Notes: Part 3 Chapter 2 Lubrication Edition 1.2 3-2-30 CP-6-series Mechanical Reference

2.21 Lubrication with AFC grease, Multemp LRL3,

SRL

AFC grease, Multemp LRL3, SRL in tubes may be fed into the grease nipples using a

grease gun, or expelled from the tube in the required quantity and applied.

CP6M3054

Part 3 Chapter 2 Lubrication

Edition 1.2 3-2-29 CP-6-series Mechanical Reference

Notes:

Part 3 Chapter 2 Lubrication

Edition 1.2 3-2-30 CP-6-series Mechanical Reference

Part 3 Chapter 3 Replacing Consumable Parts

Edition 1.1 3-3-1 CP-6-series Mechanical Reference

3. Replacing Consumable Parts

3.1 Nozzle Replacement

Point

Replace nozzles that become bent, deformed, or blocked. When removing the damaged

nozzle, be careful not to lose the spring loaded under it.

Procedure

Warning

Always be sure to cut out the 200 V power before carrying out any

work.

Nozzle

Spring

Push and turn

Remove slowly

CP6M3055
