Chapter A8
Service Manual 4022 593 51915
A.202 AX-301/501, AX-3/5 08.05
SYSTEM
A08.fm
A8.4.5 Consumables
Ordering code Description Reference
9498-396-00043 Optical kit A8.4.3 First level spare parts kit (PA 2876/15)
9498-396-00062 Filter element 0.3 A8.3.5 Air supply unit
9498-396-00063 Filter element 0.01 A8.3.5 Air supply unit
9498-396-00064 Replace unit air dryer A8.3.5 Air supply unit, only applicable when twin bulk
feeders are used
9498-396-00122 O-ring 7.65X1.78 0.12 A8.3.9.2 Trolley lift 4022-510-7995x
9498-396-00124 O-ring 13.4X18X2.0 pvc 0.60 E8.2.1 Tape cutter, spare parts
9498-396-01395 AX nozzle CPL1 A8.3.17 Placement head, toolbits and toolbit exchange unit
9498-396-01396 AX nozzle CPL2 A8.3.17 Placement head, toolbits and toolbit exchange unit
9498-396-00132 AX nozzle L3 0402-0603 A8.3.17 Placement head, toolbits and toolbit exchange unit
9498-396-00133 AX nozzle L4 0603-1206 A8.3.17 Placement head, toolbits and toolbit exchange unit
9498-396-00134 AX nozzle L5 1206-SO A8.3.17 Placement head, toolbits and toolbit exchange unit
9498-396-00135 AX nozzle L6 MELF A8.3.17 Placement head, toolbits and toolbit exchange unit
9498-396-00136 AX nozzle L7 A8.3.17 Placement head, toolbits and toolbit exchange unit
9498-396-00137 AX nozzle L8 A8.3.17 Placement head, toolbits and toolbit exchange unit
9498-396-01096 AX set of CV nozzles A8.3.17 Placement head, toolbits and toolbit exchange unit
9498-396-01144 AX nozzle V3 A8.3.17 Placement head, toolbits and toolbit exchange unit
9498-396-01145 AX nozzle V4 A8.3.17 Placement head, toolbits and toolbit exchange unit
9498-396-01146 AX nozzle V5 A8.3.17 Placement head, toolbits and toolbit exchange unit
9498-396-01147 AX nozzle V6 A8.3.17 Placement head, toolbits and toolbit exchange unit
9498-396-01148 AX nozzle V7 A8.3.17 Placement head, toolbits and toolbit exchange unit
9498-396-01202 Set of V seal round 9 A8.3.17 Placement head, toolbits and toolbit exchange unit
9498-396-00143 Grease EP lube
9498-396-00039 Lubrication kit A8.4.3 First level spare parts kit (PA 2876/15)
9498-396-00045 AX assortment kit A8.4.3 First level spare parts kit (PA 2876/15)
4022 593 51915 Service Manual
08.05 AX-301/501, AX-3/5 A.203
A08.fm
Chapter A8
SYSTEM
A8.5 Tools
A8.5.1 Glossary of terms
• Recommended standard tools
Tools that are used for general purposes during service and maintenance
activities. Local purchase by the customer is expected.
• Recommended special tools
Tools that are used for specific purposes during service and maintenance
activities. Local purchase by the customer is expected.
• Recommended Assembléon tools
Tools that are used for specific purposes during service and maintenance
activities and that are available via Assembléon. Tools can be ordered sepa-
rately or as part of a tool set, using the regular commercial channels.
•Description. . . . . . Name of the tool
•Application . . . . . Indication of what purpose the tool is used for.
•Ordering code . . . . The code number with which the tool or the tool-set can
be ordered at your regional service center.
•Identification and picture
Information to identify the tool, either a picture or an
identification number if applicable, or both. The last digit
of an identification number indicates the version of a
certain tool. The higher this digit the later the tool. The
listed identification number is the minimum required
version. All later versions are compatible.
Chapter A8
Service Manual 4022 593 51915
A.204 AX-301/501, AX-3/5 08.05
SYSTEM
A08.fm
A8.5.2 Recommended standard tools
Quantity Description
1 Open end/ring wrench 5 mm
1 Open end/ring wrench 5.5 mm
1 set Open end/ring wrenches 6 - 24 mm
1 Socket screwdriver 4 mm
1 Socket screwdriver 5 mm
1 Socket screwdriver 7 mm
1 Socket screwdriver 8 mm
1 Socket screwdriver round-head 2.5 mm
1 Socket screwdriver round-head 3 mm
1 Socket screwdriver round-head 4 mm
1 Socket screwdriver round-head 5 mm
1 Allen key 0.9 mm
1 Allen key 1.27 mm
1 set Allen key 1.5 - 10 mm
1 set Allen wrenches (short)
1 set TORX screwdrivers T7 - T40
1 Screwdriver TORX T6
1 Screwdriver TORX T7
1 Screwdriver TORX T10
1 Screwdriver TORX T15
1 Screwdriver no. 1 insulated
1 Screwdriver no. 2 insulated
1 Screwdriver no. 3 insulated
1 Screwdriver no. 4 insulated
1 Screwdriver no. 5 insulated
1 Screwdriver no. 4 short
1 Screwdriver no. 4 square
1 Screwdriver clamping M2 - M3.5
1 Screwdriver clamping M3.5 - M5
1 set Precision screwdrivers
1 Phillips screwdriver no. 0
1 Phillips screwdriver no. 1
1 Phillips screwdriver no. 2
1 Measuring tape 2 meter
1 Calliper gauge 150 mm
1 set Feeler gauges 0.03 - 0.5 mm
1 ESD-set
1 Multi meter
