Spareparts Sparepart List Service Manual SIPLACE JEDEC Tray Feeder 87 4 4 S p a r e p a r t s Spareparts 4.1 4 . 1 S p a r e p a r t L is t Sparepart List Qt y. P/N Description mit Quasys Bestellnummer Artikel Nr. Pos. L…
Maintenance
Scheduled Maintenance 3.3.1 Weekly Maintenance
86 Service Manual SIPLACE JEDEC Tray Feeder
3.3
3.3 Scheduled Maintenance
Scheduled Maintenance
3.3.1
3.3.1 Weekly Maintenance
Weekly Maintenance
3.3.2
3.3.2 Monthly Maintenance
Monthly Maintenance
Section/Mechanism Check this Correction
All Sections of the feeder ► Check for loose, damaged or
broken parts.
► Tighten or replace.
Conveyor belts ► Check for damage, dirt. ► Clean with isopropyl alcohol.
Replace if necessary.
Magazine ► Check for damage, loose
parts or dirt.
► Re-tight screws or replace
magazine.
Section / Mechanism Check this Correction
Conveyor belts Clean ► Clean with isopropyl alcohol.
Conveyer end Plate Clean ► Clean with isopropyl alcohol.
Urethane tray clamp foot on con-
veyor mechanism
► Check for wear or damage. ► Replace if necessary.
Rodless cylinder on tray clamp
mechanism
► Check for lubrication and
smooth motion.
► If dry or moving unevenly,
wipe down the shaft with iso-
propyl alcohol.
Spareparts
Sparepart List
Service Manual SIPLACE JEDEC Tray Feeder 87
4
4 Spareparts
Spareparts
4.1
4.1 Sparepart List
Sparepart List
Qt
y.
P/N Description mit
Quasys Bestellnummer
Artikel Nr. Pos. Level JTF
2
JTF
3
DRW
Number
Assy
Group #
1 PADDLE LATCH, MINIATURE
SIZE_1032046
03111674-01 10 L1 x x 001 9041300
1 Motordriver IC U9 of Control
PCB_2033989
03111675-01 20 L1 x x 002 9036231
1 Motordriver IC U4 of Control
PCB_2034101
03111678-01 30 L1 x x 002 9036231
1 Conveyorbelt1.27x9.65x1646,
Rght_15001060
03111679-01 50 L1 x x 003 (9047139A)
1 Conveyorbelt1.27x9.65x1680,
Left_15001061
03111680-01 60 L1 x x 003 (9047139A)
4 RETAINING E RING, 3/16
SHAFT_1016859
03111682-01 70 L1 x x 003 9048424
(9047139A)
2 BEARING, .19 ID X .38 OD X
.156W_1029151
03111684-01 80 L1 x x 003 , 006 9048424
(9047139A)
1 URETHANE BELT,ENDLESS
1/8"x 6"L_1032405
03111685-01 90 L1 x x 003 , 007 9048424
(9047139A)
2 Cam Follower
13mmOD,10mm,WHK0910_1
035947
03111686-01 100 L1 x 004 9039386
2 BEAR-
ING,FLNGD,6MMIDX15MMO
DX5MM_1046980
03111689-01 120 L1 x x 003 9048424
(9047139A)
1 DOWELPIN.250 OD X .500L
HD ALLOY_1047148
03111690-01 130 L1 x x 003 9048424
(9047139A)
1 TORSION SPRING, MODI-
FIED, JTF2_3039452
03111691-01 140 L1 x x 003 , 008 9048424
(9047139A)
1 CLAMPFOOT, URETHANE
70A DUROMETE_8047228
03111693-01 150 L1 x x 003 9048424
(9047139A)
2 RETAIN RING, EXT., .125
SHAFT_1000039
