3.2 Infinity Dual Imag e Manual Chapter Is sue 3 Sep 01 INFINITY A3 DR AWIN GS LISTING
Chapter Issue 3 Sep 01 Infinity Dual Image Manual 3.1
INFINITY
A3 DRAWINGS
LISTING
CHAPTER 3 A3 DRAWINGS
LISTING
Description Drawing No. Sheets Issue
State
Mechanical
Infinity Dual Image Screen Ski’s 168001 102
Frame Assembly 168107 202
Electrical
Variable Time Sensor Latch Switch 142771 1 09
288 Screen Load Circuit 167002 2 01
Typhoon Board Handling Circuit
155546
2
09
3.2 Infinity Dual Image Manual Chapter Issue 3 Sep 01
INFINITY
A3 DRAWINGS
LISTING
Mechanical Drawings Infinity Dual Image Manual 1
168001 Issue 02 Infinity Dual Image Screen Ski’s
F
E
D
C
B
A
654321
E
F
987
12345
678
9
PROJECTION
D
C
B
A
DRAWN
APPROVED
DATE
C
COPYRIGHT
DO NOT SCALE
SCALE
TITLE
DRAWING NUMBER
2000
BOM NUMBER
70.5
800.0
580.0
649.0
101.5
833.0
91.5
12.0
18.5
ITEM PART NO. DESCRIPTION QTY.
1
141769 ROLLER GUIDE 8
2
141770 PIN 8
3
141772 SPRING RETAINER 5
4
141776 GUIDE PLATE 2
5
141784 PIN 2
6
141785 BUSH 2
7
141787 SPACER 8
8
141795 SUPPORT PIN 8
9
141831 COMPRESSION SPRING 5
10
141861 ROLLER SKID 8
11
158414 FRONT END BRACKET. LH 1
12
158416 THUMB SCREW 4
13
158424 FRAME CLAMP ,BOTTOM 1
14
158426 FRAME CLAMP ,BOTTOM 2
15
158427 FRAME CLAMP,TOP 2
16
168002 SCREEN FRAME ADAPTOR - LH. 1
17
168003 SCREEN FRAME ADAPTOR - RH 1
18
168004 FRONT END BRACKET 1
19
168005 FRAME CLAMP,TOP 2
20
168006 FRAME CLAMP ,BOTTOM 1
21
168007 FRAME END BRACKET,REAR 1
22
168008 FRAME END BRACKET,REAR 1
23
700401 SCREW M3X6 CSK.SLTD.M/C ST.ST 4
24
700405 SCREW M4X8 CSK.SLTD.M/C ST.ST 6
25
700406 SCREW M4X10 CSK.SLTD.M/C ST.ST 20
26
700509 NUT M4 HEX. LOCK ST.ST 8
27
700510 NUT M5 HEX. LOCK ST.ST 4
28
700516 NUT M4 NI-LOCK 985 4
29
700835 SCREW M4X20 SKT. SET(GRUB) 5
30
B1584 PLAIN BUSH 2
31
FUIJ FRAMESCREEN FRAME 1
LATEST
ISSUE
No. DATE DCR INITIAL
02 31-JAN-01 26636 PH
1:2
PH
INFINITY DUAL IMAGE (FUJI) SCREEN SKI'S.
16-Nov-99
168001
138755
SH 1
OF 1
A
1
REFERENCE DIMENSIONS
SCALE 3:20
NOTE SET ROLLER SKID SUCH THAT THE FACE PROTRUDES
APPROX 1.0 mm BELOW THE TWO SIDES FRAMES
7
8
8
8
16
1
17
1
18
1
19
2
20
1
21
1
22
1
23
4
25
20
26
8
28
4
31
1
1
8
2
8
3
5
4
2
5
2
6
2
9
5
10
8
24
6
27
4
29
5
30
2
IT MAY NOT BE COPIED,REPRODUCED,
PUBLISHED OR DISCLOSED IN WHOLE
OR IN PART WITHOUT OUR WRITTEN
CONSENT.
IN IT, IS THE PROPERTY OF
THIS DRAWING AND THE COPYRIGHT
DEK
PRINTING MACHINES LIMITED,
