Retrofit Instructions & User’s Manual / Automatic Vacuum Support Pins (AVSP)
Edition 04/2006
1 Preface
This manual is intended as a reference on how to setup and operate the option, Automatic
Vacuum Support Pin (refer as AVSP thereof) on SIPLACE HS-60 placement machines.
If you have questions regarding these instructions or would like to have more detailed
information a particular topic, please contact appropriate Siemens’ representative or us
directly at:
Siemens A&D
Electronics Assembly Systems
Rupert-Mayer-Str. 44
D-81359 Munich
Germany
1.1 Structure of this manual
This manual consists of the following sections:
Preface
This section provides general information on this manual. It also provided some important
message on operational safety. Last but not least, some products introduction and technical
data is presented here.
Retrofit Instructions
This section listed out detailed steps on how retrofit can be done on SIPLACE HS-60.
Operation Instructions
This section highlighted the most essential steps to use this option. Detailed steps including:
(1) How to perform teaching of new PCB,
(2) How production of components placement is run with AVSP.
(3) How the controller of AVSP can be reset when necessary.
(4) How to disable vacuum functions (option to reduce air consumption).
Maintenance
This section described the only one maintenance step required for AVSP.
1-2
Retrofit Instructions & User’s Manual / Automatic Vacuum Support Pins (AVSP)
Edition 04/2006
Spare Part List
This section listed out the components that are treated as spare parts. If problem arises with
the stated parts (E.g. worn out, broken, misplaced, etc.), order can be placed thru Siemens
AG.
Troubleshooting Guide
This section described the common error encountered during the usage of AVSP.
Suggestions on how to rectify the problem can be found here.
1-3
Retrofit Instructions & User’s Manual / Automatic Vacuum Support Pins (AVSP)
Edition 04/2006
1.2 Safety Instructions
1.2.1 Convention for the use of hazard symbols
These instructions contain notes that must be observed to guarantee your personal safety
and to avoid to equipment. These notes are highlighted by warning triangles and are
indicated as follows according to the level of risk:
DANGER
or
as used in these instructions means that death, severe injury or considerable damage to
equipment
will occur if the danger warnings are not observed.
or
WARNING
as used in these instructions means that death, severe injury or considerable damage to
equipment
may occur if the danger warnings are not observed.
or
CAUTION
as used in these instructions means that slight injury or damage to equipment may occur if
the caution warnings are not observed.
NOTE
In these instructions, a note provides important information on the product or draws attention
to a specific part of the instructions which should be read particularly carefully
