VER.01E - 2/2 - ● For M3, M3S, M3-2 single conveyors Remark 1 Drg./Code no. Rating Recommended qty. Use Quantity used per unit PH0078* Brush 2 Removes dust from the surface and prevents static 2 H55037 Stopper bolt 4 4 ●…
VER.01E
- 1/2 -
Consumable parts are parts that deteriorate during the course of operating the machine and these parts must be paid for even if the machine is still under warranty.
The displayed part names below and the parts listed in the following tables are all consumable parts.
O-rings, Filters, Nozzles, Batteries, Fuses, Conveyor belts, Sheets, Rubber sheets
● For NXT 8M, 4M, 2M-2 bases and external unit Remark 1
Drg./Code no. Rating
Recommended qty.
Use
Quantity used per unit
H5448D Vacuum pump DOP-300SA maintenance kit 1 For DOP-300SA 1
Remark 1
Drg./Code no. Rating
Recommended qty.
Use
Quantity used per unit
H5448E Vacuum pump DOP-420SA maintenance kit 1 For DOP-420SA 1
● For M3, M3S, M3-2 modules (excluding conveyors)
Remark 1
Drg./Code no. Rating
Recommended qty.
Use
Quantity used per module
PG0097* Packing 1 For connecting positive air pressure 1
PH0099* Packing 1 For connecting positive air pressure 1
For unit serial number 003581 and higher
PG0131* Packing 1 For connecting positive air pressure 1 For unit serial number up to 003580
PT0075*
Movable cutter
3 Waste tape processing unit(for typeA) 3 For unit code TCM3A
PM0502* Stationary cutter 1 Waste tape processing unit(for typeA) 1 For unit code TCM3A
PM0KBN*
Movable cutter
3 New waste tape processing unit(for typeB) 3 For unit code TCM3B
2MGLPK00490*
Stationary cutter
1 New waste tape processing unit(for typeB) 1 For unit code TCM3B
● For M6, M6S, M6-2 modules (excluding conveyors)
Remark 1
Drg./Code no. Rating
Recommended qty.
Use
Quantity used per module
PG0097* Packing 1 For connecting positive air pressure 1
PH0099* Packing 1 For connecting positive air pressure 1
For unit serial number 003581 and higher
PG0131* Packing 1 For connecting positive air pressure 1 For unit serial number up to 003580
PM02RX* Movable cutter 5 Waste tape processing unit(for typeA) 5 For unit code TCM6A
PM0350*
Stationary cutter
1 Waste tape processing unit(for typeA) 1 For unit code TCM6A
PM0KBA*
Movable cutter
5 New waste tape processing unit(for typeB) 5 For unit code TCM6B
2MGKPL00140*
Stationary cutter
1 New waste tape processing unit(for typeB) 1 For unit code TCM6B
● For single nozzle head
Remark 1
Drg./Code no. Rating
Recommended qty.
Use
Quantity used per head
PH0027* Clamp pin 10 For preventing nozzle drops 2
● For 2 nozzle head
Remark 1
Drg./Code no. Rating
Recommended qty.
Use
Quantity used per head
PH0027* Clamp pin 20 For preventing nozzle drops 4
Part name
Consumable parts
Part name
Part name
Part name
Part name
Part name
● For NXT 4M-2 bases
334
PTS-NXT2-06JE Vol.2
VER.01E
- 2/2 -
● For M3, M3S, M3-2 single conveyors
Remark 1
Drg./Code no. Rating
Recommended qty.
Use
Quantity used per unit
PH0078*
Brush
2 Removes dust from the surface and prevents static 2
H55037
Stopper bolt
4 4
● For M6, M6S, M6-2 single conveyors
Remark 1
Drg./Code no. Rating
Recommended qty.
Use
Quantity used per unit
PH0079*
Brush
2 Removes dust from the surface and prevents static 2
H55037
Stopper bolt
4 4
● For M3, M3S, M3-2 double conveyors
Remark 1
Drg./Code no. Rating
Recommended qty.
Use
Quantity used per unit
PH0078*
Brush
4 Removes dust from the surface and prevents static 4
H55037
Stopper bolt
8 8
● For M6, M6S, M6-2 double conveyors
Remark 1
Drg./Code no. Rating
Recommended qty.
Use
Quantity used per unit
PH0079*
Brush
4 Removes dust from the surface and prevents static 4
H55037
Stopper bolt
8 8
● For tray unit-L
Remark 1
Drg./Code no. Rating
Recommended qty.
Use
Quantity used per unit
PJ1087*
Pad
1 For empty tray remover 1 Option
● Jig parts for hybrid calibration
Remark 1
Drg./Code no. Rating
Recommended qty.
Use
Quantity used per unit
GGAJ04**
Gauge
1 Hybrid calibration part 1
● Glass part
Remark 1
Drg./Code no. Rating
Recommended qty.
