3.2.1 Settings of Online Setup Verification
Here you can activate/deactivate the online setup verification. The following settings can be defined.
Actions on setup changeover
This means that one of the following actions is carried out after a setup with an deviating name becomes
active:
Activate pickup position with verification
If this setting has been activated, the barcode with the barcode fragment "Component" or "UID" has to
be scanned when activating a track after a track error.
Settings Meanings
General Delta setup verification (do not tear down identical components)
Identical components in the old and the new setup will not be torn down. The
pickup track, feeder type and component type are compared for this.
This setting is useful if your setups contain identical parts, e.g., if one side of
the line is always configured identically or if only some components have to be
changed on a station for a product variant.
Complete setup verification
The old setup is torn down in the database. A new, complete setup verification
is forced for the new given setup. Take this option into consideration if you
want to make sure that each setup is to be newly recorded.
Special case for tray
changers
All tray changers verified in the current setup are torn down accordingly on a
setup change.
No special handling
The relevant setting under General is used (Delta setup verification or Com-
plete setup verification).
Always complete setup verification
The Complete setup verification setting is used.
Special handling for
feeder next to WPC /
WPC3
The fixed location next to a tray changer (e.g. next to an MTC or a WPC on an
SX2) is torn down accordingly on a setup change.
No special handling
The relevant setting under General is used (Delta setup verification or Com-
plete setup verification).
Always complete setup verification
The Complete setup verification setting is used.
CAUTION
Setup change required
After a download to the machine, each verification-relevant modification to the setup triggers a
setup change in Setup Center.
Settings Meanings
For components
on S-Tables
Activating the pickup position with verification is activated for components on
S-tables.
For components
on X-Tables
Activating the pickup position with verification is activated for components on
X-tables.
Configuring Setup Center
General Settings of Online Setup Verification
28 User Guide SIPLACE Setup Center 5.1
Splice monitor
Settings Meanings
Action after missing re-
fill detection
None
Error handling with a splice monitor has been disabled. No action is needed.
Error handling with splice monitor
Error handling with splice sensor is activated.
Teardown packaging unit
The packaging unit needs to be torn down. Recommended setting to achieve
an enhanced and consistent process.
Action after missing
splice detection
None
Error handling with a splice monitor has been disabled. No action is needed.
Error handling with splice monitor
Error handling with splice sensor is activated.
% of original quantity to
detect missing splices
The option monitors splice sensors of S-feeders and X- feeders if the "Splice
detection" setting is activated for the component in the programming system.
If the quantity for a refilled packaging unit is undershot by the percentage val-
ue entered here, the track will be deactivated by Setup Center. The splice sen-
sor error has to be rectified in Setup Center and on the track.
The splice monitoring is activated if a value between 1% and 50% is entered.
The splice monitoring is deactivated if the value 0% is entered.
Please note that on the F-, S-, HF-, HS-, and C-series this setting only works
properly if the threshold value control is activated in the filling level control of
the station.
Settings Meanings
Teardown after foil torn
(X-Feeder)
If this setting is activated Setup Center cancels the relation between packag-
ing unit and feeder, in the event of an X feeder foil tear. Since the system is
unable to detect the replacement of a packaging unit in this error situation, this
setting ensures that the packaging unit is always rechecked after a foil tear.
This setting is always active if the option Tear down the packaging unit if the
verification status of the X-feeder is unreliable has been enabled at Settings
=> Line => Domain-Wide Verification Settings.
Enable quantity correc-
tion during refill
The quantity of the previous packaging unit can be corrected during refill. An
additional step on the scanner is necessary.
Configuring Setup Center
Settings of Offline Verification General
User Guide SIPLACE Setup Center 5.1 29
Next setup
3.2.2 Settings of Offline Verification
Here, you can activate/deactivate the offline setup verification. The following settings can be made:
3.2.3 General Settings for Setup Verification
Settings Meanings
Prepare next setup
The Next Setup icon is shown on the SIPLACE Setup Center user inter-
face. This icon opens the Next Setup view. This option requires a license.
External feeder LED
control
The status of the configured feeders at the station is shown on the feeder
LEDs.
The Next Setup view in SIPLACE Setup Center shows a list box with the fol-
lowing options:
▪ Station
▪ Preview
▪ Changeover
Behavior of the view
"Next Setup" after a job
download
The Next Download view is automatically closed or remains open after com-
pletion of the download.
Parameter Description
Active
Teardown after foil torn (X-
Feeder)
If this setting is activated Setup Center cancels the relation between
packaging unit and feeder, in the event of an X feeder foil tear. Since
the system is unable to detect the replacement of a packaging unit in
this error situation, this setting ensures that the packaging unit is al-
ways rechecked after a foil tear.
This setting is always active if the option Tear down the packaging
unit if the verification status of the X-feeder is unreliable has been en-
abled at Settings => Line => Domain-Wide Verification Settings.
Verify tray changers WPCs and MTCs are included in the offline setup verification.
Teardown changeover table
before verification
If this setting is activated, changeover tables that are to be used in a
new setup will be torn down automatically. If this setting is deactivat-
ed, these changeover tables will have to be torn down manually.
Check MSD level Activates the MSD verification (monitoring of moisture-sensitive com-
ponents) during offline setup verification. The MSD level specifies
how long moisture-sensitive components may be used for once they
have been taken out of their protective packaging.
Parameter Description
Allow Splicing of Alternative
Components
To allow splicing of alternative components you need to activate this
function in Setup Center.
You need to deactivate this option if you want to run alternative com-
ponents via a pre-setup feeder or complete packaging unit change on
the feeder.
Double check during refill (only
for packaging units with unique
ID)
When splicing a new tape reel the operator is prompted to scan the
preceding reel first and the new tape reel afterwards during scanning.
This function is only possible for packaging units with unique packag-
ing unit ID. This increases the safety during refill.
