Spareparts Sparepart List 88 Service Manual SIPLACE JEDEC Tray Feeder 1 Control PCB Assy_90 36231 03111742-01 280 L2 x x 002 9036231 1 EPROM JTF3 Config 9048226-08_203 4059 03111743-01 29 0 L2 x 002 9036231 1 DAUGHTER BO…
Spareparts
Sparepart List
Service Manual SIPLACE JEDEC Tray Feeder 87
4
4 Spareparts
Spareparts
4.1
4.1 Sparepart List
Sparepart List
Qt
y.
P/N Description mit
Quasys Bestellnummer
Artikel Nr. Pos. Level JTF
2
JTF
3
DRW
Number
Assy
Group #
1 PADDLE LATCH, MINIATURE
SIZE_1032046
03111674-01 10 L1 x x 001 9041300
1 Motordriver IC U9 of Control
PCB_2033989
03111675-01 20 L1 x x 002 9036231
1 Motordriver IC U4 of Control
PCB_2034101
03111678-01 30 L1 x x 002 9036231
1 Conveyorbelt1.27x9.65x1646,
Rght_15001060
03111679-01 50 L1 x x 003 (9047139A)
1 Conveyorbelt1.27x9.65x1680,
Left_15001061
03111680-01 60 L1 x x 003 (9047139A)
4 RETAINING E RING, 3/16
SHAFT_1016859
03111682-01 70 L1 x x 003 9048424
(9047139A)
2 BEARING, .19 ID X .38 OD X
.156W_1029151
03111684-01 80 L1 x x 003 , 006 9048424
(9047139A)
1 URETHANE BELT,ENDLESS
1/8"x 6"L_1032405
03111685-01 90 L1 x x 003 , 007 9048424
(9047139A)
2 Cam Follower
13mmOD,10mm,WHK0910_1
035947
03111686-01 100 L1 x 004 9039386
2 BEAR-
ING,FLNGD,6MMIDX15MMO
DX5MM_1046980
03111689-01 120 L1 x x 003 9048424
(9047139A)
1 DOWELPIN.250 OD X .500L
HD ALLOY_1047148
03111690-01 130 L1 x x 003 9048424
(9047139A)
1 TORSION SPRING, MODI-
FIED, JTF2_3039452
03111691-01 140 L1 x x 003 , 008 9048424
(9047139A)
1 CLAMPFOOT, URETHANE
70A DUROMETE_8047228
03111693-01 150 L1 x x 003 9048424
(9047139A)