03111694-01 160 L1 x x 009 9047147
4 BEARING,TEFL 3MM ID 6MM
OD 4MM L_1036796
03111697-01 170 L1 x x 009 9047147
1 KNUCKLE PIN, 3MMX6MM
W/SNAP RING_1037639
03111698-01 180 L1 x x 009 9047147
3 TORSION SPRING REWORK
9046085_3046088
03111699-01 190 L1 x 004 , 010 9046085
2 DOWEL PIN,.125 OD X .312L
HD SS_1000045
03111703-01 200 L1 x x 009 9047147
2 Plastic Bushing 4mm ID
5.5mm OD_1036227
03111704-01 240 L1 x x 011 9041300
1 ACCESS DOOR ASSEMBLY,
JTF2 KEYED_9041300
03111705-01 260 L2 x x 012 9041300
6 BEARING BF.250 ID .500 OD
.218 W_1031614
03111729-01 270 L2 x x 013 , 014 9038378
Spareparts
Sparepart List
88 Service Manual SIPLACE JEDEC Tray Feeder
1 Control PCB Assy_9036231 03111742-01 280 L2 x x 002 9036231
1 EPROM JTF3 Config
9048226-08_2034059
03111743-01 290 L2 x 002 9036231
1 DAUGHTER BOARD ASSY
RS-232, JTF2_9039470
03111744-01 300 L2 x x 031 9039470
1 Cylinder, 30mm
Stroke_1033915
03111771-01 310 L2 x x 003 , 015 9039240
1 CYLINDER, RODL.150MM
STK 6MM BOR_1039244
03111772-01 320 L2 x x 003 , 005 9039240
1 CONVEYOR MOTOR AS-
SEMBLY JEDEC II_9038305
03111773-01 330 L2 x x 003 , 016 9039240
1 CYLINDER, GUIDED RODL.
20MM BORE_1037326
03111774-01 340 L2 x 017 9044480
1 SOLENOID VALVE ASSEM-
BLY, JEDEC_2035884
03111775-01 350 L2 x 018 9044480
1 CLUTCH, SLIP CUSTOM,
5LB/IN TORQ_1037331
03111776-01 360 L2 x x 019 9044479
2 COUPLING FLEX 3/16-3/16
BORE Yel_1043899
03111783-01 370 L2 x x 020 9044479
1 GEARBOX RIGHT ANGLE
WORM DR 20:1_1046772
03111785-01 380 L2 x x 021 9044479
1 MOTOR ASSEMBLY, ELE-
VAT., JEDECII_9038306
03111786-01 390 L2 x 019 9044479
1 MOTOR ASSEMBLY, ELEVA-
TOR, JTF3_9038313
03111787-01 400 L2 x 019 9070004
1 AIR CYLIND. FEED PUSH
10BRX15 ST_1047143
03111789-01 410 L2 x x 009 9047147
1 CIRCUIT ASSEMBLY, IN-
TERF. JEDEC_9036238
03111791-01 420 L2 x x 022 , 023 9041744
1 SENSOR, THRU
BEAM_2028846
03111792-01 440 L2 x x 024 , 025
, 026
9044480
1 PROXIMITY SWITCH (CE)
JEDEC_2031877
03111793-01 450 L2 x 027 9044480
1 SENSOR, THRU-BEAM NPN
LIGHT-ON_2035879
03111794-01 460 L2 x x 003 , 028 9044480
1 PROXIMITIY SENSOR HALL
EFF 3mm_2019342
03111795-01 480 L2 x x 029 9044480
1RED
SWITCH,MAGN.MK13,1M
LEAD 1KW_2037320
03111796-01 500 L2 x x 030 9044480
1 SENSOR ASSY, RETURN
SLOW, JTF2_9039388
03111797-01 510 L2 x x 003 , 024 9044480
1 Sensor,Tray Home 3-wire Red
Len_2041604
03111798-01 520 L2 x x 026 9044480
1 SOLENOID VALVE ASSEM-
BLY, JTF3_9080407
03111799-01 960 L2 x (018) 9044480
1 PUSHER ARM, EXTENDED
STROKE_8046851
03111802-01 970 L2 x x 009 9047147
Qt
y.
P/N Description mit
Quasys Bestellnummer
Artikel Nr. Pos. Level JTF
2
JTF
3
DRW
Number
Assy
Group #
