Configuring Setup Center
Verification Settings for Lines Lines
User Guide SIPLACE Setup Center 5.1 37
3.4.3 Verification Settings for Lines
A line has been selected in the tree view. The following settings are possible for the selected line:
3.4.4 Threshold Settings
Threshold settings
This is where the threshold settings for the component level indicator are defined (from station software
701 and higher). The parameters shown differ, according to whether a line or station was selected. The
line settings apply to all 7xx stations on the line but can be modified for individual stations.
Settings Meanings
Allowed splice length The maximum number of tape parts (max. 30) of a packaging unit can be
set here for each line.
Allow feeder substitution
"8mmX“ ⇔ „2 x 8mm X"
The feeder types 8 mm X and 2x8mm X can be substituted for one an-
other, without changing the setup in SIPLACE Pro. The machine is able
to start the pickup immediately after a feeder type changeover. For pos-
sible exchange scenarios see the station software documentation.
Allow random feeder setup
during offline verification.
Active:
This enables the Random Setup setting, as defined in the SIPLACE Pro
setup, in Setup Center (at line level). The table-wise random setup func-
tion is not permitted for offline verification, irrespective of the downloaded
SIPLACE Pro setup.
NOTICE! If this option is disabled, the setup for this line must be
configured for the exact track in the pre-setup area, irrespective of the
setup setting in SIPLACE Pro. For detailed information about Random
Setup, refer to the operating manual for Random Setup, item no
[00196838-xx].
NOTICE
Only for lines with stations which have station software 701 or higher.
This view is only available if you have selected a line with stations which have station software
701 or higher.
Configuring Setup Center
Lines Verification Settings for Stations
38 User Guide SIPLACE Setup Center 5.1
We recommend the following settings:
3.4.5 Verification Settings for Stations
A station has been selected in the tree view. The following settings are possible for the selected station:
Settings Meanings
Threshold settings for
line:
Only available if you have selected a station which has station software 701
or higher.
The quick start values which are entered in the line are also applied to the se-
lected station.
Feeders Tape | Bulk case | Linear | Tray: tracks configured with the appropriate feeder
type, are set with the warning and stop threshold values.
Warning level Component count
If the calculated number of components drops below the specified number of
components, the track will be highlighted in orange in the view.
Residual length (mm)
If the remaining component tape (measured from the trailing edge of the feed-
er) is shorter than the indicated value, a warning ("Track Error") will be issued
and the track will be highlighted in yellow in the view.
Note: To monitor the residual length, the correct Feeder Pitch must be entered
for the component and/or component shape in SIPLACE Pro.
Residual time [hh:mm]
The remaining runtime is only possible from station software version 706. If
the residual time is lower than the value specified, the track will be marked or-
ange on the screen.
The residual time is the time until the track is disabled (stop threshold). If there
is no threshold defined to disable the track, the residual time is calculated as
the time until the feeder runs empty.
Deactivate track Component count
If the calculated number of components drops below the specified number of
components, the track will be deactivated and highlighted in red in the view.
Residual length (mm)
If the remaining component tape (measured from the trailing edge of the feed-
er) is shorter than the specified value, the track will be deactivated and high-
lighted in red in the view.
Note: To monitor the residual length, the correct Feeder Pitch must be entered
for the component and/or component shape in SIPLACE Pro.
Feeders Remaining runtime warning Disable at remaining length
Tape feeders Enter the time in minutes which is required to
procure and prepare the refill material.
300 mm
Bulkcase feeders Component count = 0
Linear feeder Component count = 0
Waffle-pack tray Component count = 0
Settings Meanings
Check MSD Level The MSD verification is activated for this station (monitoring of moisture-
sensitive components).
Configuring Setup Center
Connecting a Datalogic Scanner Scanner
User Guide SIPLACE Setup Center 5.1 39
3.5 Scanner
► In the main menu open Extras > Settings and the Settings window is opened.
► Select the category Scanner and the settings are opened.
In this view the settings for the scanners are made.
Datalogic scanner
Wired Scanner
Windows Mobile (WLAN) Scanner
3.5.1 Connecting a Datalogic Scanner
► In the main menu open Extras > Settings and the Settings window is opened.
► Select the category Scanner and the settings are opened.
► Go to Datalogic Scanner and select Connect Barcode Reader...
► The start page for the installation procedure will open. This will vary according to the scanner type.
Parameter Description
Active The use of the scanner can be activated/deactivated.
Serial port As an alternative the serial port can be set manually after deactivat-
ing the "Autodetect" switch.
Timeout (sec) If the scanner does not react within this time, the process will be ter-
minated.
Autodetect The automatic detection of the serial port to which the cradle of the
scanner is connected can be activated/deactivated.
Connect Scanner... This option allows the automatic configuration of one or more scan-
ners. For this, it must be ensured that the cradle of the scanner has
already been connected to the Setup Center computer.
The start screen for the installation procedure is shown. This differs
according to the scanner type used. See "3.5.1 Connecting a Data-
logic Scanner" [ ➙ 39].
Parameter Description
Active The input mask for the wired scanner is permanently shown in the
foreground of the Setup Center GUI. This setting is advisable if you
use a wired scanner that is integrated in the keyboard of the Setup
Center PC, in the pre-setup area.
Parameter Description
Active Here you can activate/deactivate the interface between Setup Center
and Symbol MC70 scanner.
Port Make sure that the port set in Setup Center is released for use.
Timeout (sec) If the scanner does not react within this time, the process will be ter-
minated.