2 RETAIN RING, EXT., .125
SHAFT_1000039
03111694-01 160 L1 x x 009 9047147
4 BEARING,TEFL 3MM ID 6MM
OD 4MM L_1036796
03111697-01 170 L1 x x 009 9047147
1 KNUCKLE PIN, 3MMX6MM
W/SNAP RING_1037639
03111698-01 180 L1 x x 009 9047147
3 TORSION SPRING REWORK
9046085_3046088
03111699-01 190 L1 x 004 , 010 9046085
2 DOWEL PIN,.125 OD X .312L
HD SS_1000045
03111703-01 200 L1 x x 009 9047147
2 Plastic Bushing 4mm ID
5.5mm OD_1036227
03111704-01 240 L1 x x 011 9041300
1 ACCESS DOOR ASSEMBLY,
JTF2 KEYED_9041300
03111705-01 260 L2 x x 012 9041300
6 BEARING BF.250 ID .500 OD
.218 W_1031614
03111729-01 270 L2 x x 013 , 014 9038378
Spareparts
Sparepart List
88 Service Manual SIPLACE JEDEC Tray Feeder
1 Control PCB Assy_9036231 03111742-01 280 L2 x x 002 9036231
1 EPROM JTF3 Config
9048226-08_2034059
03111743-01 290 L2 x 002 9036231
1 DAUGHTER BOARD ASSY
RS-232, JTF2_9039470
03111744-01 300 L2 x x 031 9039470
1 Cylinder, 30mm
Stroke_1033915
03111771-01 310 L2 x x 003 , 015 9039240
1 CYLINDER, RODL.150MM
STK 6MM BOR_1039244
03111772-01 320 L2 x x 003 , 005 9039240
1 CONVEYOR MOTOR AS-
SEMBLY JEDEC II_9038305
03111773-01 330 L2 x x 003 , 016 9039240
1 CYLINDER, GUIDED RODL.
20MM BORE_1037326
03111774-01 340 L2 x 017 9044480
1 SOLENOID VALVE ASSEM-
BLY, JEDEC_2035884
03111775-01 350 L2 x 018 9044480
1 CLUTCH, SLIP CUSTOM,
5LB/IN TORQ_1037331
03111776-01 360 L2 x x 019 9044479
2 COUPLING FLEX 3/16-3/16
BORE Yel_1043899
03111783-01 370 L2 x x 020 9044479
1 GEARBOX RIGHT ANGLE
WORM DR 20:1_1046772
03111785-01 380 L2 x x 021 9044479
1 MOTOR ASSEMBLY, ELE-
VAT., JEDECII_9038306
03111786-01 390 L2 x 019 9044479
1 MOTOR ASSEMBLY, ELEVA-
TOR, JTF3_9038313
03111787-01 400 L2 x 019 9070004
1 AIR CYLIND. FEED PUSH
10BRX15 ST_1047143
03111789-01 410 L2 x x 009 9047147
1 CIRCUIT ASSEMBLY, IN-
TERF. JEDEC_9036238
03111791-01 420 L2 x x 022 , 023 9041744
1 SENSOR, THRU
BEAM_2028846
03111792-01 440 L2 x x 024 , 025
, 026
9044480
1 PROXIMITY SWITCH (CE)
JEDEC_2031877
03111793-01 450 L2 x 027 9044480
1 SENSOR, THRU-BEAM NPN
LIGHT-ON_2035879
03111794-01 460 L2 x x 003 , 028 9044480
1 PROXIMITIY SENSOR HALL
EFF 3mm_2019342
03111795-01 480 L2 x x 029 9044480
1RED
SWITCH,MAGN.MK13,1M
LEAD 1KW_2037320
03111796-01 500 L2 x x 030 9044480
1 SENSOR ASSY, RETURN
SLOW, JTF2_9039388
03111797-01 510 L2 x x 003 , 024 9044480
1 Sensor,Tray Home 3-wire Red
Len_2041604
03111798-01 520 L2 x x 026 9044480
1 SOLENOID VALVE ASSEM-
BLY, JTF3_9080407
03111799-01 960 L2 x (018) 9044480
1 PUSHER ARM, EXTENDED
STROKE_8046851
03111802-01 970 L2 x x 009 9047147
Qt
y.
P/N Description mit
Quasys Bestellnummer
Artikel Nr. Pos. Level JTF
2
JTF
3
DRW
Number
Assy
Group #
Spareparts
Sparepart List
Service Manual SIPLACE JEDEC Tray Feeder 89
1 PUSHER, LEVER, EXTEND-
ED STROKE_8046852
03111803-01 980 L2 x x 009 9047147
1 EPROM Progr. JTF2 9044023-
07_2034060
03111805-01 990 L2 x 002 9036231
1 DOWEL PIN,2MM OD X
12MM L SS_1036915
03111807-01 1000 L1 x x 003 9039240
1 SENSOR FLAG_8031246 03111808-01 1010 L2 x x 003 9039240
1 BLOCK, CYLINDER
SLIDER_8046958
03111810-01 1020 L2 x x 003 9039240
1 RETURN PUSHER, EXT.
STROKE,JTF2_8039242
03111811-01 1030 L2 x x 003 , 005
, 008
9039240
1 HOST CABLE, JTF2 TO
SIPLACE_9039609
03111813-01 1060 L2 x x 9039609
1 SPRING COMP.360 OD .316
ID 1.0LG_1040105
03111814-01 1070 L1 x x 003 , 005 9044480
1 DOUBL.KNUCKLE JOINT
w.pin&retain_1047142
03111815-01 1080 L1 x x 003 9044480
1 Control PCB Assy JTF-
S_9036240
03111984-01 1090 L2 x 002 9036231
1 Control PCB Assy JTF-
M_9036241
03111983-01 1100 L2 x 002 9036231
Qt
y.
P/N Description mit
Quasys Bestellnummer
Artikel Nr. Pos. Level JTF
2
JTF
3
DRW
Number
Assy
Group #
