INFINITY

MANUAL ISSUE STATE

ISSUE 3 MARCH 2001

Microsoft and MS-DOS are registered trademarks of Microsoft Inc.

Windows, Windows NT and Windows NT Embedded are trademarks of Microsoft Inc.

All other brand and product names are trademarks or registered trademarks of their respective holders.

Trademark Acknowledgment

AutoFlex, FormFlex, Vortex and ProFlow are registered trademarks of DEK Printing Machines Limited.

In line with DEK Policy of continual improvement, this manual is periodically up-issued to reflect the latest

machine enhancements and provided with a date of issue which is displayed at the bottom of each hardcopy

page.

INFINITY

TECHNICAL REFERENCE

INTRODUCTION

Chapter Issue 4 Aug 01 Infinity Dual Image Manual 1.1

CHAPTER 1 TECHNICAL REFERENCE

INTRODUCTION The dual image option enables the Infinity machine to run products top side/

bottom side or two different products. The screen is shuttled forward and

backward within the machine to register an image corresponding to the product

to be printed.

A sensor frame is fitted above the input conveyor and the sensors are set up to

enable the detection of products as they are fed into the printing machine.

Two product detection sensor options are available:

A bar code reader mounted on the sensor frame at either the left or right input

conveyor (dependent upon input configuration), detects the board type by read-

ing the board bar code label. A sensor is utilized to trigger the Bar Code Reader

(BCR) ON at the appropriate time.

Alternatively, the machine may be set up with a ‘Product Sensor’ system to

determine the type of board that is to be printed. Where boards have recesses or

protrusions or are of a different length, the sensor determines the correct product

to be printed.

When the product type has been determined, a board present sensor detects the

board as it is fed to the machine. The machine uses the standard SMEMA

interface (or DEK supported interface) to give limited control of product move-

ments. The board is stopped on the input conveyor at the conveyor sensor, the

board present sensor is positioned on the sensor frame at this point.

Either the ProFlow unit or Squeegees can be used to apply paste to the screen.

NOTE

This manual contains supplementary information, instructions given in this

manual include installation, operation and technical reference information. The

information presented should be used in conjunction with the standard Infinity

manual set.

WARNING

LASER LIGHT SOURCE. THE BAR CODE READER UTILIZES A

LASER TO SCAN THE BAR CODE, DO NOT LOOK DIRECTLY IN

TO THE READER OR AT THE LIGHT DIRECTLY REFLECTED

FROM A SURFACE, AS SERIOUS DAMAGE CAN OCCUR TO THE
