4022 593 51915 Service Manual 08.05 AX-301/501, AX-3/5 A.155 A08.fm Chapter A8 SYSTEM 01-01 01-02 01-03 01-04 01-05 01-06 01-07 01-08 01-09 01-11 01-12 01-13 01-14 01-03 01-03 01-03 01-01 01-02 01-15 01-13 01-16 01-17 01…

Chapter A8

Service Manual 4022 593 51915

A.154 AX-301/501, AX-3/5 08.05

SYSTEM

A08.fm

A8.3.3 Base

Current spare parts list, see www.assembleon.com

Qty/ Mod

Priority indicator

Repair options

Replacement Instruction

Remarks

Item No.

Part of Item No.

Ordering Code

Description

01-01 9488-396-00103 Safety Interlock 2 Y - -

01-02 9498-396-00004 Actuator key 2 Y - -

01-03 9498-396-00003 Emergency stop button 4 Y - •

01-04 9498-396-00006 Indicator green 1 - - •

01-05 9498-396-00007 Indicator white 1 - - •

01-06 9498-396-00008 Indicator blue 1 - - •

01-07 9498-396-00005 Buzzer 1 - - •

01-08 9498-396-00091 Touch screen 1 Y - -

01-09 9498-396-00093 Power supply touchscreen 1 - - -

01-11 9498-396-00067 Keyboard with touchpad 1 - - - In drawer.

01-12 9498-396-00079 Hub/Switch 1 Y - • Behind door.

01-13 9498-396-00109 Fan 2 Y - - Behind transport and system

controller.

01-14 9498-396-02415 Main switch 3-phase Neutral 1 - - -

9498-396-00026 Main switch 1 - - -

01-15 9498-396-00563 Software licence hardware key,

limited validity 300 machine hours.

1Y - • Behind door. Refer to

B8.2.4

9498-398-00563 Software licence hardware key 1 Y RC • Behind door. Refer to B8.2.4

01-16 9498-396-01149 Component bin 3/5 - - • Only applicable in case

upgraded FCM feeder trolleys

are used.

01-17 - A-series feeder trolley - E8.2.1 Tape cutter, spare parts

01-18 FCM feeder trolley for AX 3/5-301/

501

E8.6 FCM feeder trolley for AX-

301/501, Upgraded FCM feeder

trolley, spare parts

01-19 - 9498-396-01735 AX FeederL. ID FCM-II TR 1 - - - Set of 5 strips for AX-301 or 501.

Only applicable in case

upgraded FCM feeder trolleys

are used

01-20 - 9498-396-01857 AX-5 Feederlane ID set 1 - - - Set of 5 strips for AX-301 or 501.

Only applicable in case A-series

feeder trolleys are used

4022 593 51915 Service Manual

08.05 AX-301/501, AX-3/5 A.155

A08.fm

Chapter A8

SYSTEM

01-01

01-02

01-03

01-04

01-05

01-06

01-07

01-08

01-09

01-11

01-12

01-13

01-14

01-03

01-01

01-02

01-15

01-13

01-16

01-17

01-18

01-19

01-20

Chapter A8

Service Manual 4022 593 51915

A.156 AX-301/501, AX-3/5 08.05

SYSTEM

A08.fm

A8.3.4 Mains supply unit and transformer

Mains supply units exist in two different technical versions.

• A8.3.4.1 Mains supply unit, PA 1120/04 and newer, PA 1121/04 and newer

• A8.3.4.2 Mains supply unit, PA 1120/03 and older, PA 1121/03 and older

A8.3.4.1 Mains supply unit, PA 1120/04 and newer, PA 1121/04 and newer

Current spare parts list, see www.assembleon.com

Qty/ Mod

Priority indicator

Repair options

Replacement Instruction

Remarks

Item No.

Part of Item No.

Ordering Code

Description

01 - 9498-396-00025 Circ breaker 400V/4A 3p 1 Y - -

02 - 9498-396-00023 CIRC.BREAKER 400V/8A 1P 6 Y - -

03 - 9498-396-00024 CIRC.BREAKER 400V/4A 1P 2 Y - -

04 - 9498-396-02406 EMERGENCY RELAIS PNOZX1 1 Y - -

05 - 9498-396-02410 Relay 24V DC 1 Y - -

06 - 9498-396-00258 Power supply 24V 1 Y - -
