A8.3.7 System controller
System controllers exist in two different technical versions.
A8.3.7.1 System controller, 4022-594-1238X
A8.3.7.2 System controller, 4022-594-1430X
Item No.
Part of Item No.
Ordering Code
Description
Qty/ Mod
Priority indicator
Repair options
Replacement Instruction
Remarks
18-01 9498-396-00375 System controller 1 - - • Not compatible with
application software 1.02
18-02 9498-397-00375 System controller rep 1 Y RO • Not compatible with
application software 1.02
Same as 18-01 but repaired
18-03 AX software release 1 - - • See current software release
introduction service
information
Item No.
Part of Item No.
Ordering Code
Description
Qty/ Mod
Priority indicator
Repair options
Replacement Instruction
Remarks
05-01 9498-396-00080 System controller 1 - - •
05-02 9498-397-00080 System controller rep 1 Y RO • Same as 05-01 but repaired
05-03 AX software release 1 - - • See current software
release introduction service
information
