F4000N Series Operating Manual
Section 5: Point Type & Function Reference
Part # 562187N-1
Rev. D Sep 2012
55
© 2012 Fisnar Inc.
2. F2 (Menu 1)
2.1 Group Edit
Group Edit is a powerful utility, which allows several different functions to be applied to a
user-defined group of addresses. These functions include copy, delete, move, multiply line
speed, multiply dispense times, apply X Offset, apply Y Offset, and apply Z Offset.
2.1.1 Copy
For example, to use group edit to copy addresses 1 – 20 in the current program to
memory address 21 - 40:
Instruction
Display Shows
1
Press the F2 (MENU 1) key, then 1 to select
Group Edit.
The display will prompt the user to enter the
starting memory address of the group to edit
(From) and the ending number of the group to
edit (To).
GROUP EDIT
FROM: 1
TO: 1
(1 <-> 4000)
F1: All F2: End
2
Type 1 then press ENTER to register 1 in From.
Type 20 then press ENTER to register 20 in To.
GROUP EDIT
ADDR: 1-20
------------------------
1.Copy 5.Dispense Time
2.Delete 6.Offset
3.Move 7.Offset (R.E)
4.Line Speed
Select:
3
The Group Edit menu will then appear, allowing
the user to select an operation to be applied to
the range of points.
Press 1 to select Copy. Then press ENTER.
GROUP COPY
------------------------
SOURCE 1-20
Destination:
4
The display will prompt the user to type the
destination memory address where the data will
be copied.
Press the Clear key to erase the old value, then
type 21 and press ENTER to select destination
memory address number 21.
GROUP COPY
SOURCE 1-20
Destination: 21
1.Yes 2.No
Select:
5
The display will now prompt the user to confirm
the copy. Press 1 and then press ENTER to
select Yes and perform the copy.
F4000N Series Operating Manual
Section 5: Point Type & Function Reference
Part # 562187N-1
Rev. D Sep 2012
56
© 2012 Fisnar Inc.
2.1.2 Delete
To use group edit to delete addresses 15 – 25 in the current program:
Instruction
Display Shows
1
Press the F2 (MENU 1) key, then 1 to select
Group Edit.
The display will prompt the user to enter the
starting memory address of the group to edit
(From) and the ending number of the group to
edit (To).
GROUP EDIT
FROM: 1
TO: 1
(1 <-> 4000)
F1: All F2: End
2
Type 15 then press ENTER to register 15 in
From.
Type 25 then press ENTER to register 25 in To.
GROUP EDIT
ADDR: 15-25
----------------------
1.Copy 5.Dispense Time
2.Delete 6.Offset
3.Move 7.Offset (R.E)
4.Line Speed
Select:
3
The Group Edit menu will then appear, allowing
the user to select an operation to be applied to
the range of points.
Press 2 to select Delete. Then press ENTER
GROUP DELETE
ADDR: 15-25
------------------------
1. Yes
2. No
Select:
4
The display will now prompt the user to confirm
the deletion.
Press 1 and then press ENTER to select Yes and
delete the data.
F4000N Series Operating Manual
Section 5: Point Type & Function Reference
Part # 562187N-1
Rev. D Sep 2012
57
© 2012 Fisnar Inc.
2.1.3 Move
To use group edit to move addresses 10 – 20 in the current program to memory
addresses 50 – 60:
Instruction
Display Shows
1
Press the F2 (MENU 1) key, then 1 to select
Group Edit.
The display will prompt the user to enter the
starting memory address of the group to edit
(From) and the ending number of the group to
edit (To).
GROUP EDIT
FROM: 1
TO: 1
(1 <-> 4000)
F1: All F2: End
2
Type 10 then press ENTER to register 10 in
From.
Type 20 then press ENTER to register 20 in To.
GROUP EDIT
ADDR: 10-20
------------------------
1.Copy 5.Dispense Time
2.Delete 6.Offset
3.Move 7.Offset (R.E)
4.Line Speed
Select:
3
The Group Edit menu will then appear, allowing
the user to select an operation to be applied to
the range of points.
Press 3 to select Move. Then press ENTER
GROUP MOVE
------------------------
SOURCE 10-20
Destination:
4
The display will prompt the user to type the
destination memory address where the data will
be moved.
Press the Clear key to erase the old value, then
type 50 and press ENTER to select destination
memory address number 50.
GROUP MOVE
SOURCE 10-20
Destination:
50
1.Yes 2.No
Select:
5
The display will now prompt the user to confirm
the move. Press 1 and then press ENTER to
select Yes and move the data.
