7. Pallet Mounting and Removal
Warning
Always be sure to cut out the 200 V power before carrying out any
work.
Command operations are used for mounting and removal of pallets on the feeder.
Gate arm
"Up" lifter
"Up" lifter
Pallet
Grooved area
Cam follower
CP6M9043
Part 9 Chapter 7 Pallet Mounting & Removal
Edition 1.0 9-7-1 CP-6 Series Mechanical Reference
