SIPLACE Software Guide SR.503.xx 3 Graphical user interface

Issue 12/01 EN 3.3 User interface - views and menus

NOTE

The following 6 menu options belong to the group of single functions.

The single functions are used to execute specific actions following fatal errors as well as to set up

and test the machine since they allow you to address the various functional modules in a defined

manner. 3

Gantry 1 F5 3

This is used to call the single functions for Gantry 1. These can be used to, for example, test the

functions of the revolver head. 3

NOTE

Each of the max. 4 gantries can be addressed separately.

The functions are identical for all the gantries. 3

Gantry 2 F6 3

Single functions for Gantry 2 3

Gantry 3 Shift 5 3

Single functions for Gantry 3 3

Gantry 4 Shift 6 3

Single functions for Gantry 4 3

Conveyor 2 F7 3

Single functions for PCB conveyor 2 (= left conveyor track in the case of dual conveyors) 3

NOTE

The single functions for Conveyor 2 can only be called if a dual conveyor has been configured.

The functions are identical to the functions for Conveyor 1. 3

Conveyor 1 F8 3

This is used to call the single functions for PCB conveyor 1 (= right conveyor track in the case of

dual conveyors). These are used to test and set the functional modules for PCB conveyor as well

as to set the conveyor width. 3

3 Graphical user interface SIPLACE Software Guide SR.503.xx

3.3 User interface - views and menus Issue 12/01 EN

NOTE

The next two menu options belong to the group of vision functions.

These functions are used to teach and test fiducials, measure components and change compo-

nent package form data.

The vision functions cannot be executed at the „Operator“ access level. 3

Teach fiducial F9 3

This menu item is used to call the functions for the processing of fiducials for PCB position recog-

nition.

For a more extensive description of the procedure refer to the „Vision functions“ section of the op-

erating instructions. 3

Test component F10 3

This menu item is used to call the functions for the processing of component package forms for

component centering.

For a more extensive description of the procedure refer to the „Vision Functions“ section of the

operating instructions. 3

Start SITEST F11 3

This automatically starts the SITEST test program for machine set-up and calibration.

The user interface, together with the procedure for the execution of the functions, is described in

the separate User’s Manual for the SITEST test program. 3

NOTE

The SITEST test program cannot be started from the "Operator" access level. 3

GEM F12 3

This menu item is used to call the GEM interface functions. See Option „GEM Interface“ on page

97. 3

NOTE

The GEM interface functions cannot be called unless the interface has been configured.

At the „Operator“ access level, only the function „Send and receive messages“ is available. In the

„GEM State View“ function the buttons are inactive for the „Operator“. 3

SIPLACE Software Guide SR.503.xx 3 Graphical user interface

Issue 12/01 EN 3.3 User interface - views and menus

Matrix-tray changer (only for S-25 HM) 3

In order to move to the view for the Siplace Matrix-tray changer you must click the 3

button (Location 1 or Location 3).

Or, from the "View" menu, select the "Feeder" function, and activate the button for MTC in the

dialog displayed. The following window opens.

Fig. 3.3 - 3 "Matrix Tray Changer" view (S-25 HM)

Key to Fig. 3.3 - 3

(1) Cassette number

(2) Tower number

(3) Level number

(4) Selects the "MTC" view.

(5) Help system for the topic „MTC“

You will find a detailed description of the MTC in the Station Operating Manual. Please refer to the

Online Help for parameter descriptions..
