Retrofit Instructions & User’s Manual / Automatic Vacuum Support Pins (AVSP)
Edition 04/2006
1.2 Safety Instructions
1.2.1 Convention for the use of hazard symbols
These instructions contain notes that must be observed to guarantee your personal safety
and to avoid to equipment. These notes are highlighted by warning triangles and are
indicated as follows according to the level of risk:
DANGER
or
as used in these instructions means that death, severe injury or considerable damage to
equipment
will occur if the danger warnings are not observed.
or
WARNING
as used in these instructions means that death, severe injury or considerable damage to
equipment
may occur if the danger warnings are not observed.
or
CAUTION
as used in these instructions means that slight injury or damage to equipment may occur if
the caution warnings are not observed.
NOTE
In these instructions, a note provides important information on the product or draws attention
to a specific part of the instructions which should be read particularly carefully
1-4
Retrofit Instructions & User’s Manual / Automatic Vacuum Support Pins (AVSP)
Edition 04/2006
1.2.2 Qualified Personnel
Qualified or adequately trained personnel:
Persons familiar with the erection, operation and maintenance of the placement machine and
supplementary equipment and who possess appropriate qualifications, e.g.:
- The education or training and/or authorization to activate, deactivate, disable, ground or
mark electric circuits and system parts in accordance with the standards of safety
engineering.
- The education or training in the care and use of appropriate safety equipment in
accordance with the standards of safety engineering.
- Training in first aid.
1.2.3 Operational safety
WARNING
The following points MUST be observed in order to maintain operational safety.
- Never open the protective covers of machine if you are not completely familiar with the
procedures and operations of the machine. The protective covers are only to be opened
when
you are instructed to do so in this SIPLACE manual and this manual.
- Never make any changes, however minor, unless you are totally aware of the effect they
will have on the overall functions of the system.
- Use only spare parts listed in section 5 that are provided by Siemens.
- The retrofittings of AVSP options includes installing and uninstalling pneumatic
components. Ensured all safety procedures highlighted are followed before carry out any
modifications or changes (see also Chapter 2.4).
- Uninstall tubing from pin module(s) to control unit only when the main air supply is
switched OFF.
- Do not adjust conveyor width while the pin module(s) is installed on the lifting table.
- Do not activate teaching mode while running of production.
1-5
Retrofit Instructions & User’s Manual / Automatic Vacuum Support Pins (AVSP)
Edition 04/2006
1.2.4 Use as prescribed
The product must only be used for its intended purposes as described in the catalogs and
technical descriptions, namely the placement of SMD components, and only with the third-
party equipment and components recommended or permitted by SIEMENS A&D. Use for a
different or extended purpose is not prescribed.
If the product is not used as prescribed, SIEMENS accepts no liability for any damage that
may occur and does not guarantee that the components will work properly and without
problems.
Use as prescribed also includes compliance with all the instructions in the user manual.
For the product to operate correctly and reliably, it must have been transported, stored,
erected and assembled correctly and must be operated and maintained with care.
1.2.5 Failure to use as described
Failure to use the product as prescribed can result in both danger to life and limb and
material damage. For this reason any use that is not prescribed is not allowed. If the product
is not used as prescribed, SIEMENS accepts no liability for any damage that may occur and
does not guarantee that the components will work properly and without problems.
Failure to use the placement machine as prescribed includes, for example the operation of
the station without safety cover or with safety cover without function.
