4022 591 96082 User Re ference Manual 02.02 FCM Multiflex 5-69 MIS Er ro r co de Subsystem Error descripti on 54284 G PM M U P down during movement 54285 Process error l ost before align 54286 Servo ampli fiers disabled …
MIS
User Reference Manual 4022 591 96082
5-68 FCM Multiflex 02.02
Error code Subsystem Error description
53851 BVM Temperature Pin measurement failed
53853 X position out of range
53854 Y position out of range
53857 Servo tracking error on X front
53858 Servo tracking error on X rear
53859 Servo tracking error on Y
53860 Servo power failure
53863 Servo amplifiers disabled
53864 Movement while no homing was done
53865 Right stop X axis not found
53866 Rear stop Y axis not found
53869 Index pulse X front not found
53870 Index pulse X rear not found
53871 Index pulse Y axis not found
53873 Left stop X axis not found
53874 Front stop Y axis not found
53877 X axis obstructed
53878 Y axis obstructed
53881 Communication error on X front
53882 Communication error on X rear
53883 Communication error on Y servo
53884 DC Firmware RS232 receive error
53885 Timeout on communication X front
53886 Timeout on communication X rear
53887 Timeout on communication Y servo
53888 DC Firmware RS232 transmit error
53916 DC not configured for DFA
53920 DC not configured for BMS
54272 GPM Miss SMD after pick
54273 Retain SMD after place
54274 Lost SMD before place
54275 Vacuum wrong, Cal. limit surpassed
54276 Requested X position out of range
54277 Requested Y position out of range
54278 Requested Phi pos. out of range
54279 Power dip during MUP down
54280 Servo tracking error on X axis
54281 Servo tracking error on Y axis
54282 Servo tracking error on Phi axis
54283 Servo power failure
4022 591 96082 User Reference Manual
02.02 FCM Multiflex 5-69
MIS
Error code Subsystem Error description
54284 GPM MUP down during movement
54285 Process error lost before align
54286 Servo amplifiers disabled
54287 Movement while no homing was done
54288 Right stop X axis not found
54289 Rear stop Y axis not found
54290 Zero EPD not found on Phi axis
54291 Pusher down during movement
54292 Index pulse X axis not found
54293 Index pulse Y axis not found
54294 Index pulse Phi axis not found
54295 PPU EEPROM Communication error
54296 Left stop X axis not found
54297 Front stop Y axis not found
54298 Home error Phi area is too large
54300 X axis obstructed
54301 Y axis obstructed
54302 Home error Phi area is too small
54304 Communication error on X servo
54305 Communication error on Y servo
54306 Communication error on Phi servo
54307 RS232 laser align link receive err
54308 Timeout on communication X servo
54309 Timeout on communication Y servo
54310 Timeout on communication Phi servo
54311 RS232 laser align link transmit er
54313 Flash EPROM table full
54314 Susp placement after machine error
54315 Flash EPROM zero offsets lost
54316 Timeout Smart Feeder
54317 Requested X position out of range
54318 Requested Y position out of range
54320 The MUP has become too slow
54321 The MUP has become too fast
54324 No PPU installed or wrong type
54325 PPU calibration checksum error
54328 X pos out of range due offset comp
54329 Y pos out of range due offset comp
54330 X pos out of range due MUP comp
54331 Y pos out of range due MUP comp
MIS
User Reference Manual 4022 591 96082
5-70 FCM Multiflex 02.02
Error code Subsystem Error description
54332 GPM X pos out of range due XY comp
54333 Y pos out of range due XY comp
54334 X pos out of rnage due feeder corr
54335 Y pos out of rnage due feeder corr
54336 Misalign SMD, X pick off too large
54337 Misalign SMD, Y pick off too large
54338 Misalign SMD,Phi pick off too larg
54341 SMD lost due to power down
54342 Align ID not present (system err)
55040 WVM Camera Cal. Tool not mounted
55041 Can not find vision marker 1
55042 Can not find vision marker 2
55043 Quality vision marker 1 too low
55044 Quality vision marker 2 too low
55045 Bad shape vision marker 1
55046 Bad shape vision marker 2
55047 No video
55048 Vision unit set to wrong videomode
55049 Light level too low
55050 SBIP BBRAM checksum error
55051 SBIP Config. info file missing
55052 Camera cal. data not available
55053 Auto-test not successful
55054 Crossbar on auto-test not ok
55055 Video memory not ok
55056 Relative cal. object not detected
55057 Absolute cal. object not detected
55058 Camera cal. object not detected
55059 Bad quality rel. cal. obj. detect
55060 Bad quality abs. cal. obj. detect
55061 Bad quality camera cal. object
55062 SBIP Parameter setting incorrect
55090 X Offset too large
55091 Y Offset too large
55092 Phi Offset too large
55093 Misalign SMD not measurable
55094 Misalign SMD auto lightlevel failed
55095 Misalign SMD not recognized
55097 Misalign SMD lead pitch error
55098 Misalign SMD coplanarity error
