P-250-003e - 第39页
MEMO
MODEL GXH-1J
1012-003
36
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
C-7
663 4110420703 SCR PAN 3X8 11 M3X8 PAN 221E0499
665 4110505004 SCR TRS 3X6 14 M3X6 TRS 221E0497
666 4110511708 SCR TRS 4X6 4 M4X6 TRS 221E0532
667 4111410307 NUT HEX 4 4 M4 221F0082
671
4111412608 WASHER SPR 2 2 SW2 221H0277
672
4110864408 WASHER SPR 3 7 SW3 F 221H0280
673
4111412806 WASHER SPR 3 4 SW3 221H0281
675
4111412905 WASHER SPR 4 54 SW4 221H0284
676
4111416705 WASHER SPR 5 16 SW5 221H0287
681
4111416903 WASHER V 2X5X0.3 2 FW2 221H0308
682
4111191909 WASHER V 3X7X0.5 7 FW3 F 221H0311
683 4111413902 WASHER V 3X7X0.5 4 FW3 221H0312
684
4111192104 WASHER V 4X9X0.8 4 FW4 F 221H0314
685
4111414008 WASHER V 4X9X0.8 52 FW4 221H0315
686
4111414107 WASHER V 5X10X1 16 FW5 221H0318
MEMO
MODEL GXH-1J
0909-002
38
ビーム部
BEAM SECTION
Fig. C-8
ケーブル
Cable
See Fig.C-6
Key No.535
775
774
773
See Fig.C-7
Key No.635
775
774
773
753
761
.
762
.
763
772
771
772
771
761
.
762
.
763
754