Use
Quantity used per unit
AA7SA**
Chip
1 Hybrid calibration part 1
Part name
Part name
Part name
Part name
Part name
Part name
Part name
335
PTS-NXT2-06JE Vol.2
VER.01J
- 1/2 -
消耗品
消耗品とは装置の動作に伴って消耗する部品をいい、装置の保障期間内であっても有料となります。
下記に示す品名及び、表中の部品は全て消耗品扱いとなります
・Oﾘﾝｸﾞ ・ﾌｨﾙﾀｰ ・ﾉｽﾞﾙ ・ﾊﾞｯﾃﾘｰ ・ﾋｭｰｽﾞ ・ｺﾝﾍﾞｱﾍﾞﾙﾄ ・ｼｰﾄ ・ｼｰﾄｺﾞﾑ
●NXT 8Mベース用 4Mベース用 2MⅡベース用 外付け用 備考1
図番/ｺｰﾄﾞNo. 規格 推奨個数 用途 使用個数/ﾓｼﾞｭｰﾙ
H5448D ﾎﾟﾝﾌﾟ ﾊﾞｷｭｰﾑ DOP-300SAﾒﾝﾃﾅﾝｽｷｯﾄ 1 DOP-300SA用 1
●NXT 4MⅡベース用 備考1
図番/ｺｰﾄﾞNo. 規格 推奨個数 用途 使用個数/ﾓｼﾞｭｰﾙ
H5448E ﾎﾟﾝﾌﾟ ﾊﾞｷｭｰﾑ DOP-420SAﾒﾝﾃﾅﾝｽｷｯﾄ 1 DOP-420SA用 1
●M3/M3S M3IIモジュール用（コンベアを除く）
備考1
図番/ｺｰﾄﾞNo. 規格 推奨個数 用途 使用個数/ﾓｼﾞｭｰﾙ
PG0097* ﾊﾟｯｷﾝ 1 正負圧エア接続用 1
PH0099* ﾊﾟｯｷﾝ 1 正負圧エア接続用 1 ﾕﾆｯﾄｼﾘｱﾙNo.003581～用
PG0131* ﾊﾟｯｷﾝ 1 正負圧エア接続用 1 ﾕﾆｯﾄｼﾘｱﾙNo.～003580用
PT0075*
ｶｯﾀ ｶﾄﾞｳ
3 残ﾃｰﾌﾟ処理ﾕﾆｯﾄ(Aタイプ用) 3 ユニット記号TCM3A用
PM0502* ｶｯﾀ ｺﾃｲ 1 残ﾃｰﾌﾟ処理ﾕﾆｯﾄ(Aタイプ用) 1 ユニット記号TCM3A用
PM0KBN*
ｶｯﾀ ｶﾄﾞｳ
3 新残ﾃｰﾌﾟ処理ﾕﾆｯﾄ(Bタイプ用) 3 ユニット記号TCM3B用
2MGLPK00490*
ｶｯﾀ ｺﾃｲ
1 新残ﾃｰﾌﾟ処理ﾕﾆｯﾄ(Bタイプ用) 1 ユニット記号TCM3B用
●M6/M6S M6IIモジュール用（コンベアを除く）
備考1
図番/ｺｰﾄﾞNo. 規格 推奨個数 用途 使用個数/ﾓｼﾞｭｰﾙ
PG0097* ﾊﾟｯｷﾝ 1 正負圧エア接続用 1
PH0099* ﾊﾟｯｷﾝ 1 正負圧エア接続用 1 ﾕﾆｯﾄｼﾘｱﾙNo.003581～用
PG0131* ﾊﾟｯｷﾝ 1 正負圧エア接続用 1 ﾕﾆｯﾄｼﾘｱﾙNo.～003580用
PM02RX* ｶｯﾀ ｶﾄﾞｳ 5 残ﾃｰﾌﾟ処理ﾕﾆｯﾄ(Aタイプ用) 5 ユニット記号TCM6A用
PM0350*
ｶｯﾀ ｺﾃｲ
1 残ﾃｰﾌﾟ処理ﾕﾆｯﾄ(Aタイプ用) 1 ユニット記号TCM6A用
PM0KBA*
ｶｯﾀ ｶﾄﾞｳ
5 新残ﾃｰﾌﾟ処理ﾕﾆｯﾄ(Bタイプ用) 5 ユニット記号TCM6B用
2MGKPL00140*
ｶｯﾀ ｺﾃｲ
1 新残ﾃｰﾌﾟ処理ﾕﾆｯﾄ(Bタイプ用) 1 ユニット記号TCM6B用
●1ﾉｽﾞﾙﾍｯﾄﾞ用
備考1
図番/ｺｰﾄﾞNo. 規格 推奨個数 用途 使用個数/ﾍｯﾄﾞ
PH0027* ﾋﾟﾝ ｸﾗﾝﾌﾟ 10 ﾉｽﾞﾙ落下防止用 2
●2ﾉｽﾞﾙﾍｯﾄﾞ用
備考1
図番/ｺｰﾄﾞNo. 規格 推奨個数 用途 使用個数/ﾍｯﾄﾞ
PH0027* ﾋﾟﾝ ｸﾗﾝﾌﾟ 20 ﾉｽﾞﾙ落下防止用 4
品名
品名
品名
品名
品名
品名
336
PTS-NXT2-06JE Vol.2
