Assembly instructions Head Reconfiguration SIPLACE D1 / D2
Edition 03/2007
49
2
Disassembly P&P Head 30 min
With standard stationary camera and nozzle
changer. No options such as additional vision
systems.
Assembly C&P 6/12 70 / 90 min
With mapping and without options such as nozzle
changer.
Assembly P&P Head 70 / 90 min
With mapping and with standard stationary
camera and nozzle changer. Without options
such as additional vision systems.
Assembly instructions Head Reconfiguration SIPLACE D1 / D2
Edition 03/2007
50
2.2 Parts, tools, and consumables required
– Angle Phillips screwdriver
2
2.3 Parts lists
2
2
2
Extension / with joint Item no. 03042635-
Extension / straight Item no. 03043440-
Torque screwdriver with setting scale Item no. 00376504-
Pressure gauge with measurement cable Item no. 00313523-
Mapping test board HF/X/D3 Item no. 00373952-
Calibration part version 3 Item no. 03010565-
Nozzle / NP-adjustment P&P Item no. 03008862-03
Calibration part version SST23 Item no. 03034148-
Assembly instructions:
Nozzle changer, C+P-Placement head_SIPLACE_D1-D2 Item no. 00195370-
Assembly instructions:
Flip-chip camera, digital 16x16 (SST 25) Item no. 00194554-
Assembly instructions: Head reconfiguration kits D1/D2 Item no. 00195427-
00119860- Reconfig.Kit C+P12 SIPLACE D1/2
03041228- 12 segm. Collect+Place head DLM3 cpl. 1 x
03014449- Component camera, C+P (type28) 18x18 digital 1 x
03052012- DIN912-M4 x 16-8.8 zinc-plated DSP 4 x
00313069- DIN912-M4 x 10-A2-70 4 x
00195427- Assembly instructions Head Reconfig. D1/D2 1 x
00119861- Reconfig.Kit C+P6 SIPLACE D1/2
03041229- 6 segm. Collect+Place head DLM3 cpl. 1 x
03018637- Component camera, C+P (type29) 27x27 digital 1 x
03052012- DIN912-M4 x 16-8.8 zinc-plated DSP 4 x
00313069- DIN912-M4 x 10-A2-70 4 x
00195427- Assembly instructions Head Reconfig. D1/D2 1 x
Assembly instructions Head Reconfiguration SIPLACE D1 / D2
Edition 03/2007
51
2
00119862- Extension kit P+P for D1 single
03033628- Pick+Place Module/THK 1 x
03048530- Conversion kit P+P Module / D1 1 x
03048203- Silencer Assembly Pick and Place module 1 x
03048209- Bracket for flat silencer compl. 1 x
03006296- Silencer exhaust air 1 x
03006295- Filter cap 1 x
03046875- Standoff i/o M3x30 1 x
00316904- DIN 125-A 3.2-140HV-A2 1 x
03045031- DIN912-M3 x 12-A2-70 1 x
03048237- Exhaust connecting tube 1 x
03045048- DIN912-M4 x 12-A2-70 2 x
03045425- Camera Screen P+P Module / D1 1 x
03050786- Connection Pick and Place module / D1 1 x
03050787- Tube 1, retraction stroke cylinder 1 x
03050789- Tube 1, vacuum generator 1 x
03010908- Plug QSC-8H 1 x
00337891- Plug QSC-6H 1 x
00353446- Servo amplifier SDS60/1.0Z1-01 1 x
00353447- Servo amplifier SDS60/0,5D1 1 x
03050647- Flat Ribbon cable gantry head distributor P+P 1 x
03054109- Additional Parts for P+P Modul 1 x
03041840- Pipette change machine p. P+P head 1 x
03047406- BE-dropping completely p. P+P head 1 x
03045087- DIN912-M6 x 12-A2-70 4 x
03039370- S/F Sandwich plate f. mark IC-sensor 1 x
03042491- Components camera, stat. P+P (type36) 32x32 digit. 1 x
03045095- DIN912-M6 x 35-A2-70 4 x
03052012- DIN912-M4 x 16-8.8 zinc-plated DSP 4 x
03005958- DIN 913 - M 6 x 50-ST 2 x
00195427- Assembly instructions Head Reconfig. D1/D2 1 x
