MODEL GXH-1J 1012-003 27 Key No. P AR T No. P AR T NAME Q’ty REMARKS New Code NOTE C-5 402 6300805369 SENSOR,PHOTO 3 -B2101,-B2102,-B2202 829C--010-102 23G10059 403 6301239842 ENCODER(APE391M) 2 829C--010-103 23G40021 40…
MODEL GXH-1J
0501-001
26
ビーム部
BEAM SECTION
Fig. C-5 X
軸部
B X Axis Section B
469
404
413
415
445
468
414
403
437
445
409
444
408
406
481
471
466
445
444
407
405
414
468
415
403
404
413
469
461
.
476
.
486
451
.
472
.
482
445
460
.
475
.
485
456
.
474
.
484
460
.
475
.
485
451
.
472
.
482
461
.
476
.
486
456
.
474
.
484
460
.
475
.
485
455
.
474
.
484
455
.
474
.
484
460
.
475
.
485
456
.
474
.
484
460
.
475
.
485
455
.
474
.
484
466
466
481
481
471
471
402
402
432
432
427
427
430
430
431
428
458
.
475
.
485
457
.
474
.
484
461
.
476
.
486
459
461
.
476
.
486
452
.
473
.
483
458
.
475
.
485
459
431
467
467
434
422
421
454
452
.
473
.
483
433
425
467
424
429
452
.
473
.
483
425
453
.
473
.
483
457
.
474
.
484
454
410
402
MODEL GXH-1J
1012-003
27
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
C-5
402 6300805369 SENSOR,PHOTO 3 -B2101,-B2102,-B2202
829C--010-102 23G10059
403
6301239842 ENCODER(APE391M) 2 829C--010-103 23G40021
404
6301239859 MECH PARTS(APE PLATE) 2 829C--010-104 226J1871
405
6301254760 PLATE 1 829C--010-105 211D9456
406 6301254777 PLATE 1 829C--010-106 211D9457
407 6301267609 BRACKET 1 829C--010-107 211F8345
408 6301267616 BRACKET 1 829C--010-108 211F8346
409 6301233444 PLATE 1 829C--010-109 211D9263
410 6301233451 BRACKET 1 829C--010-110 21
1F7960
413 6301267623 BRACKET 2 829C--010-113 21
1F8347
414 6301234083 BRACKET 2 829C--010-114 21
1F7978
415 6301234090 BRACKET 2 829C--010-115 21
1F7979
421 6301239293 GUIDE,LINEAR 1 829C--010-201 222L0674
422
6301275024 MOTOR,AC-SERVO 4 829C--010-202 4M150209
424
6301239804 ENCODER(LIDA407 TAPESET) 1 829C--010-204 23G40019
425
6301239828 MECH PARTS(LIDA407 HOLDE) 2 829C--010-205 226J1869
427
6301240411 BOLT 2 829C--010-207 221E0287
428
6301254784 FRAME 1 829C--010-208 210B3600
429
6301233581 PLATE 1 829C--010-209 211D9268
430 6301233659 BLOCK 2 829C--010-210 211G3339
431 6301233680 ROD 2 829C--010-211 216C0697
432 6301233604 BRACKET 2 829C--010-212 211F7962
433 6301254807 BRACKET 1 829C--010-213 211F8180
434 6301243511 COVER 4 829C--010-214 211A8501
437 6301263533 PIN,LOCATE 1 829C--010-117 216E1478
444 6301275017 MOTOR,AC-SERVO 2 -M22,-M23 829C--010-004 4M150208
445 6301239798 ENCODER(LIDA48 HEAD) 2 -U22,-U23 829C--010-005 23G40018
451 6300007527 BOLT,HEX-SCT 4 M3X10 221A0007
452
6300007626 BOLT,HEX-SCT 8 M4X10 221A0017
453
6300007633 BOLT,HEX-SCT 6 M4X12 221A0018
454
6300007640 BOLT,HEX-SCT 30 M4X14 221A0019
455
6300007756 BOLT,HEX-SCT 6 M5X12 221A0030
456
6300007763 BOLT,HEX-SCT 28 M5X16 221A0031
457
6300007770 BOLT,HEX-SCT 56 M5X20 221A0032
458
6300007923 BOLT,HEX-SCT 2 M6X35 221A0047
459
6300007930 BOLT,HEX-SCT 2 M6X40 221A0048
460
6300007886 BOLT,HEX-SCT 26 M6X16 221A0043
461
6300008166 BOLT,HEX-SCT 12 M10X50 221A0071
466
4111406300 SCR PAN 2X8 6 M2X8 PAN 221E0484
467 4110505004 SCR TRS 3X6 18 M3X6 TRS 221E0529
468 4111139109 SCR TRS 5X10 4 M5X10 TRS 221E0534
469 4110022600 SCR FLT 3X6 4 M3X6 FLT
221D0216
471 4111412608 WASHER SPR 2 6 SW2 221H0277
472
4111412806 WASHER SPR 3 4 SW3 221H0281
473
4111412905 WASHER SPR 4 14 SW4 221H0284
474
4111416705 WASHER SPR 5 90 SW5 221H0287
475
4111413001 WASHER SPR 6 28 SW6 221H0289
476
4111413209 WASHER SPR 10 12 SW10 221H0293
481
4111415500 WASHER F 2X4.3X0.3 6 FWS2 221H0334
MODEL GXH-1J
1012-003
28
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
C-5
482 4111413902 WASHER V 3X7X0.5 4 FW3 221H0312
483 4111414008 WASHER V 4X9X0.8 14 FW4 221H0315
484
4111414107 WASHER V 5X10X1 90 FW5 221H0318
485
4111414305 WASHER V 6X12.5X1.6 28 FW6 221H0320
486
4111414701 WASHER V 10X21X2 12 FW10 221H0325
