T he set-up tooling set is a set of tools, which is required for first time installation of the A Q-2, when the machine is moved to another location, or for periodic maintenance. 6.0 Ins t alla tion requirements T able 3…
Technical specifications
41 of 44
PA 2382/10
Feeder Trolley
PA 2675/00
Tray Trolley
PA 2674/10
Tray Carrier
PA 2635/10
Feeder Bank
PA 2673/00
Trolley Interface
Auxiliary Feeder:
Partner Products
See Feeder Product Folder
PA 2654/0x-6x
Intelligent Tape Feeder
8-56mm
PA 2601/01
ITF-2 Tape Loading Unit
PA 2602/01
Feeder Storage Cart
PA 2676/00
Manual Tray Feeder
PA 2835/00
Sector Safety Cover
The set-up tooling set is a set of tools, which is required for first time installation of the
AQ-2, when the machine is moved to another location, or for periodic maintenance.
6.0 Installation
requirements
Table 32
Figure 33
6.1 Installation
tooling
Installation requirements
42 of 44
Specifications
Power supply 190-480 Volt 3-phase, 47-63 Hz, 5 kVA
Air supply > 6 bar, 190 Nl/min
Dimensions 1560 x 1750 x 1850mm (L x W x H) (excl. trolleys)
Transport height Japanese height (885-915 mm) or SMEMA (940-965 mm)
(When adjusted to Japanese height special trolleys are
required, please contact an application engineer for details)
Weight < 1750 kg (excl. trolleys)
Ambient temperature 15-35ºC within specification range)
Humidity 20-90%, no dew
Noise < 72 dB(A) at 1 m distance
Floor flatness < 1%
