MODEL GXH-1J 0501-001 176 162 151 171 . 170 171 . 170 171 . 170 172 172 175 174 173 153 152 168 165 193 190 192 161 160 155 190 154 156 159 158 167 166 157 190 190 190 181 167 163 164 172 175 174 173 175 174 173 架台下 XY サ…
MODEL GXH-1J
1012-003
175
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
BN-1
52 6301337180 BRACKET 1 829BN-010-052 211F9346
53 6301268453 BRACKET 1 829BN-020-053 211F8353
55 6300863857 BREAKER 1 Q200 829BN-010-175 4S230067
56 6300835441 HANDLE 1 829BN-010-176 226C0141
57
6301187839 FILTER,NOISE 1 Z01 829BN-010-177 4F300073
58 6301168821 FILTER,NOISE 1 Z02 829BN-010-178 4F300071
61 4080310004 VARISTOR R.A.V-781BXZ-4 1 F200 829BN-010-251 4V320010
62 6301231303 FUSE,SPECIAL 3 F201,F202,F203
829BN-010-252 4S300006
63
6301231310 FUSE HOLDER 3 829BN-010-253 4J200032
70
6300007749 BOLT,HEX-SCT 2 M5X10 221A0029
71
4111416705 WASHER SPR 5 2 SW5 221H0287
72
4111414107 WASHER V 5X10X1 2 FW5 221H0318
73
4111131400 SCR PAN 4X6 10 M4X6 PAN 221E0509
74 4110423001 SCR PAN 4X10 1 M4X10 PAN 221E0500
75 4111132407 SCR PAN 4X30 2 M4X30 PAN 221E0570
76 4110081706 WASHER SPR 4 13 SW4 F 221H0283
77
4111192104 WASHER V 4X9X0.8 13 FW4 F 221H0314
MODEL GXH-1J
0501-001
176
162
151
171
.
170
171
.
170
171
.
170
172
172
175
174
173
153
152
168
165
193
190
192
161
160
155
190
154
156
159
158
167
166
157
190
190
190
181
167
163
164
172
175
174
173
175
174
173
架台下
XY
サーボ電源部
B UNDERFRAME XY SERVO
POWER SUPPLY SECTION B
Fig. BN-2
200V
電源２
200V Power Supply 2
MODEL GXH-1J
1012-003
177
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
BN-2
151 6301337159 BRACKET 1 829BN-010-051 211F9343
152 6301340029 EM-CONTACTOR 1 -K33 829BN-010-152 4S2101
17
153 6301241586 COMP,CR 1 829BN-010-153 4F400025
154
6300634457 RELAY 1 -K48 829BN-010-154 4S200085
155 6300454260 SOCKET 1 829BN-010-155 4J120079
156
6300001020 BRACKET,WIRING 1 829BN-010-156 23N10001
157
6301340043 CIRCUIT PROTECTOR 1 -Q221 829BN-010-157 4S250322
158 6301340074 ACCESSORY,WIRING 1 829BN-010-158 23N30652
159
6301340081 ACCESSORY,WIRING 1 829BN-010-159 23N30653
160
6301340005 RAIL,WIRING 1 829BN-010-160 23N00101
161
6300911725 ACCESSORY,WIRING 1 829BN-010-161 23N30499
162
6301354026 TERMINAL 1 829BN-010-162 4J320229
163
6301340036 CIRCUIT PROTECTOR 1 -Q205 829BN-010-163 4S250321
164 6301340159 BREAKER 1 -Q206 829BN-010-164 4S230094
165 6301340166 EM-CONTACTOR 1 -K29 829BN-010-165 4S2101
18
166 6301340050 CIRCUIT PROTECTOR 2 -Q222,-Q223
829BN-010-166 4S250323
167
6301340067 ACCESSORY,WIRING 4 829BN-010-167 23N30651
168
6300769166 COMP,CR 1 829BN-010-168 4F400008
170
6300007763 BOLT,HEX-SCT 4 M5X16 221A0031
171
4111416705 WASHER SPR 5 4 SW5 221H0287
172
6300010220 WASHER 4 BW5 221H0005
173
4111131400 SCR PAN 4X6 8 M4X6 PAN 221E0509
174 4110081706 WASHER SPR 4 8 SW4 F 221H0283
175
4111192104 WASHER V 4X9X0.8 8 FW4 F 221H0314
181
6301340012 BREAKER 1 -Q201 829BN-010-151 4S230093
190 6300911749 BRACKET,WIRING 6 829BN-010-170 23N10027
192
6301268712 TERMINAL 1 829BN-010-172 4J320186
193
6301339993 ACCESSORY,WIRING 1 829BN-010-173 23N30650
