The conveyor belts are driven by DC motors. Each placement area has a lifting table for clamping
the PCBs. The width of the PCB conveyor can be adjusted either 1
– via the menu or
– using the line computer
1
1.18.2 Technical data - single conveyor
1
1.18.3 Technical data - dual conveyor
1
Fixed conveyor edge Right (standard), left (optional)
PCB format 50 mm x 50 mm to 368 mm x 460 mm
2" x 2" to 14.5 " x 18 "
PCB thickness 0.3 mm to 4.5 mm
Maximum PCB curvature On top: 4.5 mm - PCB thickness
On bottom: 0.3 mm + PCB thickness
Clearance underneath PCB Standard: 25 mm
Option: Up to 40 mm
PCB conveyor height 830 ± 15 mm (standard)
900 ± 15 mm (option)
930 ± 15 mm (option
950 ± 15 mm (SMEMA option)
Type of interface Siemens (standard)
SMEMA (option)
Clear guide edge of component 3 mm
PCB changeover time 2.5 s
Ink spot recognition Possible
Automatic width adjustment Possible
Fixed conveyor edge Right (standard), left (optional)
PCB format 50 mm x 50 mm to 368 mm x 216 mm
2" x 2" to 14.5" x 8.5"
PCB thickness 0.3 mm to 4.5 mm
Maximum PCB curvature On top: 4.5 mm - PCB thickness
On bottom: 0.3 mm + PCB thickness
Clearance underneath PCB Standard: 25 mm
Option: Up to 40 mm
User Manual SIPLACE HS-50 1 Introduction
Software Version SR.50x.xx 01/2006 US Edition 1.18 Overview of the modules - PCB conveyor
43
1
1
PCB conveyor height 830 ± 15 mm (standard)
900 ± 15 mm (option)
930 ± 15 mm (option)
950 ± 15 mm (SMEMA option)
Type of interface Siemens (standard)
SMEMA (option)
Clear guide edge of component 3 mm
PCB changeover time 2.5 s
Type of transportation asychronous
Components on each conveyor same
PCB width on each conveyor same
Ink spot recognition possible
Automatic width adjustment possible
