1
Part names and functions
4.4 4D angular camera
The YSi-V can be optionally equipped with a 4D angular cameras that capture images obliquely from 4
directions.
4D angular camera
4D angular camera
YSi-V
23106-M9-00
n
4D angular camera
The 4D angular camera captures images obliquely from 4 directions.
When the visual inspection has to judge pass or fail (OK or NG) at the repair station, inspecting 4D images makes the
judgment easier.
Since the 4D images are saved in the program, it can be tuned offline.
1-11
1
Part names and functions
4.5 High-speed dual lane
The YSi-V can be optionally equipped with a high-speed dual lane that transfers two boards simultaneously.
High-speed dual lane
YSi-V
Lane 1
Lane 2
23107-M9-00
n
High-speed dual lane
This high-speed dual lane can transfer two boards simultaneously to increase the production volume per hour.
