Mount Program
User Reference Manual 4022 591 96082
4-8 FCM Multiflex 02.02
Product Aspects (continued)
AS PRODUCT
COMMENT
COMMENT Product actions
COMMENT
PROD_ID ctc146
SIDE T
FAMILY ctc146
BOARD_ROTATION 0
BOARD_DIM 291.0 201.2 3.0
STOPPER -161.000
BOARD_PITCH 300.000
NUMBER_OF_BOARDS 8
CYCLE_TIME 25.567
4022 591 96082 User Reference Manual
02.02 FCM Multiflex 4-9
Mount Program
4.2.2.5 BOARD_DIM
syntax: product_len + product_width + product_thickness
NOTE: Dimensions in respectivily CAD X-, Y- and Z-direction
■ product_len
type: real
range: 50.000 .. 460.000 mm
description: Product (board) dimension in cad X direction. The maximum is such that
after applying the product rotation, the dimension in the FCM’s X-
direction is 460 mm or smaller, and the dimension in FCM’s Y-direction is
406 mm or smaller.
■ product_width
type: real
range: 50.000 .. 460.000 mm
description: Product (board) dimension in cad Y direction. The maximum is such that
after applying the product rotation, the dimension in FCM X direction is
460 mm or smaller and the dimension in FCM Y direction is 406 mm or
smaller.
■ product_thickness
type: real
range: £ 3.000 mm
description: Product (board) thickness.
4.2.2.6 STOPPER
syntax: runin_stopper_pos + [ runout_stopper_pos ]
NOTE: The run out stopper is not always needed. In that case the position must be omitted.
■ runin_stopper_pos
type: real
range: -480.000 .. -41.000 (mm)
description: Specifies the runin stopper position relative to the machine origin.
■ runout_stopper_pos
type: real
unit: mm
range: 1959.000 .. 2500.000
description: Specifies the runout stopper position relative to the machine origin.
4.2.2.7 BOARD_PITCH
syntax: board_pitch
type: real
range: 0.000 .. 480.000
description: Describes the distance between two consecutive PCB carriers, measured
from the same reference point (e.g. the first centring pin).
Mount Program
User Reference Manual 4022 591 96082
4-10 FCM Multiflex 02.02
Product Aspects (continued)
AS PRODUCT
COMMENT
COMMENT Product actions
COMMENT
PROD_ID ctc146
SIDE T
FAMILY ctc146
BOARD_ROTATION 0
BOARD_DIM 291.0 201.2 3.0
STOPPER -161.000
BOARD_PITCH 300.000
NUMBER_OF_BOARDS 8
CYCLE_TIME 25.567
