63 Configuration List Configuration Options CA4 CA3 PCB transport height (830, 900, 930, 950 mm) X X Single conveyor, fi xed side right X X Single conveyor, fi xed side left X X Single conveyor: Wide bo ard X X 21" …
62
Option List
SWS
Available options SWS
12
Notes
SIPLACE wafer transfer system (table: 1,3)
X
SIPLACE wafer transfer system (table: 2,4)
X
Adapter FF070 & FF 090 on standard frame FF 108
X
Adapter hoop ring 4" on FF 108
X
Adapter hoop ring 6" on FF 108
X
Adapter hoop ring 8" on FF 108
X
SIPLACE wafer expansion unit for 12" wafers
X
Wafer holder 8" for standard frame in combination with hoop
ring (table.: 1,3)
X
Wafer holder 8" for standard frame in combination with hoop
ring (table.: 2,4)
X
Wafer holder 12" for standard frame in combination with hoop
ring (table.: 1,3)
X
Wafer holder 12" for standard frame in combination with hoop
ring (table.: 2,4)
X
Wafer holder 8" for standard frame (table: 1,3)
X
Wafer holder 8" for standard frame (table: 2,4)
X
Multi needle eject system 3.5 x 3.5 mm min. needle pitch
X
Multi needle eject system 2.0 x 2.0 mm min. needle pitch
X
Component handling standard, field of view: 12 mm x 12 mm
X
Component handling small die, FoV: 5 x 5 mm, eject tool Sm.
die, component sensor
X
SIPLACE Linear Dipping Unit (LDU)
X
Integrated into SWS 12
and/or on X table, although
only one LDU per location.
Standard flux pot for LDU
X
SIPLACE CA LDU cavity plates, 20 - 400µm in 10µm steps
X
SIPLACE WS die attach unit
X
Nozzle changer C&P20
X
One bank in row 2
Nozzle changer C&P12
X
Two banks in row 1 and 2
Operating SW for ALPS
X
ALPS EL license for one to four SWS
X
ALPS wafer mapping HW (PC, keyboard, KVM switch, XP
software)
X
63
Configuration List
Configuration Options CA4 CA3
PCB transport height (830, 900, 930, 950 mm) X X
Single conveyor, fixed side right X X
Single conveyor, fixed side left X X
Single conveyor: Wide board X X
21" conveyor width for the single conveyor
a
XX
Dual conveyor, fixed side right X X
Dual conveyor, fixed side left X X
Dual conveyor: Wide board X X
Dual conveyor in single conveyor mode X X
Siemens/SMEMA interface X X
a) The accuracy may be limited, depending on the PCB layout.
