Semi-conductor System Div 4 PUSHER ASS'Y 1 5 J9065196A CROSS LEVER ASS'Y 1 6 J9065201A DRAIN GEAR ASS'Y 1 6 J9065202A DRAIN GEAR ASS'Y 1 16mm EXCLUSIVE 7 DRAIN ASS'Y 1 11 REEL PLATE ASS'Y 1 …
Semi-conductor System Div
LEVEL
12~16mm SM Tape Feeder (Front, Rear) - CS PART
NO. PART NO. PART NAME TYPE REMARK
J9060367A NON IT BOARD REV-1.0
NON IT TYPE A
J9060366A IT SLAVER BOARD REV-2.0
IT TYPE A
CS-24
J7066024A COUPLER BKT1 SM1-MF08-090
C
CS-25
J7066040A TOGGLE SPRING SM1-MF08-125
50ea = 1 pack C
47
J7066070A LOCKER SPRING SM1-MF12-118-2
30ea = 1 pack A
48
J7066071A TAPE GUIDE SPRING SM1-MF12-119-2
30ea = 1 pack A
49
J7066072A FEEDING SPRING SM1-MF12-120-2
30ea = 1 pack A
50
J7066073A STOP PAWL SPRING SM1-MF12-121-9
30ea = 1 pack A
51
J7066075A REWIND SPRING SM1-MF12-123-4
30ea = 1 pack A
J7066085A LOCKER LIMIT SPRING SM1-MF12-148
30ea = 1 pack A
J7066086A LOCKER LIMIT SPRING(16mm type) SM1-MF16-148
30ea = 1 pack A
64
J7066089A TAPE SUPPORT SCREW TF12-N017
30ea = 1 pack A
68
J6049000390 ENG WASHER LL-1218-01
50ea = 1 pack A
73
J1301226 C-RING(SHAFT) DIA12.0(SUS)
50ea = 1 pack A
74
J1301023 E-RING DIA3.0(SUS)
200ea = 1 pack A
75
J1301149 E-RING DIA4.0(SUS)
100ea = 1 pack A
76
J6071600050 E-RING DIA6.0(SUS)
50ea = 1 pack A
77
J6004300550 BUTTON HEAD CAP SCREW M3*5(SUS)
50ea = 1 pack A
78
J6004300650 BUTTON HEAD CAP SCREW M3*6(SUS)
50ea = 1 pack A
79
J6004301050 BUTTON HEAD CAP SCREW M3*10(SUS)
50ea = 1 pack A
80
J1301161 FLAT HEAD CAP SCREW M2*3(SUS)
50ea = 1 pack A
81
J1301158 FLAT HEAD CAP SCREW M3*5(SUS)
50ea = 1 pack A
82
J1301448 FLAT HEAD CAP SCREW M3*6(SUS)
100ea = 1 pack A
83
J6006300850 FLAT HEAD CAP SCREW M3×8(SUS)
200ea = 1 pack C
84
J1301157 FLAT HEAD SOCKET SCREW M4*10(SUS)
50ea = 1 pack A
85
J6007300838 FLAT HEAD SOCKET SCREW M3*8(BL/Zn)
50ea = 1 pack A
86
J6007301238 FLAT HEAD SOCKET SCREW M3*12(BL/Zn)
100ea = 1 pack A
87
J6010300438 SOCKET SET SCREW M3*4(BL/Zn)
50ea = 1 pack A
88
J1301154 FLAT WASHER M3(SUS)
50ea = 1 pack A
89
J1300717 FLAT WASHER M4(SUS)
100ea = 1 pack A
90
J1301225 SPRING WASHER M4(SUS)
50ea = 1 pack A
91
J1301148 STAR WASHER M3(SUS)
50ea = 1 pack A
59
CS-23
System Engineering Team
Semi-conductor System Div
4
PUSHER ASS'Y
1
5
J9065196A CROSS LEVER ASS'Y 1
6
J9065201A DRAIN GEAR ASS'Y 1
6
J9065202A DRAIN GEAR ASS'Y 1
16mm EXCLUSIVE
7
DRAIN ASS'Y 1
11
REEL PLATE ASS'Y
1
12
REEL ARM ASS'Y
1
13
CYLINDER ASS'Y 1
J9065281A
PROBER CABLE ASS'Y
1
SM1-MF12-221 (NON IT EXCLUSIVE)
16
J7065944A
V LOC PIN
1
