P-0195-001 - 第227页
MODEL TCM-3000Z-2 0108-001 225 Key No. P AR T No. P AR T NAME Q’ ty REMARKS NOTE 11 - 1 7 1 630 087 8349 BOX 1 628FB-03V-021 2 630 004 6496 CONNECT OR 1 CN1 1 1 628FB-03D-130 3 630 004 6274 CONNECT OR 1 CN144 628FB-03D-1…
MODEL TCM-3000Z-2
0108-001
224
ELECTRICAL SECTION
Fig.11-17
I F 2
Previous/Next Work Process Interface-2
1
3
5
6
11
11
12
12
2
2
4
10-1
10
10
21
22
22
23
23
24
24
25
25
26
30-1
30-1
30
30
31
32
32
MODEL TCM-3000Z-2
0108-001
225
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
11-17
1 630 087 8349 BOX 1 628FB-03V-021
2 630 004 6496 CONNECTOR 1 CN111 628FB-03D-130
3 630 004 6274 CONNECTOR 1 CN144 628FB-03D-129
4 411 034 7208 SCR FLT 3X8 6 M3X8 FLT
5 630 054 8778 CONNECTOR 1 CN110 628FB-03D-103
6 411 042 0703 SCR PAN 3X8 4 M3X8 PAN
10 411 140 8007 SCR TRS 5X6 1 M5X6 TRS
10 -1 411 036 8609 SCR PAN+SW+W 5X12 1
11 630 060 4771 COVER 1 628FB-03V-023
12 411 140 8007 SCR TRS 5X6 2 M5X6 TRS
21 630 087 8332 BOX 1 628FB-03V-020
22 630 004 6496 CONNECTOR 1 CN113 628FB-03D-130
23 630 004 6274 CONNECTOR 1 CN114 628FB-03D-129
24 411 034 7208 SCR FLT 3X8 6 M3X8 FLT
25 630 054 8778 CONNECTOR 1 CN112 628FB-03D-103
26 411 042 0703 SCR PAN 3X8 4 M3X8 PAN
30 411 140 8007 SCR TRS 5X6 1 M5X6 TRS
30 -1 411 036 8609 SCR PAN+SW+W 5X12 1
31 630 060 4764 COVER 1 628FB-03V-022
32 411 140 8007 SCR TRS 5X6 2 M5X6 TRS
MODEL TCM-3000Z-2
0108-001
226
ELECTRICAL SECTION
Fig.11-18
Conveyor Driver Circuit L
A
13
1
82
82
83
83
81
81
12
11
2-2
2-2
2-1
2
4
3
6
.
58
58-1
58-1
.
8-1
8-1
8
.
5
9
9
26-1
26
25
25
25-1
29
28
27
41
42
See Fig.7-1
See Fig.7-1
Key No.2
A
B
B
13
12
11
10
101
101
100
100
103
102
13
12
11
21
24
23
22
24
23
22
98
99
52-2
52-2
92
92
92
92
91
72
72
73
74
74
59
59
71
53
55
59
59
21
21
52
52
52-1
52-1
51
97
96
Fig.11-18
TCM-3000Z-2
