- - 11 . COV ER COMP ONE NT S (5) 3 4 5 3 7 3 8 3 8 3 5 3 9 4 0 3 6 4 2 4 1 1 1 1 2 1 0 9 8 7 6 5 3 1 3 1 3 1 2 9 2 6 2 6 2 4 2 0 1 7 1 7 1 6 1 5 1 5 1 3 4 1 1 1 2 1 4 1 4 A A 1 8 1 9 2 1 2 1 2 3 2 2 2 7 2 8 3 3 3 2 4 …
- -
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1 401-61791 COVER_CUL_350_ASM 1
2 401-58855 COVER_CUCR_BR (1)
3 401-47140 COVER_CUL_M (1)
4 SL-6061292-TN SCREW (1)
5 SL-6061292-TN SCREW (4)
6 SL-3061232-TN SCREW (4)
7 400-01464 STOPPER SUPPORT (1)
8 SL-6041092-TN SCREW (4)
9 400-49671 COVER CUSHION (1)
10 SM-4030601-SC SCREW M3 X 6 (1)
11 401-47221 STOPPER_NUT_PLATE (2)
12 400-93708 HOLE_PLUGS_HP11 (2)
13 HX-0009400-0D NYLON RIVET (10)
14 401-61792 COVER_CUR_350_ASM 1
15 401-58855 COVER_CUCR_BR (1)
16 401-47131 COVER_CUR_M (1)
17 SL-6061292-TN SCREW (1)
18 SL-3061232-TN SCREW (4)
19 400-01464 STOPPER SUPPORT (1)
20 SL-6041092-TN SCREW (4)
21 400-49671 COVER CUSHION (1)
22 SM-4030601-SC SCREW M3 X 6 (1)
23 401-47221 STOPPER_NUT_PLATE (2)
24 400-01453 SAFETY SWITCH BRACKET (1)
25 400-02254 COVER OPEN SW CABLE ASM (1)
26 SL-6042042-TN SCREW (2)
27 NM-3040520-SF FLANGE NUT M4 (4)
28 401-47577 CONNECTOR_BR (1)
29 SL-3061232-TN SCREW (4)
30 400-46586 REPEATER BRACKET (1)
31 SL-4040691-SC SCREW M4 L=6 (4)
32 SL-4030691-SC SCREW M3 L=6 (2)
33 HX-0029400-00 FIXED BASE (2)
34 SM-4040601-SC SCREW M4X0.7 L=6 (2)
35 401-46928 CB_BRACKET (1)
36 SL-3061232-TN SCREW (4)
37 SM-6061202-TN BOLT (4)
38 401-10219 FC_SUPPORT_Y_V2 (1)
39 SM-6060802-TN BOLT (2)
40 401-29009 SIGNAL TOWER CABLE ASM (1)
41 SL-6041092-TN SCREW (4)
42 SL-6061292-TN SCREW (4)
43 401-58866 COVER OPEN SW CABLE ASM (1)
44 HX-0055700-00 TIE MOUNT (1)
45 SL-3061232-TN SCREW (1)
46 E1310-727-000 C/O SWITCH BR (1)
47 SL-4021091-SC SCREW M2 L=10 (2)
48 401-61793 COVER_SUL(350)_ASM 1
49 CM-3009000-06 WATCH_YOUR_HANDS_LABEL(100) (1)
50 401-36850 MOTOR_COVER_R (1)
51 400-81751 B_COVER_SCREW (4)
52 SL-3061232-TN SCREW (5)
53 401-47144 COVER_SUL_R_M (1)
54 401-61652 COVER_SUL_F_350 (1)
55 SL-3061232-TN SCREW (8)
56 400-81751 B_COVER_SCREW (2)
57 401-47149 COVER_BR_B (1)
58 SL-6061292-TN SCREW (1)
59 401-47263 COVER_CUC(M)_ASM 1
60 401-47129 COVER_CUC_M (1)
61 SL-6061292-TN SCREW (8)
62 401-61794 COVER_SUR(350)_ASM 1
63 401-61625 COVER_SUR_F_350 (1)
64 400-81751 B_COVER_SCREW (4)
65 401-47148 COVER_SUR_R (1)
66 SL-3061232-TN SCREW (6)
67 401-47149 COVER_BR_B (1)
68 SL-6061292-TN SCREW (1)
69 CM-3009000-06 WATCH_YOUR_HANDS_LABEL(100) (1)
70 SL-3061232-TN SCREW (11)
71 401-47151 COVER_SUR_F_MOTOR_BR (1)
72 400-48078 IEEE1394 REPEATER BOARD 1
- -
11. COVER COMPONENTS (5)
3 4
5
3 7
3 8
3 8
3 5
3 9
4 0
3 6
4 2
4 1
1 1
1 2
1 0
9
8
7
6
5
3
1
3 1
3 1
2 9
2 6
2 6
2 4
2 0
1 7
1 7
1 6
1 5
1 5
1 3
4
1 1
1 2
1 4
1 4
A
A
1 8
1 9
2 1
2 1
2 3
2 2
2 7
2 8
3 3
3 2
4 3
4 5
4 4
1 2
2
4 5
2
2
2
4
3 0
2 5
3 0
2 5
- -
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1 401-47219 COVER_BOTTOM(M)_ASM 1
2 CM-3001000-04 DANGER LABEL (50) (4)
3 401-47105 COVER_SBL (1)
4 400-01510 COVER STUD RL (6)
5 SL-3061232-TN SCREW (6)
6 400-00550 FV BRACKET (1)
7 PV-0152120-00 FINGER VALVE (1)
8 PJ-0252000-03 PLUG (1)
9 SL-6032542-TN SCREW (2)
10 SL-6041092-TN SCREW (2)
11 HX-0070600-0A MOUNT BASE (2)
12 401-11970 LAMINATING_SEAL (1)
13 401-47107 COVER_SBR (1)
14 400-01510 COVER STUD RL (5)
15 SL-3061232-TN SCREW (5)
16 401-47082 COVER_FBL (1)
17 SL-3061232-TN SCREW (4)
18 400-01512 COVER STUD YF (2)
19 400-01510 COVER STUD RL (2)
20 401-47083 COVER_FBR (1)
21 SL-3061232-TN SCREW (4)
22 400-01512 COVER STUD YF (2)
23 400-01510 COVER STUD RL (2)
24 401-47084 COVER_RBL_M (1)
25 HM-0010100-10 FILTER (2)
26 SL-3061232-TN SCREW (4)
27 400-01512 COVER STUD YF (2)
28 400-01510 COVER STUD RL (2)
29 401-47106 COVER_RBR_M (1)
30 SL-4030891-SC SCREW M3X8 (4)
31 SL-3061232-TN SCREW (4)
32 400-01512 COVER STUD YF (2)
33 400-01510 COVER STUD RL (2)
34 400-93785 ASM_DRAIN_TANK (1)
35 400-16815 DRAIN TANK (1)
36 400-16814 DRAIN TANK STAY (1)
37 400-93721 DT_STAY_BR (1)
38 SL-6040892-TN BOLT (4)
39 PJ-3081000-01 UNION Y (1)
40 SL-6042592-TN SCREW (1)
41 PJ-3090400-03 REDUCER 4-10 (1)
42 BT-0400251-EA URETHANE TUBE BLUE 4X2.5 (0.16)
43 BT-1000651-EB POLYURETHANE TUBE (1.7)
44 E9635-455-000 REVISION SEAL (1)
45 168-70206 GRAVITY SEAL (2)
