Notes: Part 1 1 Chapter 2 Noise Levels Edition 1.0 1 1-2-2 CP-6 Series Mechanical Reference
2. Noise Levels
Noise Levels of Standard Machines
The following table shows the results of noise level measurements for each type of
machine during operation. The conditions under which these measurements were made
are as follows.
Distance from the machine: 1 meter
Height from the floor: 1.2 meters
The machines used for conducting measurements were all standard specifications
machines. Refer to the table for the operation status of each machine.
Warning
Operators should exercise due caution in regard to health considerations
with noise levels of 70 dB being exceeded in some cases.
M/C Type Max. Noise Level (dB) Operation Status During Measurement
GSP-II
&GSP-III
During auto operation and temperature regulator operation
(frame lowered)
During auto operation (including contact noise between
nozzle stopper and board)
During auto operation and temperature regulator operation
During auto operation and temperature regulator operation
During auto operation with MTU
During auto operation with MTU
During auto operation with MTU
During auto operation (vacuum pump on)
During idle operation
During auto operation and temperature regulator operation
During auto operation and temperature regulator operation
During auto operation (Internepcon program used)
During auto operation (Internepcon program used)
During auto operation with MTU6
During one pitch movement of device axis in idle operation
with a full load of devices
During one pitch movement of device axis in idle operation
with a full load of devices
During one pitch movement of device axis in idle operation
with a full load of devices
During auto operation and temperature regulator operation
During auto operation and temperature regulator operation
During cleaning and temperature regulator operation
78.8
CP-6 79.6
CP-65 82.3
CP-6M
83.2
GP-2 &GP-3
70.6
72.3 (hermetic)
GL-V 69.9
GL-541
73.5
QP-242E
70.8
CP-642 82.1 (w/fence)
CP-642 76.3 (w/rear cover)
IP-I 76.0
IP-II 72.0
IP-III
84.4
CP-III 78.0
CP IV-3 77.0
GL-II
67.0
GSP-V
79.2
( IEC compatible machines included)
GP-641
GP-641
72.0 (double squ.)
GP-551 65.8
CP6M11007
Part 11 Chapter 2 Noise Levels
Edition 1.0 11-2-1 CP-6 Series Mechanical Reference
Notes:
Part 11 Chapter 2 Noise Levels
Edition 1.0 11-2-2 CP-6 Series Mechanical Reference
CP-6-series Mechanical Reference
Edition 1.0 March 10, 2000
Edition 1.1 July 20, 2001
Edition 1.2 August 5, 2002
Edition 1.3 February 1, 2003
Edition 1.4 March 24, 2003
