Spacer block run-in and run-out
transport belt motor (only on front
transport rail).
9. Torx screw M2.5 x 10 stainless
steel (20x)
Run-in and run-out transport belt
motor on front transport rail.
10. Torx screw M2.5 x 6 stainless
steel (20x)
Run-in and run-out transport belt
motor on rear transport rail.
11. Torx screw M3 x 8 stainless steel
(20x)
Rear board clamp.
12. Cylindrical M3 x 16 stainless
steel (20x)
Front board clamp.
13. Knurled screw M4X16 zinc
coated (2x)
Stopper.
14. Counter sunk screw M4X12
(10x)
Cover plate (between support plate
and Z-plate).
15. Bolt M8x 20 + nipple
Optical kit, containing 9498-396-00043 Cleaning camera and laser
1. Optical tissue (100x) Cleaning BA-camera.
2. Chamois cloth double tip (100x) Cleaning component laser.
Double tips can be ordered
separately with ordering
code 9498-396-01105 (for
50 pieces)
3. Camelhair brush (1x) Cleaning component laser.
Description Ordering code Application
Picture /
Spare part reference
4022 593 50571 Service Manual
06.01 AX - series A8-51
A8. Spares, tools and materials
A. SYSTEM
A8.4.4 Second level spare parts
Ordering Code Description Application Picture / Spare part reference
9498-396-00080 System controller 05-01
9498-396-00016 Motion controller 06-09
9498-396-00267 EPC Placement controller, transport
controller
6-13, 14-07
9498-396-00268 EPC adaption kit Placement controller, transport
controller
To make EPC compatible with older types
of placement controller and transport
controllers (See SI-A series-016)
9498-396-00014 Ri-Ro servo driver board 06-10
9498-396-00015 X-servo amplifier 06-11
9498-396-00031 Z-servo amplifier 06-12
9498-396-00129 AX placement controller 14-01
9498-396-00081 Motion controller 14-02
9498-396-00082 Motion amplifier 14-03
9498-396-00127 AX compact placement robot 15-02
9498-396-00128 AX standard placement robot 15-04
9498-396-00070 Flexible cable guide 15-10
9498-396-00074 Connection board 15-11
9498-396-00142 Cable set 15-12
9498-396-00047 Pneumatic controller 15-13
9498-396-00138 AX placement head 16-01
