F4000N Series Operating Manual
Section 5: Point Type & Function Reference
Part # 562187N-1
Rev. D Sep 2012
57
© 2012 Fisnar Inc.
2.1.3 Move
To use group edit to move addresses 10 – 20 in the current program to memory
addresses 50 – 60:
Instruction
Display Shows
1
Press the F2 (MENU 1) key, then 1 to select
Group Edit.
The display will prompt the user to enter the
starting memory address of the group to edit
(From) and the ending number of the group to
edit (To).
GROUP EDIT
FROM: 1
TO: 1
(1 <-> 4000)
F1: All F2: End
2
Type 10 then press ENTER to register 10 in
From.
Type 20 then press ENTER to register 20 in To.
GROUP EDIT
ADDR: 10-20
------------------------
1.Copy 5.Dispense Time
2.Delete 6.Offset
3.Move 7.Offset (R.E)
4.Line Speed
Select:
3
The Group Edit menu will then appear, allowing
the user to select an operation to be applied to
the range of points.
Press 3 to select Move. Then press ENTER
GROUP MOVE
------------------------
SOURCE 10-20
Destination:
4
The display will prompt the user to type the
destination memory address where the data will
be moved.
Press the Clear key to erase the old value, then
type 50 and press ENTER to select destination
memory address number 50.
GROUP MOVE
SOURCE 10-20
Destination:
50
1.Yes 2.No
Select:
5
The display will now prompt the user to confirm
the move. Press 1 and then press ENTER to
select Yes and move the data.
F4000N Series Operating Manual
Section 5: Point Type & Function Reference
Part # 562187N-1
Rev. D Sep 2012
58
© 2012 Fisnar Inc.
2.1.4 Line SP (Line Speed)
To use group edit to increase all of the line speed commands in memory address range
1 – 200 by 20 %:
Instruction
Display Shows
1
Press the F2 (MENU 1) key, then 1 to select
Group Edit.
The display will prompt the user to enter the
starting memory address of the group to edit
(From) and the ending number of the group to
edit (To).
GROUP EDIT
FROM: 1
TO: 1
(1 <-> 4000)
F1: All F2: End
2
Type 1 then press ENTER to register 1 in From.
Type 200 then press ENTER to register 200 in To.
GROUP EDIT
ADDR: 1-200
----------------------
1.Copy 5.Dispense Time
2.Delete 6.Offset
3.Move 7.Offset (R.E)
4.Line Speed
Select:
3
The Group Edit menu will then appear, allowing
the user to select an operation to be applied to the
range of points.
Press 4 to select Line Speed. Then press ENTER.
GROUP LINE SPEED
ADDR: 1-200
------------------------
Multiple Value:
4
The display will prompt the user to type the
Multiple Value to be applied to the line speeds.
For example, a value of 1.2 will increase all
speeds by 20%. A value of 0.8 will decrease all
speeds by 20%.
Type 1.2 and press ENTER to select a multiplier
of 1.2.
GROUP LINE SPEED
ADDR: 1-200
------------------------
Multiple Value:
1.2
1.Yes
2.No
Select:
5
The display will now prompt the user to confirm
the change. Press 1 to select Yes. Then press
ENTER
All of the line speed instructions in the select
range of points will now be multiplied by 1.2.
F4000N Series Operating Manual
Section 5: Point Type & Function Reference
Part # 562187N-1
Rev. D Sep 2012
59
© 2012 Fisnar Inc.
2.1.5 Dispense Time
To use group edit to increase all of the dispensing times (Point Dispense Setup) in
memory address range 1 – 200 by 15%:
Instruction
Display Shows
1
Press the F2 (MENU 1) key, then 1 to select
Group Edit.
The display will prompt the user to enter the
starting memory address of the group to edit
(From) and the ending number of the group to
edit (To).
GROUP EDIT
FROM: 1
TO: 1
(1 <-> 4000)
F1: All F2: End
2
Type 1 then press ENTER to register 1 in From.
Type 200 then press ENTER to register 200 in To.
GROUP EDIT
ADDR: 1-200
------------------------
1.Copy 5.Dispense Time
2.Delete 6.Offset
3.Move 7.Offset (R.E)
4.Line Speed
Select:
3
The Group Edit menu will then appear, allowing
the user to select an operation to be applied to the
range of points.
Press 5 to select Dispense Time. Then press
ENTER.
GROUP DISPENSE TIME
ADDR: 1-200
------------------------
Multiple Value:
4
The display will prompt the user to type the
Multiple Value to be applied to the dispense times.
For example, a value of 1.15 will increase all
dispense times by 15%. A value of 0.85 will
decrease all dispense times by 15%.
Type 1.15 and press ENTER to select a multiplier
of 1.15.
GROUP DISPENSE TIME
ADDR: 1-200
------------------------
Multiple Value:
1.15
1.Yes
2.No
Select:
5
The display will now prompt the user to confirm
the change. Press 1 to select Yes. Then press
ENTER.
All of the Point Dispense Setup instructions in the
select range of points will now be multiplied by
1.15.
