Semi-conductor System Div 12~16mm SM Tape Feeder (Front, Rear) - Undefined NO. PART NO. PART NAME TYPE REMARK Q'TY J7066113A VINYL ROLLER SHAFT2 1 SM1-MF12-114-2 REEL PLATE ASSY J7065797A STOPPER IN BUSH 1 TF12-N222…
Semi-conductor System Div
12~16mm SM Tape Feeder (Front, Rear) - Undefined
NO. PART NO. PART NAME TYPE REMARKQ'TY
38
J7066060A
LOCKER SHAFT
1
SM1-MF16-076 16mm EXCLUSIVE
39
J7066062A SENSOR DOG 1
SM1-MF12-106-2
40
J7066063A
LEVER SHAFT1
1
SM1-MF12-108-3
41
J7066064A
CYL BKT PIN
1 SM1-MF12-109
42
J7066065A
LEVER SHAFT 2
1
SM1-MF12-110-2
43
J7066066A
SPRING PIN 37
2
SM1-MF12-111-2
44
J7265162A
TIE MOUNT
1
SM1-MF16-112 16mm EXCLUSIVE
45
J7066067A
TAKE UP REEL SHAFT
1 SM1-MF12-115-3
45
J7066068A
TAKE UP REEL SHAFT
1 SM1-MF16-115-3
16mm EXCLUSIVE
46
J7066069A
TAPE SUPPORT
1 SM1-MF12-116
52
J9065195A
LINK 2 ASS`Y
1 SM1-MF12-205
53
J7165297A
PCB COVER
1 SM1-MF12-128-3
54
J7066076A
SPRING PIN 25
3
SM1-MF12-129
55
J7066077A
DRAIN SHAFT-S
1
SM1-MF12-130-3
55
J7066078A
DRAIN SHAFT-S
1
SM1-MF16-130-3
16mm EXCLUSIVE
56
J7066080A
PCB SUPPORT
3
SM1-MF12-137
57
J7066083A
LOCKING LIMIT
1 SM1-MF12-140-2
58
J7265163A CABLE COVER 1 SM1-MF12-146
60
J7066313A
TOGGLE STOPPER2
1
SM1-MF12-150
62
J7066087A
VINYL ROLLER SHAFT
1 SM1-MF16-037-2
63
J7066088A
FORMING BKT SHAFT
1 SM1-MF12-131-3
65
J7265131A
DAMPER
1
TF12-N226
66
J7065802A DAMPER WASHER 1
TF12-N228
67
J7065350A
LEVER SHAFT 1
2
TF44-107R
69
J6711249A
COUPLER PLUG
1
KS-4-M5-SA34268KR
70
TIE MOUNT
1
71
J6025300050
HEX NUT(STYLE 2)
2
M3-STYLE 2(SUS)
72
J6025400050
HEX NUT(STYLE 3)
1 M4-STYLE 3(SUS)
93
J7065992A
BOTTOM LOC PIN
1
SM1-MF08-056
J9065212A
CLAMP SWITCH CABLE ASS'Y
1 SM1-MF12-219
REEL PLATE ASSY
System Engineering Team
Semi-conductor System Div
12~16mm SM Tape Feeder (Front, Rear) - Undefined
NO. PART NO. PART NAME TYPE REMARKQ'TY
J7066113A
VINYL ROLLER SHAFT2
1 SM1-MF12-114-2
REEL PLATE ASSY
J7065797A
STOPPER IN BUSH
1 TF12-N222
REEL ARM ASSY
J7065810A
REEL ARM POST
1 TF12-N241
REEL ARM ASSY
J7066114A
VINYL ROLLER SHAFT2
1 SM1-MF16-114
REEL PLATE ASSY
J7065825A
REEL ARM POST
1 TF16-N241
REEL ARM ASSY
