Retrofitting Instructions Retrofitting Instructions Bulk-Case Feeders
Edition 05/99
Page 15 of 23
Retrofitting Instructions Bulk-Case Feeders for Siplace
1 General
These retrofitting instructions describe how to install the compressed-air distributor on the component
change-over table and change-over trolley, retrofit the bulk-case air supply on the component change-over
table or change-over trolley, and install the F3 protection conversion kit (bulk-case feeders). The retrofitting
instructions are valid for SIPLACE 80 F3 placement machines as of machine number 51.
1.1 Required Tools, Testing Equipment and Documentation for Retrofitting
−
Standard tools
−
Retrofitting Instructions Bulk-Case Feeders Item no.:00190702-04
−
Adjustment gage 1 for compressed-air distributor Item no.:00322317-01
−
Adjustment gage 2 for compressed-air distributor Item no.:00322328-01
1.2 Prerequisites
−
Line computer software as of version 401.002
Required versions Hardware
Line computer PC/486 66 MHz
Operating system >=SCO ODT 3.0
−
Station computer software as of version 8.006
Required versions: MVS >=2106
M10000 >=1299
Axes >=3.6
CRDL >=B8 (2.1 / 10.08.93)
Coplanarity Provisionally: COV 201.012 ff
Sitest >= 202.XXX
Component table SW As of version 2.5
Retrofitting Instructions Bulk-Case Feeders Retrofitting Instructions
Edition 04/96
Page 16 of 23
1.3 Retrofit Kits
1.3.1 BC Compressed-Air Supply (Change-Over Table) Item No. 00142331-01
A BC compressed-air supply for the change-over table is required on the SIPLACE 80 S/F for each
component change-over table.
The retrofit kit contains the installed compressed-air distributor (long), three fixing screws and the bulk-case
air supply (change-over table) retrofit kit.
1.3.2 Bulk-Case Compressed-Air Supply (Short) Item No. 00142332-01
A bulk-case compressed-air supply (short) is required on the SIPLACE 80F for each component change-over
table with WPC.
The retrofit kit contains the installed compressed-air distributor (short), three fixing screws and the bulk-case
air supply (change-over table) retrofit kit.
1.3.3 Retrofit Kit, Bulk-Case Air Supply (Change-Over Table) Item No. 00346318-01
This retrofit kit ensures reliable compressed-air supply. One kit is required on the SIPLACE 80 S/F for each
component change-over table where there is an existing compressed-air distributor (short or long).
The retrofit kit contains the installed controller and cable mount and a ring for installation in the pneumatic
unit.
1.3.4 BC Air Supply (Moving Change-Over Table) Item No. 00142330-01
A BC air supply (moving change-over table) is required on the SIPLACE 80 S/F for each component change-
over trolley.
The retrofit kit contains the installed compressed-air distributor (long), three fixing screws and the bulk-case
air supply (change-over trolley) retrofit kit.
1.3.5 Retrofit Kit, Bulk-Case Air Supply (Change-Over Trolley) Item No. 00346319-01
This retrofit kit ensures a reliable compressed-air supply. A kit is required on the SIPLACE 80 S/F for each
component change-over trolley where there is a compressed-air distributor.
The retrofit kit contains the installed controller and cable mount and a ring for installation in the pneumatic
unit.
1.3.6 F3 Protection Conversion Kit (Bulk-Case Feeders) Item No. 00325075-01
This conversion kit is required on the SIPLACE 80F3 for each machine. Conversion is necessary so that the
bulk-case feeder does not have to be removed when the doors are opened.
The conversion kit contains 2 complete hinged doors, 2 installation strips and fixing screws.
Retrofitting Instructions Retrofitting Instructions Bulk-Case Feeders
Edition 05/99
Page 17 of 23
1.4 Safety Information
Danger !!!
The machines of the SIPLACE family are supplied with line voltage of 3 x 400V
10%, 50/60 Hz. Parts of
this system therefore carry dangerous voltages even when switched off at the main switch.
Improper handling of these machines can therefore lead to death, serious injury and considerable damage to
property.
Note the valid accident prevention and any other relevant regulations (in particular EN 60204).
Only qualified and adequately trained personnel may carry out this retrofitting work.
Switch the machine off at the main switch before beginning retrofitting work, and disconnect the power plug.
Secure the system so that it cannot be switched on again.
If you do not comply with the above, contact with live parts can result in death or serious injury.
1.4.1 Definitions
Qualified and adequately trained personnel:
Persons who know how to install, operate and maintain the placement machine and the optional devices and
who have relevant qualifications, such as:
•
Training or instruction in switching circuits and unit components on and off, and isolating, grounding or
identifying them in accordance with the standards of safety systems, as well as the authorization to do
so
•
Training or instruction in the maintenance and use of appropriate safety equipment in accordance with
safety system standards
•
Training in first aid
