Mount Program
User Reference Manual 4022 591 96082
4-30 FCM Multiflex 02.02
Placement Module Activities (continued)
AS LAS/WVM 3
COMMENT
COMMENT Placement module actions for position 3
COMMENT
COMMENT PPU_id /nozzle_id /clow/chgh/cidx
MUP VISION 4900 20 50 1
BOARD_ROTATION 0
COMMENT index coordinates are relative to placement module origin
COMMENT indx /brd /refholex /refholey /board_x /board_y
INDEX 1 3 -7.000 143.500 269.000 138.000
INDEX 2 3 3.000 143.500 339.000 138.000
INDEX 3 2 -157.000 143.500 119.000 138.000
INDEX 4 2 -77.000 143.500 199.000 138.000
COMMENT feed/pick /feeder_id /type /component_id /smd info [/feeder_phi /f_pick_x /f_pick_y]
FEEDER 301 1 T12-P T 93697451 SO-8 0.0
FEEDER 303 1 T12-P T 93697711 SO-8 0.0
FEEDER 307 1 T12-P T 93697706 SO-8 0.0
FEEDER 401 1 T16-P T 286114465Z SO-16 0.0
FEEDER 404 1 T24-P T 286114414A VSOP.CA 0.0 0.2 0.1
COMMENT pick coordinates are relative to placement module origin
COMMENT fd /pk/psh/mrp/mra/pick_x /pick_y/pick_phi/na/prf/arf/ale/ple [/c_pick_x/c_pick_y]
PICK 301 1 1 1 0 19.000 77.000 90.0 1 50 28 80 80
PICK 303 1 1 1 0 51.000 77.000 90.0 1 50 28 80 80
PICK 307 1 1 1 0 99.000 77.000 90.0 1 50 28 80 80
PICK 401 1 1 1 0 187.000 77.000 90.0 1 50 30 80 80
PICK 404 1 1 1 0 235.000 77.000 90.0 1 50 30 80 80 0.2 0.1
COMMENT : In case a deviating dump position is needed enter
COMMENT : DUMP position_x position_y
DUMP 120.000 117.000
COMMENT mount coordinates are in board coordinates
COMMENT comp_ref /ci/ix/bd/fd /pk /mnt_x /mnt_y /mnt_phi /align_phi
MOUNT U2313 1 1 3 303 1 -198.780 85.390 0.0 0.0
MOUNT U4404 1 1 3 301 1 -210.080 116.740 0.0 0.0
MOUNT U2905 1 2 3 401 1 -253.130 71.040 90.0 90.0
MOUNT U2909 1 2 3 303 1 -265.830 75.870 90.0 90.0
...
...
...
4022 591 96082 User Reference Manual
02.02 FCM Multiflex 4-31
Mount Program
4.2.6.4 FEEDER
syntax: feeder_pos_nr + pick_pos_nr + feeder_id + feeder_type + component_id +
package_id / smd_info_file_id [+ feeder_phi [+ feeder_pick_vector] ]
NOTE: feeder_phi is obligatory for “AS WVM” and optional for “AS LAS”.
NOTE: feeder_pick_vector is only used for “AS WVM”, and is obligatory if the file extension of the
smd_info_file_id is “CA” (indicating an asymmetrical component).
■ feeder_pos_nr (feed)
type: integer
range: 1.. 9999
description: Denotes the position number on the feeder-bar/feeder-trolley on which
the feeder is located. The number is related to the slot-number (hole)
on the feeder-bar/feeder-trolley.
It is preferred to also include the PM position in the notation. The
preferred notation for the feeder position is :
(“PM position” * 100) + slot-nr .
Note that a WVM covers 2 PM positions
The slot nr. for a feederbar ranges from 1..8
The slot nr. for a feedertrolley ranges from 1..16
Examples:
1412: LAS 14 (or WVM 13 !!) on slot 12 of the feeder
trolley.
504: LAS 5 (or WVM 5) on slot 4 of the feeder-bar
/feedertrolley.
■ pick_pos_nr (pick)
type: integer
range: 1..16
description: Denotes the pick position within a feeder, counted from left to right.
■ feeder_id (feeder_id)
type: string
length: 1..20
description: Denotes the feeder name.
■ feeder_type (type)
type: "T" | "M" | “B”
description: For respectively: Mechanical/Pneumatical/Inteligent Tape Feeders (T),
Matched-diode feeders (M) and Bulkfeeders (B).
Mount Program
User Reference Manual 4022 591 96082
4-32 FCM Multiflex 02.02
Placement Module Activities (continued)
AS LAS/WVM 3
COMMENT
COMMENT Placement module actions for position 3
COMMENT
COMMENT PPU_id /nozzle_id /clow/chgh/cidx
MUP VISION 4900 20 50 1
BOARD_ROTATION 0
COMMENT index coordinates are relative to placement module origin
COMMENT indx /brd /refholex /refholey /board_x /board_y
INDEX 1 3 -7.000 143.500 269.000 138.000
INDEX 2 3 3.000 143.500 339.000 138.000
INDEX 3 2 -157.000 143.500 119.000 138.000
INDEX 4 2 -77.000 143.500 199.000 138.000
COMMENT feed/pick /feeder_id /type /component_id /smd info [/feeder_phi /f_pick_x /f_pick_y]
FEEDER 301 1 T12-P T 93697451 SO-8 0.0
FEEDER 303 1 T12-P T 93697711 SO-8 0.0
FEEDER 307 1 T12-P T 93697706 SO-8 0.0
FEEDER 401 1 T16-P T 286114465Z SO-16 0.0
FEEDER 404 1 T24-P T 286114414A VSOP.CA 0.0 0.2 0.1
COMMENT pick coordinates are relative to placement module origin
COMMENT fd /pk/psh/mrp/mra/pick_x /pick_y/pick_phi/na/prf/arf/ale/ple [/c_pick_x/c_pick_y]
PICK 301 1 1 1 0 19.000 77.000 90.0 1 50 28 80 80
PICK 303 1 1 1 0 51.000 77.000 90.0 1 50 28 80 80
PICK 307 1 1 1 0 99.000 77.000 90.0 1 50 28 80 80
PICK 401 1 1 1 0 187.000 77.000 90.0 1 50 30 80 80
PICK 404 1 1 1 0 235.000 77.000 90.0 1 50 30 80 80 0.2 0.1
COMMENT : In case a deviating dump position is needed enter
COMMENT : DUMP position_x position_y
DUMP 120.000 117.000
COMMENT mount coordinates are in board coordinates
COMMENT comp_ref /ci/ix/bd/fd /pk /mnt_x /mnt_y /mnt_phi /align_phi
MOUNT U2313 1 1 3 303 1 -198.780 85.390 0.0 0.0
MOUNT U4404 1 1 3 301 1 -210.080 116.740 0.0 0.0
MOUNT U2905 1 2 3 401 1 -253.130 71.040 90.0 90.0
MOUNT U2909 1 2 3 303 1 -265.830 75.870 90.0 90.0
...
...
...
