chapt er 2 Inspe ction It ems fo r Main t e nanc e Nex t Generation, Multi- Funct ional Placer DE CAN S 1 Mai nte nan ce H an dbo ok 2-2 Daily Inspections Inspection It ems for Maint enanc e
chapter 2
Inspection Items for Maintenance
Next Generation, Multi-Functional Placer
DECAN S1 Maintenance Handbook
2-1
Daily Inspections
Check-up List
Replacement
Time
Reference
Time
required
Period No Inspection Item Measures Tools
Daily
D-1 Nozzle Inspect and clean Air gun, swab, Ethyl Alcohol 2years
After use of the
machine
10 Minutes
D-2 Feeder, Feeder Base Clean Brush, cloth
After use of the
machine
10 Minutes
D-3 Backup Table Clean Cloth
After use of the
machine
5 Minutes
D-4 Air Filter Inspect and replace 1years Frequent inspection 30 Minutes
D-5 Mist Separator Filter Inspect and replace 1years Frequent inspection 30 Minutes
D-6 Fix Camera Cover Glass Inspect and clean
Ultra fine fiber cloth, alcohol,
Wrench
10 Minutes
D-7 Fix Camera Lens Inspect and clean Air Ejector, Wrench 10 Minutes
Setting the replacement period for parts
ㆍ Based on the regulated use environment.
ㆍ If the use environment is poor, the intervals for part inspection and replacement can be shortened.
ㆍ In the above table, C/S means our designated C/S company (STS) or our overseas local agents.
chapter 2
Inspection Items for Maintenance
Daily Inspections
chapter 2
Inspection Items for Maintenance
Next Generation, Multi-Functional Placer
DECAN S1 Maintenance Handbook
2-2
Daily Inspections
Inspection Items for Maintenance
chapter 2
Inspection Items for Maintenance
Next Generation, Multi-Functional Placer
DECAN S1 Maintenance Handbook
2-3
Weekly Inspections
Check-up List
Replacement
Time
Reference
Time
required
Period No Inspection Item Measures Tools
Weekly
W-1 Head Fly Camera Lens Clean Wrench, Air spray, cotton swab 5 Minutes
W-2 Head Mirror Clean Air spray, cloth 5 Minutes
W-3 Solenoid Valve Inspect and replace 2 years
Contact C/S for
replacement
20 Minutes
W-4 Head Vacuum Filter Inspect and replace 6 months
Contact C/S for
replacement
30 Minutes
Setting the replacement period for parts
ㆍ Based on the regulated use environment.
ㆍ If the use environment is poor, the intervals for part inspection and replacement can be shortened.
ㆍ In the above table, C/S means our designated C/S company (STS) or our overseas local agents.
Weekly Inspections
