Configuring Setup Center Material Reorder Dockin g Station Dialog Box 44 User Guide SIPLACE Setup Center 5.1 3.8.1 Docking Station Dialog Box ► After you have made all se tt ings confirm these with OK . 3.9 M aterial Reo…
Configuring Setup Center
Connecting a Datalogic Scanner Docking Stations
User Guide SIPLACE Setup Center 5.1 43
Functions
Icons in the List of Existing Docking Stations
If no icon is displayed, there is currently no information on the status of the connection and the docking
station.
Icon Designation Description
1 Add docking station Select the Add Docking Station icon.
The Docking Station dialog box will open. See "3.8.1
Docking Station Dialog Box" [ ➙ 44].
2 Remove selected docking station Mark a docking station and select the "remove selected
docking station" icon.
-Or-
Mark a docking station in the selection list and select Re-
move from the context menu.
The entry is removed irrevocably even if you quit the
configuration dialog with Cancel.
3 Edit Selected Docking Station Mark a docking station and select the Edit Selected
Docking Station icon.
-Or-
Mark a docking station in the selection list and select Edit
from the context menu.
The Docking Station dialog box with the relevant settings
will open. See "3.8.1 Docking Station Dialog Box"
[➙44].
4 Update Docking Station You can test the connection of all entered docking sta-
tions and update the version numbers. If the connection
is not established, the corresponding error messages
will be issued in the notifications window.
5 Download Firmware Open the context menu in the list of existing docking sta-
tions and the Download Firmware function will be dis-
played in addition. Select this function to update the
firmware of the selected docking station.
See "7.10.3.1 Firmware Download to the Docking Sta-
tions" [ ➙ 139].
Icon Description
The docking station was recognized and successfully connected.
The displayed software version of the docking station does not correspond to the current sta-
tus.
The docking station could not be connected.
Configuring Setup Center
Material Reorder Docking Station Dialog Box
44 User Guide SIPLACE Setup Center 5.1
3.8.1 Docking Station Dialog Box
► After you have made all settings confirm these with OK.
3.9 Material Reorder
► In the main menu open Extras > Settings and the Settings window is opened.
► Select the category Material reorder and the settings are opened.
Material Reorder
After a successful setup verification the packaging unit can be marked for reordering. This is usually the
case if the line operator has taken the last packaging unit of a part number from the Kanban storage.
The "Reorder" information is saved in the database or can be sent as a message via OIB.
Settings Meanings
Display name Freely selectable name for the docking station. It is used for display only.
ID Text that is printed on the barcode label of the docking station. The format is:
sssnnnnnnnn
s: Three letters fro identifying the customer
n: Eight digits for identifying the docking station at the customer.
Comment A random text that gives further information on the docking station.
CAN The address of the CAN interface on the docking station. This address is set via
switches on the rear side of the docking station.
Bus The number of the CAN interface on the CAN interface board to which the dock-
ing station is connected.
Feeder kitting If a docking station is to be used as a feeder kitting station, the kitting function
can be enabled permanently. If a docking station is permanently enabled as a
feeder kitting station, you no longer need to scan in a control barcode to start the
component feeder kitting function.
CAUTION
Check the docking station settings
Please note that Setup Center cannot communicate with the docking station if these settings
are faulty. For this reason, carefully check the settings of the switches on the rear side of the
docking station and the cabling of the docking station with the CAN interface on the computer
on which the Setup Center is installed.
Settings Meanings
Reorder material dur-
ing Online-Verification
Activates reordering of packaging units after a successful online setup verifi-
cation.
Reorder material dur-
ing Offline-Verification
Activates reordering of packaging units after a successful offline setup verifi-
cation.
Reorder material via Database view
The material reorder is saved as a data set in the Setup Center database with
the parameters Component name, Line, Station, Location no, Date/time. Line,
station and location number indicate the location where the component was
refilled. The reorder data sets can be read out via the database view
v_Reorder.
Web service
The Web service settings field is activated. The material reorder is sent as a
message via OIB. See the OIB documentation for further information.
Configuring Setup Center
Docking Station Dialog Box MES
User Guide SIPLACE Setup Center 5.1 45
Web service settings
3.10 MES
► In the main menu open Extras > Settings and the Settings window is opened.
► Select the category MES and the settings are opened.
In this view you can configure the connection of a superordinate system for managing, updating and ver-
ifying packaging unit data.
3.11 Security
► In the main menu open Extras > Settings and the Settings window is opened.
► Select the category Security and the settings are opened.
Security
Several functions, e. g. the settings, the barcode label wizard or firmware functions can be locked by a
password request.
Parameter Description
Address: Address of the web service for processing the reorder.
Confirm successful reorder via
barcode reader
Activate this option to receive a feedback on the reorder (successful/
not successful) at the scanner
Parameter Description
OIB Service Locator Address Refer to the OIB SDK for the description and configuration.
OIB Service Name Refer to the OIB SDK for the description and configuration.
Requesting packaging unit data
from MES, if this is not already
in the Setup Center database
If the packaging unit data is not in the Setup Center database, this
can be requested from MES. If Setup Center does not receive any
packaging unit data, the system will be unable to use this packaging
unit. If this option is enabled, the operator will only request the pack-
aging unit ID but no other data via the scanner, irrespective of wheth-
er any data is supplied in answer to the request, or not.
Request verification status from
MES during online setup verifi-
cation
The connection is active for the online setup verification.
Request verification status from
MES during offline setup verifi-
cation
The connection is active for the offline setup verification.
Take gray zone value for the
packaging unit data from MES
If this function is enabled, the gray zone value determined by MES
will also be applied.
Parameter Description
Active The password request is activated. If the option is deactivated, the
Password Request dialog will be omitted.
Password Enter the new password.
Confirm password Reenter the new password here.
