1004-003 27 Key No. P AR T No. P AR T NAME Q’ty REMARKS New Code NOTE S-1 S-1 list-1 必ずバージョンを確認してから、立体分解図の書類番号を選択して下さい。 （ Fig. S 参照） Make sure to con firm the version No. and sel ect the Document No. for th e Exploded Vie…

100%1 / 44
0909-002
26
テープフィーダ
T
APE FEEDER
GD-18083C GD-18083C
Fig. S-1
フレーム部
Frame Section
28
49
28
28
48
44
42
34
26
33
38
2
13
12
30
41
46
46
47
43
14
10
1
1
19
28
27
1
29
9
5
20
20
3
21
6
23
4
24
23
25
28
28
28
28
8
38
See Fig.S-6
Key No.405
See Fig.S-6
Key No.505
.
.
41
43
31
.
.
26
70
69
51
52
55
53
󰑉
Key No.23,25,49,54(󰀩󰂽
󱖒󰂡󰚗󰬡󰧨󱖤
Notice) The Key No. 23, 25, 49 and 54 (with a circle) are maintenance components.
For replacement timing, refer to the Instruction Manual
or consult our service
personnel.
72
49
S-1 illust-1
必ずバージョンを確認してから、立体分解図の書類番号を選択して下さい。（
Fig. S
参照）
Make sure to confirm the version No. and select the Document No. for the Exploded View. (Refer to Fig. S).
1004-003
27
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
S-1
S-1 list-1
必ずバージョンを確認してから、立体分解図の書類番号を選択して下さい。（
Fig. S
参照）
Make sure to confirm the version No. and select the Document No. for the Exploded View. (Refer to Fig. S).
1 6301735801 FRAME 1 877S--020-001 210B4456
2 6301624952 BLOCK(KIBAN) 1 877S--020-002 211G5664
3 6301730776 COVER(LA) 1 877S--020-003 211AD750
4 6301624723 COVER(LB) 1 877S--020-004 211AC688
5 6301730783 COVER(RA) 1 877S--020-005 211AD751
6 6301624747 COVER(RB) 1 877S--020-006 211AC690
8 6301688022 COVER(KIBAN) 1 877S--020-008 211AD219
9 6301366463 SLIDE(BASE) 1 877S--020-009 212C0385
10 6301266084 ASSY,LEVER(KAIJYO) 1 877S--020-010 016S0689
11 6301265827 PIN,HINGE 1 877S--020-011 216D0448
12 6301265834 ROLLER 1 877S--020-012 213C0206
13 6301265841 PIN,GUIDE(ROLLER) 1 877S--020-013 216F0879
14 6301646121 SPRING,TORSION 1 877S--020-014 222P0207
19 6301265735 COVER(HAISEN) 1 877S--020-019 211A8626
20 6301687537 PIN,LOCATE(TAPE) 4 877S--020-020 216E1741
21 6301265933 GUIDE(TAPE) 2 877S--020-021 212A2058
23 6301265742 COVER(FUTA) 2 877S--020-023 211A8627
24 6301629957 MECH PARTS(MAGNET) 2 877S--020-024 226J2473
25 6301265902 MECH PARTS(CUTTER) 1 877S--020-025 226J1909
26 6301274546 SCR PAN+SW+W 3X6 2 877S--020-026 221D0262
27 6300347906 MECH PARTS(RUBBER LEGS) 1 877S--020-027 226J0249
28 4110335700 SCR FLT 2.5X6 47 877S--020-028 221D0261
29 6300008494 BOLT,HEX-SCT 1 M2.5X6 877S--020-029 221A0104
30 6300007633 BOLT,HEX-SCT 2 M4X12 877S--020-030 221A0018
31 6300007640 BOLT,HEX-SCT 2 M4X14 877S--020-031 221A0019
33 4111407208 SCR FLT 4X6 1 877S--020-033 221D0224
34 4111255403 SCR PAN 2X4 1 877S--020-034 221E0482
38 4110010003 RING E 4 2 877S--020-038 221K0097
41 4111412905 WASHER SPR 4 4 877S--020-041 221H0284
42 4111412509 WASHER SPR 2 1 877S--020-042 221H0276
43 4111414008 WASHER V 4X9X0.8 4 877S--020-043 221H0315
44 4111413605 WASHER V 2X5X0.3 1 877S--020-044 221H0307
46 0804000G NAME PLATE,NOTICE 2 877S--020-046 0804000G
47 08040006 NAME PLATE,INDEX 1 877S--020-047 08040006
48 6301624921 COVER(HAISEN) 1 877S--020-048 211AC692
49 6301633961 MECH PARTS(SEAL) 2 877S--020-049 226J2477
51 6301587677 PLATE 1 877S--020-051 211DD071
52 6300787702 BOLT,HEX-SCT 2 M3X4 BOTTAN
877S--020-052 221A0231
53 6301614182 PIN,LOCATE 1 877S--020-053 216E1716
55 6300008890 SET SCREW 1 M3X6 SET
877S--020-055 221C0002
69 6301330280 SPRING PIN 1 877S--020-069 221J0061
70 6301259970 SPRING PIN 1 877S--020-070 221J0059
72 4111406805 SCR FLT 2X4 4 877S--020-072 221D0207
GD-18083C
0901-001
28
テープフィーダ
T
APE FEEDER
GD-18083C GD-18083C
Fig. S-2
テープ駆動部
T
ape Driving Section
A
A
B
B
C
C
1
12
102-04
113
102-08
106
123
124
102-03
102-08
103
1
10
109
101-08
101-04
101-08
101-07
101-03
101-09
124
107
127
102-07
127
129
130
129
130
131
121
1
15
114
145
121
122
103
1
1
1
124
108
126
129
130
See Fig.S-1
Key No.1
.
.
126
129
130
.
.
104
105
101
139
139
102
注)
Key No.103,104,105,113(○印)は保守品と
なっております。交換時期については取扱
説明書を参照、もしくは当社サービス員に
ご相談下さい。 
Notice) The Key No. 103, 104, 105 and 113
(with a circle) are maintenance components.
For replacement timing, refer to the Instruction
Manual or consult our service personnel.
102-09
S-2 illust-1
必ずバージョンを確認してから、立体分解図の書類番号を選択して下さい。（
Fig. S
参照）
Make sure to confirm the version No. and select the Document No. for the Exploded View. (Refer to Fig. S).