SM1-MF08-002
17
J7065948A
LOCATION FLANGE
1
SM1-MF08-006
18
J7065956B
LINK SHAFT COVER2
1 SM1-MF08-014
19
J7065978A
INSTALL GUIDE
1
SM1-MF08-040
20
J7065981A
PROBER COVER
1 SM1-MF08-043
21
J7065994A
TOGGLE STOPPER
2
SM1-MF08-058
22
J7066001A
T LINK4 SHAFT1
1 SM1-MF08-064
23
J7066008A
T LINK1 SHAFT1
1 SM1-MF08-071
24
J7066022A
T LINK5 SHAFT1
1
SM1-MF08-088
26
J7066026A
T-COVER
1 SM1-MF08-092
27
J7066030A
TOGGLE STOPPER2
1
SM1-MF08-096
28
J7066047A
FLAT HEAD CAP SCREW-H4.4
16
SM1-MF08-132
30
J7165294B
MAIN FRAME
1 SM1-MF12-001
30
J7165295A
MAIN FRAME
1 SM1-MF16-001
16mm EXCLUSIVE
31
J7066050A Y ECCENTRIC PIN 1 SM1-MF12-009-2
33
J7066052A LIMIT SHAFT 1 SM1-MF12-017-2
34
J7066054A
SPROCKET SHAFT
1 SM1-MF12-031-2
35
J7066057A
TAPE GUIDE SHAFT
1 SM1-MF12-038
35
J7066058A
TAPE GUIDE SHAFT
1 SM1-MF16-038
16mm EXCLUSIVE
36
J7165296A
REEL COVER
1 SM1-MF12-039-3
38
J7066059A
LOCKER SHAFT
1
SM1-MF12-076
12~16mm SM Tape Feeder (Front, Rear) - Undefined
NO. PART NO. PART NAME TYPE REMARKQ'TY
System Engineering Team
Semi-conductor System Div
12~16mm SM Tape Feeder (Front, Rear) - Undefined
NO. PART NO. PART NAME TYPE REMARKQ'TY
38
J7066060A
LOCKER SHAFT
1
SM1-MF16-076 16mm EXCLUSIVE
39
J7066062A SENSOR DOG 1
SM1-MF12-106-2
40
J7066063A
LEVER SHAFT1
1
SM1-MF12-108-3
41
J7066064A
CYL BKT PIN
1 SM1-MF12-109
42
J7066065A
LEVER SHAFT 2
1
SM1-MF12-110-2
43
J7066066A
SPRING PIN 37
2
SM1-MF12-111-2
44
J7265162A
TIE MOUNT
1
SM1-MF16-112 16mm EXCLUSIVE
45
J7066067A
TAKE UP REEL SHAFT
1 SM1-MF12-115-3
45
J7066068A
TAKE UP REEL SHAFT
1 SM1-MF16-115-3
16mm EXCLUSIVE
46
J7066069A
TAPE SUPPORT
1 SM1-MF12-116
52
J9065195A
LINK 2 ASS`Y
1 SM1-MF12-205
53
J7165297A
PCB COVER
1 SM1-MF12-128-3
54
J7066076A
SPRING PIN 25
3
SM1-MF12-129
55
J7066077A
DRAIN SHAFT-S
1
SM1-MF12-130-3
55
J7066078A
DRAIN SHAFT-S
1
SM1-MF16-130-3
16mm EXCLUSIVE
56
J7066080A
PCB SUPPORT
3
SM1-MF12-137
57
J7066083A
LOCKING LIMIT
1 SM1-MF12-140-2
58
J7265163A CABLE COVER 1 SM1-MF12-146
60
J7066313A
TOGGLE STOPPER2
1
SM1-MF12-150
62
J7066087A
VINYL ROLLER SHAFT
1 SM1-MF16-037-2
63
J7066088A
FORMING BKT SHAFT
1 SM1-MF12-131-3
65
J7265131A
DAMPER
1
TF12-N226
66
J7065802A DAMPER WASHER 1
TF12-N228
67
J7065350A
LEVER SHAFT 1
2
TF44-107R
69
J6711249A
COUPLER PLUG
1
KS-4-M5-SA34268KR
70
TIE MOUNT
1
71
J6025300050
HEX NUT(STYLE 2)
2
M3-STYLE 2(SUS)
72
J6025400050
HEX NUT(STYLE 3)
1 M4-STYLE 3(SUS)
93
J7065992A
BOTTOM LOC PIN
1
SM1-MF08-056
J9065212A
CLAMP SWITCH CABLE ASS'Y
1 SM1-MF12-219
REEL PLATE ASSY
