Tape Feeder; 24;32 mm; Splice sensing; Type A
Kit No.
Kit Name
KXFW1KS7A00
PARTS LAYOUT
Section No.
M1
Ref
No.
Remarks
R
1
Q't
y
Tape Feeder; 24;32 mm; Splice sensing; Type A
Part No.
R
2
Kit No.
Kit Name
KXFW1KS7A00
Part Name
PARTS LIST
Section No.
R
3
PRESSER-COVER
1
1 N610090959AA
SLIT-PLATE
1
2 N610072585AC
TENSIONER
1
3 N610025479AB
COVER
1
4 N210123199AA
MAGNET
1
5 KXF0DYAZA00 NEO33
SCREW
1
6 XXE25C3FP
Hexagon socket set screw Flat point M2.5X3-45H SCHP
COVER
1
7 N210020703AA
COVER
1
8 KXFA1PR5B01
GUIDE
1
9 N210081356AB
PIN
2
10 KXFA1PQ5B00
PIN
2
11 KXFA1LHAA00
GUIDE
1
12 KXFA1NNAA00
SCREW
2
13 KXF0DYAJA00 S020659-2001(DDA)
SPRING
1
14 KXF0DYUFA01 (DA KXF0DYUFA01)
SCREW
2
15 N510002400AA SUSB Taptite pan head 2.6 8
GEAR
2
16 N210050456AB
PIN
1
17 KXFA1LSAA00
PIN
1
18 KXFA1KAAA00
COMB
1
19 KXFA1PT0A00
SCREW
1
20 XSN25+6VW
Cross recessed Pan head machine screw M2.5X6-A2-70
PIN
2
21 KXFA1KRAA00
LEVER
1
22 N210029790AA
PIN
1
23 KXFA1LTAA00
PIN
1
24 KXFA1LQAA00
LEVER
1
25 N210038151AA
ROLLER
2
26 KXFA1LPBA00
PIN
2
27 KXFA1KAAA00
SPRING
1
28 KXF0DK6AA00 (DA 0DK6A)
LEVER
1
29 KXFA1NKAA00
LEVER
1
30 KXFA1NSAA00
PIN
1
31 KXFA1Q0LA00
PLATE
1
32 N210081355AB
PIN
1
33 N210044529AA
M2
Tape Feeder; 24;32 mm; Splice sensing; Type A
Kit No.
Kit Name
KXFW1KS7A00
PARTS LAYOUT
Section No.
M3
