WPW an SIPLACE 8 0 F3/F4 / WPC on SIPL ACE 80 F3/F4 Nac hrüstanleitung/R etrofitting Ins tructions Aus gabe 09/96 / 09/96 Edition Seite/ Page 10 von/ of 12 • Boot up t he Si test using t he Si test start di skette. • Not…
Nachrüstanleitung/Retrofitting Instructions WPW an SIPLACE 80F3/F4 / WPC on SIPLACE 80F3/F4
Ausgabe 09/96 / 09/96 Edition
Seite/Page 9 von/of 12
When wiring up the emergency stop circuit, check the delivery or product status of terminal panel Y904.
2.3.1.1 Delivery date before December 1994
•
On the left-hand terminal panel Y904 on terminal strip X211, from terminal 6 and
place the jumper on terminal 7 (see drawing).
Terminal panel Y904
X211
X5 X6 X7 X8 X9 X10 X10
2.3.1.2 Delivery date after January 1995
•
On the left-hand terminal panel Y904 on terminal strip X211, between terminal 5
and terminal 6.
2.3.1.3 Delivery date after January 1995 and product status of terminal panel Y904 PS 07.
•
On the left-hand terminal panel Y904 on terminal strip X211, check that there between
terminal 5 and terminal 6.
•
Then check terminal 6 and terminal 7. There must be between these terminals.
•
Plug cable F515-W1 on the wafflepack changer into plug X4sb on the machine controller.
•
Plug the cable on the short right-hand components table into plug X5sb on the machine controller.
•
Plug the cable on the left-hand components table into plug X6sb on the machine controller.
Wiring without WPC
Wiring with WPW
WPW an SIPLACE 80 F3/F4 / WPC on SIPLACE 80 F3/F4 Nachrüstanleitung/Retrofitting Instructions
Ausgabe 09/96 / 09/96 Edition
Seite/Page 10 von/of 12
•
Boot up the Sitest using the Sitest start diskette.
•
Note the positions of the two heads and the gantry.
At present, table 2 cannot be measured using the PCB camera or Sitest. The table positions must be
measured manually using the calibration segment.
•
Using the segment removal tool, remove segment no. 7 (top segment) from the revolver head.
•
Insert the calibration segment.
•
Position the calibration segment in the bottom position.
•
Place the iron-type gauge on track 61 on table 2.
•
Disable the X and Y axes and push the gantry over the ‘iron’.
•
Disable the Z axis and manually position the main axes until the tip of the calibration segment is above
the indent of the ‘iron’.
Always check the position of the Z axis when moving the gantry.
•
Read the X and Y positions on the axis testing device and note the values.
•
Then place the ‘iron’ on track 120 on table 2 and repeat the measuring procedure.
•
When the measuring procedure is complete, switch the axes on again in the following :
⇒ ⇒
•
Insert the DOS diskette and edit .
•
Convert the measured track positions from digits into
µ
m (measured value x 2.5).
•
Enter the calculated values into Real.ma (see extract from Real.ma).
Nachrüstanleitung/Retrofitting Instructions WPW an SIPLACE 80F3/F4 / WPC on SIPLACE 80F3/F4
Ausgabe 09/96 / 09/96 Edition
Seite/Page 11 von/of 12
\ SP1_Marke1_Pos_x_ist \ 426500,
\ SP1_Marke1_Pos_y_ist \ 491000,
\ SP1_Marke2_Pos_x_ist \ 0,
\ SP1_Marke2_Pos_y_ist \ 0,
\ SP2_Marke1_Pos_x_ist \
,
\ SP2_Marke1_Pos_y_ist \ ,
\ SP2_Marke2_Pos_x_ist \ ,
\ SP2_Marke2_Pos_y_ist \ ,
\ SP3_Marke1_Pos_x_ist \ 778670,
\ SP3_Marke1_Pos_y_ist \ 1304473,
\ SP3_Marke2_Pos_x_ist \ 178348,
\ SP3_Marke2_Pos_y_ist \ 1304505,
This is merely . The values shown in bold and italics must be measured.
•
Save the modified machine data and remove the DOS diskette.
•
Open the Siplace 80F configuration editor.
•
Delete the component set in conveying area 1.
•
Set the desired wafflepack changer carriages in conveying area 1. for the
WPC 80F/3 wafflepack changer.
•
Configure conveying area 2 ( .
• Set the settable component in conveying area 2.
Conveying area fiducial for WPC
Fixed position, may not be changed
Conveying area fiducial 80 F
half setting range tracks 61 to 120
Conveying area fiducial 80 S
Complete setting range
