4022 591 96082 User Re ference Manual 02.02 FCM Multiflex 5-67 MIS Er ro r co de Subsystem Error descripti on 44103 LAS Undefined Error (LAS-B8) 44104 Laser sensor not connect ed 44105 Laser meas ur ement error 44106 Las…
MIS
User Reference Manual 4022 591 96082
5-66 FCM Multiflex 02.02
Error code Subsystem Error description
44062 LAS Home err Phi area too large
44064 Communication error on X servo
44065 Communication error on Y servo
44066 Communication err on Phi servo
44067 RS422 laser align link rcv. error
44068 Timeout communication X servo
44069 Timeout communication Y servo
44070 Timeout Communication Phi serv
44071 LAS RS422 laser align link xmit error
44072 Flash EPROM write protected
44073 Flash EPROM table full
44074 Suspected placement, check SMD
44075 Flash EPROM zero offsets lost
44076 Timeout Smart Feeder
44077 X pos out of range, offset/FFA
44078 Y pos out of range, offset/FFA
44079 misalign SMD
44080 MUP too slow
44081 MUP too fast
44082 PPU changed, associate?
44083 PPU changed, associate!
44084 Chuck not conform Action spec
44085 PPU cal. checksum error
44086 Laser sensor exchanged
44087 Data eeprom LA sensor corrupted
44088 X pos out of range due to LA comp.
44089 Y pos out of range due to LA comp.
44090 X pos out of range due to MUP comp
44091 Y pos out of range due to MUP comp
44092 X pos out of range due to XY comp.
44093 Y pos out of range due to XY comp.
44094 X pos out of range due to Pick off
44095 Y pos out of range due to Pick off
44096 X pick offset too large
44097 Y pick offset too large
44098 Phi pick offset too large
44099 SMD length not within req. limits
44100 SMD width not within req. limits
44101 SMD lost due to power down
44102 Align id not present (sys. error)
4022 591 96082 User Reference Manual
02.02 FCM Multiflex 5-67
MIS
Error code Subsystem Error description
44103 LAS Undefined Error (LAS-B8)
44104 Laser sensor not connected
44105 Laser measurement error
44106 Laser hardware error
44107 Laser protocol error
44108 Laser beam obstructed error
44109 Laser dirty error
44110 Laser checksum error on received data
44111 Laser time-out error on received data
44112 Laser parameter data damaged error
44113 Laser software error occured
44114 MUP did not move error
44115 LAS MUP has wrong notch size error
53307 BVM Measureline inconsistency
53790 BI Board id. configuration failed
53791 Barcode read failed
53792 Barcode read notification failed
53793 Board id. version not correct
53794 Param. save in param. file wrong
53795 Wrong configuration parameter
53796 Rate test startup failed
53797 Mailbox create failed
53798 Human interface not synchronized
53799 Human interface not started
53800 Close down failed
53801 Wrong AM id.
53802 No configuration entry found
53803 Time out
53804 Invalid response
53805 First board error
53806 Barcode not in range
53807 Board count failed
53808 No read was requested
53809 Barcode not matched in exist. order
53810 Validation of barcode not correct
53811 Barcode length not correct
53812 Illegal order handle
53813 Cannot start idle order
53849 BVM Fiducial/Badmark measurement failed
53850 DC Firmware SBIP timeout
MIS
User Reference Manual 4022 591 96082
5-68 FCM Multiflex 02.02
Error code Subsystem Error description
53851 BVM Temperature Pin measurement failed
53853 X position out of range
53854 Y position out of range
53857 Servo tracking error on X front
53858 Servo tracking error on X rear
53859 Servo tracking error on Y
53860 Servo power failure
53863 Servo amplifiers disabled
53864 Movement while no homing was done
53865 Right stop X axis not found
53866 Rear stop Y axis not found
53869 Index pulse X front not found
53870 Index pulse X rear not found
53871 Index pulse Y axis not found
53873 Left stop X axis not found
53874 Front stop Y axis not found
53877 X axis obstructed
53878 Y axis obstructed
53881 Communication error on X front
53882 Communication error on X rear
53883 Communication error on Y servo
53884 DC Firmware RS232 receive error
53885 Timeout on communication X front
53886 Timeout on communication X rear
53887 Timeout on communication Y servo
53888 DC Firmware RS232 transmit error
53916 DC not configured for DFA
53920 DC not configured for BMS
54272 GPM Miss SMD after pick
54273 Retain SMD after place
54274 Lost SMD before place
54275 Vacuum wrong, Cal. limit surpassed
54276 Requested X position out of range
54277 Requested Y position out of range
54278 Requested Phi pos. out of range
54279 Power dip during MUP down
54280 Servo tracking error on X axis
54281 Servo tracking error on Y axis
54282 Servo tracking error on Phi axis
54283 Servo power failure
