AI-power ed Aut o Pr ogr amming (K AP) ▪ Industry-leading 3D prolome tr y technology conver ges with Koh Y oung’ s propriet ar y AI technology to deliver true automa tic progr amming. The innovative geometr y-b ased Ko…
Best Value 3D
Enhanced 3D Measurement Using Proprietary AI Technology
▪ The Smart & Dynamic True 3D measurement inspection technology on the Zenith Alpha incorporates AI to
deliver the accuracy needed for ultra-ne pitch and solder joint interreection challenges.
High Accuracy and Speed for Demanding Production Line
▪ Without sacricing accuracy and speed, the Zenith
Alpha combines mechatronics technology with cutting-
edge measurement capabilities to yield high throughput
suitable for demanding production lines.
Whole-board Foreign Material Inspection (WFMI)
▪ Inspection is not limited to components and solder joints. The Zenith Alpha combines 2D and 3D technologies
to identify Foreign Object Debris (FOD) across the board. The WFMI technology provides solutions for misplaced
chips, solder balls, burr, and other foreign materials that may lead to costly eld failures.
Identies Foreign Object Debris Across Entire Board
Ultra-Fine Pitch (Narrow Gap) Inspection
Advanced Tall Component Inspection
▪ Tall components on a board has traditionally been a challenge for AOIs. Yet the Zenith Alpha easily handles tall
components up to 25mm through Koh Young’s combined multi-projection Moiré interferometry system and
incomparable AI technologies. The Zenith Alpha overcomes component shadow challenges.
Standard AOITall Component Inspection
VS
AI-powered Auto Programming (KAP)
▪ Industry-leading 3D prolometry technology converges with Koh Young’s proprietary AI technology to deliver
true automatic programming. The innovative geometry-based Koh Young Auto Programming (KAP) software
solution reduces the programming process to minimizes time to production and reduces costs.
One Click Needed To Start KAP Programming Time Saved by 70%
“We didn’t think we would be able to satisfy both ends, however the Zenith Alpha
proved otherwise. It is truly a best value AOI machine as it is equipped with
Koh Young’s best algorithms and capabilities without it being unreasonable.”
- Global Industrial Manufacturer
01 02 03
“KSMART Solutions is the Gateway to a Smart Factory”
▪ Converts data into knowledge for eective and quality-driven actions
▪ Delivers an AI-powered process analysis and optimization tool
▪ Achieves an autonomous process optimization facility
KSMART Solutions: True 3D Measurement-based Process Control System
▪ Koh Young pioneered True 3D measurement technology 20 years ago to create a zero-defect future. This gave
rise to KSMART Solutions and its continuous eorts to leverage data and connectivity.
▪ KSMART Solutions uses Articial Intelligence to help automate process control while focusing on data
management, analysis, and optimization. It collects data from across the factory line for defect detection, real-
time optimization, enhanced decisions, and traceability to improve metrics, increase quality, and lower costs by
eliminating variance, false calls, and escapes.
Koh Young Technology Inc.
14
th
Floor, Halla Sigma Valley, 53 Gasandigital 2-ro, Geumcheon-gu, Seoul, 08588, Korea
Zenith Alpha_HQ_S_V02_ENG_202010
Specication
L XL
490 x 510 mm
(19.29 x 20.01 in)
º
690 x 690 mm
(27.17 x 27.17 in)
490 x 580 mm
(19.29 x 22.83 in)
690 x 580 mm
(27.17 x 22.82 in)
490 x 320 mm
(19.29 x 12.60 in)
690 x 320 mm
(27.17 x 12.60 in)
50 x 50 mm (1.97 x 1.97 in)
0.4 ~ 5 mm (0.02~0.2 in) 0.4 ~ 8 mm (0.02 ~ 0.31 in)
4kg (8.82 lbs) 10kg (22.05 lbs)
600kg
(1322.77 lbs)
700kg
(1543.24 lbs)
750kg (1653.47 lbs)
50mm(1.97 in)
220 Vac ± 10%, 1 Phase, 50/60 Hz, 5Kgf/cm2 (0.45Mpa)
1000 mm (39.37 in) 1200 mm (47.25 in)
1295mm(50.98 in) 1475 mm(58.07 in) 1475 mm(58.07 in)
1627 mm (64.06 in)
Requirements Solutions
3D Shadow Free Moiré Technology &
4-Way Projection (Zenith Alpha HS & Zenith Alpha UHS) /
5-Way Projection (Zenith Alpha HS+)
Multi-Frequency Moiré Technology
Warp Compensation (Pad Referencing + Multi-Frequency Moiré Technology)
True 3D Measurement
Inspection
Items
Missing, Dimension, Oset, Rotation, Polarity, Upside down, OCV/OCR, Coplanarity, Solder llet, Lifted lead,
Lifted body, Tombstone, Bridging
Zenith Alpha
Inspection
Performance
HS
6.5M 20μm
8M 10μm
8M 15μm
51 x 51 mm
28 x 28 mm
42 x 43 mm
55.3 cm
2
/sec (0.47 sec/FOV)
17.8 cm
2
/sec (0.44 sec/FOV)
36.9 cm
2
/sec (0.49 sec/FOV)
3 mm
4 mm
4 mm
±3%
IR-RGB
LED
(Dome
Styled
Illumination)
HS+
6.5M 20μm
8M 15μm
51 x 51 mm
42 x 43 mm
49.1 cm
2
/sec (0.53 sec/FOV)
32.1 cm
2
/sec (0.55 sec/FOV)
20 mm
25 mm
UHS
12M 10μm
12M 15μm
41 x 31 mm
61 x 46 mm
28.2 cm
2
/sec (0.45 sec/FOV)
57.3 cm
2
/sec (0.49 sec/FOV)
4 mm
PCB Handling
Automatic
Front / Rear Fixed (Factory setting)
Software
GERBER Data (274X, 274D), ODB++, Mounter JOB le, Allegro, Zuken, Mentor (Optional)
ePM-AOI, AOI GUI
SPC Plus, Review Station
Library, KYCAL
(Auto Camera Calibration, Auto Illumination Calibration, Auto Height Calibration)
WINDOWS 10 IOT ENTERPRISE LTSC 2019
Add-on
Solutions
(The above specications are subject to change without notice.)
º Please contact us for more information about PCB Sizes.
(The above specications are subject to change without notice. )
