1. WC Feeders

1.1 W8, W12 Feeder Part Names

Compatible tape types : W8, W12 x P4, W12 x P8

Feeder Part Names

Tape feed lever

Roller 1

Roller 2

Take-up reel

Roller 3

Holder

Parts reel

Tape leaf

Tape feed sprocket

Tape leaf lock

CP6M8001
